AHDH-TY1
(Continued from page 3)
Enters into scan mode. It will seek to the next found chan-
SCAN
nel in HD mode continuously until pressed again. If in iPod
mode, it will scan to the next song in the current playlist.
Pressing the scan button a second time will disable the
scan mode.
Toggles through the different available display options for
TEXT
current song.
CONTROLS FOR RADIOS EQUIPPED
WITH CD CHANGER CONTROLS
BUTTON
DESCRIPTION OF FUNCTION
DISC Enters into 'CD Changer' mode & selects the next
device. If HD-AM was the previous device that was
playing, then HD-FM is selected and vise versa. If an
iPod is attached, then it will alternatively be chosen in
the following order :
HD-AM > iPod > HD-FM > iPod
Seeks to the next found station in HD-AM or HD-FM. In
TRK
iPod it goes to the next/previous song.
PRESET#1
In iPod mode, this toggles the Random mode playback.
PRESET#3 In iPod mode, this goes to the previous playlist.
In iPod mode, this goes to the next playlist.
PRESET#4
PRESET#5 In HD mode, this goes to the next physical station.
PRESET#6 In HD mode, this goes to the previous physical station.
SCAN
Enters into scan mode. It will seek to the next found
channel in HD mode continuously until pressed again.
If in iPod mode, it will scan to the next song in the cur-
rent playlist. Pressing the scan button a second time
will disable the scan mode.
FIRMWARE FOR THE iPOD
The firmware in your iPod must be the latest revision to operate correctly.
Go to Apple.com and check your revision with iPod Update.
4
AHDH-TY1
5
Rev. 03/04/08
1-800-221-0932 www.metraonline.com
©Copyright 2007-2008 Metra Electronics Corporation
TOYOTA/SCION HARNESS
USED WITH AHDT-01 AND AHDI-IO1
AHDH-TY1
INSTALLATION INSTRUCTIONS
* READ IMPORTANT WARNING ON PAGE 1
BEFORE ATTEMPTING ANY INSTALLATION
The AHDH-TY1 is to be used along with the AHDT-01 HD Tuner and
the AHDI-I01 import HD radio interface (all sold separately) in the
vehicles listed. An iPod may also be connected by using the XIAH-IPC
iPod cable (sold separately). The OEM radio will control the functions
of the HD Tuner and the iPod through the buttons on the radio. Also
for those radios that do not display text, the XIA-LCD display screen
(sold separately), may be added to display the HD and iPod text
information. NOTE: The factory CD changer or satellite tuner must
be disconnected if both are present.
INSTAHDH-TY1
1-800-221-0932
©Copyright 2007-2008 Metra Electronics Corporation
A A P P P P L L I I C C A A T T I I O O N N S S : :
TOYOTA
4-Runner 2003-2007
Celica 2003-2006
Camry 2005-2006
Highlander 2003-2008
Landcruiser 2003-2007
MR2 2003-2005
Prius 2004
Rav4 2003-2007
Sequoia 2003-2007
Sienna 2003-2007
Tacoma 2005-2007
Tundra 2003-2008
SCION
xA 2004-2007
xB 2004-2008
tC 2005-2007
