INFINITY ID2 ACTIVE REPEATER MANUAL
9 SPECIFICATIONS
9.1 Enclosure specifications
DESCRIPTION
ENCLOSURE SIZE
TOP CABLE ENTRIES
9.2 Electrical specifications
ELECTRICAL DESCRIPTION
SUPPLY VOLTAGE
OPERATING CURRENT
AUXILIARY FAULT OUTPUT
MAX NUMBER OF REPEATERS PER SYSTEM
REPEATER CONNECTION
Approved Document No: GLT-221-7-1
Issue 1.0 Author: NRPJ
.
Date: 29/11/2013
VALUE
364 x 302 x 90 mm
15 x 19mm DIA ENTRIES
VALUE
29V DC Nominal (19 to 30V DC)
40mA typical
1 x FAULT RELAY SELV@1A (NORM. ENERG)
8
RS485
Software Versions: 0.H.8682
