INFINITY ID2 ACTIVE REPEATER MANUAL
6 Menu Structure
To help locate the different features available, the menu structure of the Infinity ID2 Active repeater panel is
shown here.
MENU LAYOUT
1:Language Choose between English, Spanish, Portuguese, French, Italian, Hungarian, Serbian,
Lithuanian with prev & next keys. Press enter to select
2:Panel Type Select the panel this repeater is connected to with the Prev & Next Keys. Options are:-
Simplicity 126 / Simplicity 64 / Simplicity 252
Infinity ID2/2 Zone / Infinity ID2/4 Zone / Infinity ID2/6 Zone / Infinity ID2/8 Zone
Select repeater number with buttons 1 to 8. Each repeater on a system must have a
different number
3:Activity Selects which commands the repeater will send to the main panel:-
A * means the option is selected. If Silence all has a *, it will silence its own buzzer, the
panel`s buzzer, and any other repeaters connected. If silence is not marked with a *, it
will just silence it`s own buzzer.
7. GENERAL FAULT FINDING
The Infinity ID2 repeater panel does not have any input or output circuits, so any General faults reported should
be investigated at the main panel. There are 2 possible faults which can be generated by the repeater itself
7.1 Communication fault
Communication fault means that the repeater cannot see the communications from
the main panel. The possible causes for this are:-
Communication cable reverse polarity. It should be connected A to A and B to B
Communication cable loose connection or cable break
Damaged repeater PCB
Damaged panel PCB
To check a PCB, Disconnect the data cable. Then check the DC voltage between B and A with a DVM. It should
be around 1.5V
7.2 System fault
A system fault is an abnormal microprocessor running condition due to various unexpected phenomena.
This will result in the panel attempting to correct itself. Should this fault occur, the System Fault LED, General
Fault LED, General Fault relay and fault internal buzzer will be constantly active until the control panel is reset.
Disconnect the power to the repeater. Wait for 10 seconds, then turn power back on. This should cause the
system fault condition to clear. If not, it is likely that the PCB is damaged. Consult your supplier.
Approved Document No: GLT-221-7-1
Issue 1.0 Author: NRPJ
.
1. Start sounders
2. Stop Sounders
3. Reset Panel
4. Silence All
Date: 29/11/2013
Software Versions: 0.H.8682
Infinity ID2/8 Zone
Repeater Panel 1
Communication Lost
