REV. 08-04-09
KIT FEATURES
Shaft and
99-5600
DIN unit
provisions
AW-560FD
Equalizer
provisions
INSTALLATION
Rear support
provisions
INSTRUCTIONS
APPLICATIONS
KIT COMPONENTS
CAR
FORD
Radio Housing
Crown Victoria 1995-09............ ........ 1-2
Econoline 1997-08............................ 1-2
Explorer 1995-01...............................1-2
Ranger 1995-09................................ 1-2
LINCOLN
Continental 1995-97..........................1-2
Mark VIII 1996-98..............................1-2
Equalizer
Dummy
Town Car 1995-02.............................1-2
Plate
MAZDA
B-Series Pickup 1995-09...................1-2
Rear Support
Bracket
MERCURY
Grand Marquis 1995-09.....................1-2
Marauder 2003-04..............................1-2
TOOLS REQUIRED
Mountaineer 1997-01........................ 1-2
WIRING AND ANTENNA CONNECTIONS (Sold Separately)
Harness:
• Please see www.metraonline.com for specific interface harness
Antenna Adapter:
• 40-CR10 - Chrysler antenna adapter 02-up
86-5618 or AW-FDRT -
Head unit removal keys
Phillips screwdriver
1-800-221-0932
Cutting tool
© COPYRIGHT 2001-09 METRA ELECTRONICS CORPORATION
PAGE
K
P
NOWLEDGE IS
OWER
Enhance your installation and fabrication skills
by enrolling in the most recognized and respected
mobile electronics school in our industry.
Log onto www.installerinstitute.com
or call 800-354-6782 for more information
and take steps toward a better tomorrow.
www.metraonline.com
Advertisement
Table of Contents
Related Manuals for Metra Electronics 99-5600
Summary of Contents for Metra Electronics 99-5600
- Page 1 Log onto www.installerinstitute.com or call 800-354-6782 for more information Phillips screwdriver and take steps toward a better tomorrow. 1-800-221-0932 Cutting tool © COPYRIGHT 2001-09 METRA ELECTRONICS CORPORATION PAGE NOWLEDGE IS OWER www.metraonline.com...
- Page 2 ALL VEHICLES Disconnect the negative battery terminal to prevent an accidental short circuit. Using Metra's 86-5618 or AW-FDRT, pull the factory head unit from the dash and disconnect the wiring. Fig. A B-SERIES PICKUP, ECONOLINE, EXPLORER, MOUNTAINEER, RANGER: Position the Radio Housing with the radio opening at the TOP for the remainder of the installation.
