Setup menu

The available menu items are dependent on the input
source being selected.
The illustration is for reference only.
Item
Auto installation
Manual
installation
CH swap
AV 1
AV 2
AV 3
Auto
Frequency
Phase
H. Position
V. Position
26 The On-Screen Display (OSD) menu
Function
Clears both the TV channel list and the sequential channel list, then reloads and
searches through the designated TV frequencies for available channels, and adds
any found to the sequential channel list, depending upon the selected country:
• If Australia or New Zealand is selected, this function loads the channel list
and searches through the designated TV frequencies for that country, adding
any found to the sequential channel list in their proper channel positions.
• If 'Others' is selected as country, searches through all frequencies for the
selected PAL TV standard, adding any channels found to the sequential
channel list in sequential order starting a position zero.
See "Performing Auto installation" on page 27
Used for adding channels to the sequential channel list. Allows you to manually
select a channel position in the sequential channel list, and adjust its properties
including channel frequency.
See "Performing Manual installation" on page
Allows you to reorder the channel positions in the sequential channel list, as
used by the Channel Up and Down buttons.
See "Swapping channels in the sequential channel list" on page
Selects the input signal terminal
when AV1, AV2 or AV3 is selected as
the input. Use these settings only
whenever you have more than one
signal type connected to the same
input at the same time.
Do not select 'Auto' when more
than one signal type is
connected simultaneously to the
same AV input terminal.
Automatically adjusts frequency,
phase, H. position and V. position to
place the image on the screen.
Adjusts the display clock frequency. Press or to
Adjusts the display clock phase.
Adjusts the horizontal position of
the image.
Adjusts the vertical position of the
image.
Setup
Auto installation
Manual installation
CH swap
Select Adjust
Operation
27.
Press or to
make selection.
0 to 100
make adjustment.
0 to 31
0 to 100
0 to 100
Enter
OK
Range
29.
• S-Video
• CVBS
(composite Video)
• Auto
• CVBS
(composite Video)
• YPbPr
(Component video)
• Auto
• No
• Yes
