New Classic Furniture BISCAYNE B3314-060 Assembly Instructions

Thank you for purchasing this quality product. Be sure to check all packing materials carefully for small parts,
which may have come loose inside the carton during shipment. Identify and count all items and compare with
the parts list and/or hardware list shown below.
Please read all instructions carefully. See the hardware and furniture part listing for guidance. Be sure you have
all parts listed before beginning assembly. Place all wooden parts on a clean, flat surface to protect the finish
from scratches. Follow the diagram to assemble.
CAUTION
1. Do not fully tighten the nuts or bolts until the table is fully assembled.
2. Please tighten by hand, not by a drill. Overtightening will damage threads. Do not overtighten.
3. Keep all hardware out of the reach of childen.
ITEM DESCRIPTION
A MIRROR
B MIRROR SUPPORT
C DRESSER
(FROM DRESSER BOX)
HARDWARE DIMENSIONS
VERIFICATION TOOL
STEP 1: Assemble the Mirror Support (B) with the Dresser (C) by using Allen Key (4) with hardware (1), (2) and (3).
** Attention: DO NOT OVER TIGHTEN THE BOLTS.
B
C
ASSEMBLY INSTRUCTIONS
BISCAYNE COLLECTION
MODEL : B3314-060 BISCAYNE MIRROR
PARTS LIST
SKETCH
inches
B
QTY
ITEM DESCRIPTION
BOLT M6 x 1
1 PC 1
2 SPRING WASHER M6 x
FLAT WASHER M6 x
2 PCS 3
ALLEN KEY M4 x 2
4
1 PC
1 2
1
4
HARDWARE LIST
SKETCH
9
"
16
7
"
16
3
"
4
3
"
8
3
3
2
MADE IN MALAYSIA
QTY
8 PCS
8 PCS
8 PCS
1 PC
4
