AGSE -E262-G05-LTLS Manual

Transportation stand for pratt & whitney pw1130g-jm engine and pw1400g-jm engine
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
ADVANCED GROUND SYSTEMS ENGINEERING LLC
and shall not be reproduced, transferred to other documents, disclosed to others, or used for
any purpose other than that for which it is furnished without the prior written permission of
AGSE-E262-G05-LTLS
Transportation Stand
ORIGINAL MANUAL DATED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8/4/2023
LATEST MANUAL REVISION LEVEL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12/18/2023 (REV B)
Advanced Ground Systems Engineering LLC
10805 Painter Ave., Santa Fe Springs, CA, 90670 • PHONE: 562-906-9300 • FAX: 562-906-9308 • E-MAIL: agse@agsecorp.com
This document contains information proprietary to
Advanced Ground Systems Engineering LLC.
For Pratt & Whitney
PW1130G-JM Engine
PW1400G-JM Engine
and

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AGSE-E262-G05-LTLS and is the answer not in the manual?

Questions and answers

Related Manuals for AGSE AGSE-E262-G05-LTLS

Summary of Contents for AGSE AGSE-E262-G05-LTLS

  • Page 1 LATEST MANUAL REVISION LEVEL ....... 12/18/2023 (REV B) Advanced Ground Systems Engineering LLC 10805 Painter Ave., Santa Fe Springs, CA, 90670 • PHONE: 562-906-9300 • FAX: 562-906-9308 • E-MAIL: agse@agsecorp.com...
  • Page 2 • Substitution of AGSE-supplied parts, including hardware, with an alternate source or supplier • Reverse engineering of AGSE equipment and parts. Requests for modifications should be submitted to AGSE for review – please send modification requests to support@agsecorp.com. Once reviewed by our Engineering team, a Customer Support Letter (Subject: No Technical Objection) will be issued for any approved modifications.

  • Page 3: Table Of Contents

    Statement of Warranty ......... 7.0 Page B AGSE-E262-G05-LTLS PW1130G-JM/PW1400G-JM Engine Transport Stand Dec 18, 2023...

  • Page 4: Description Page(S)

    IPB Figure 2 - AGSE-E26201-S01-LTLS Base Assembly ..8.4 IPB Figure 3 - AGSE-E26202-S03 Cradle Assembly ... . . 8.10 IPB Figure 4 - AGSE-E26288-S01 Blocker Assembly ... . 8.15 IPB Figure 5 - AGSE-E26238-S01/S02 Front Mounting Leg Assys .

  • Page 5: Revisions

    1.0 – Revisions The following is an itemized record of all changes from previous revision. PAGE DESCRIPTION OF CHANGE DATE Updated EC Declaration 12/18/2023 Page 1.0 AGSE-E262-G05-LTLS PW1130G-JM/PW1400G-JM Engine Transport Stand Dec 18, 2023 Rev B...

  • Page 6: Illustrations

    2.0 – Illustrations Figure 2.0-1 AGSE-E262-G05-LTLS Engine Transport Stand with Spacers in Storage Position Page 2.0 AGSE-E262-G05-LTLS PW1130G-JM/PW1400G-JM Engine Transport Stand Dec 18, 2023 Rev B...
  • Page 7 2.0 – Illustrations (Continued) Figure 2.0-2 AGSE-E262-G05-LTLS Engine Transport Stand Raised by Spacers Page 2.1 AGSE-E262-G05-LTLS PW1130G-JM/PW1400G-JM Engine Transport Stand Dec 18, 2023 Rev B...
  • Page 8 2.0 – Illustrations (Continued) Figure 2.0-3 AGSE-E262-G05-LTLS Engine Transport Stand with PW-1130G Engine Page 2.2 AGSE-E262-G05-LTLS PW1130G-JM/PW1400G-JM Engine Transport Stand Dec 18, 2023 Rev B...
  • Page 9 2.0 – Illustrations (Continued) Figure 2.0-4 AGSE-E262-G05-LTLS Engine Transport Stand Fully Stowed Page 2.3 AGSE-E262-G05-LTLS PW1130G-JM/PW1400G-JM Engine Transport Stand Dec 18, 2023 Rev B...

  • Page 10: Specification

    The AGSE-E262-G05 version is designed without GPS transmitter. The engine transport stand includes an AGSE-E26202-S03 cradle and AGSE-E26201-S01-LTLS base. The AGSE-E26202-S03 cradle consists of a welded steel frame with removable engine ground handling mounts compatible with the PW1130G-JM/PW1400G-JM Engine in QEC configuration.

  • Page 11: Fabrication And Finish

    Stand Height (In.) (with 5” Shipping Spacers) 72-5/16 Cradle Weight (Lbs) 2000 Base Weight (Lbs) 2800 Total Stand Weight (Lbs) 4800 Total Stand Weight with Engine (Lbs) 12,400 Page 3.1 AGSE-E262-G05-LTLS PW1130G-JM/PW1400G-JM Engine Transport Stand Dec 18, 2023 Rev B...
  • Page 12 2 1/4 5 1/2 13 1/2 144 11/16 Figure 3.5-1 Engine Transport Stand Dimensions with Blockers Deployed Page 3.2 AGSE-E262-G05-LTLS PW1130G-JM/PW1400G-JM Engine Transport Stand Dec 18, 2023 Rev B...
  • Page 13 184 1/8 Figure 3.5-1 Engine Transport Stand with Engine Page 3.3 AGSE-E262-G05-LTLS PW1130G-JM/PW1400G-JM Engine Transport Stand Dec 18, 2023 Rev B...

  • Page 14: Maintenance And Inspection

    The Pump reservoir level should be checked every 90 days and refilled as necessary with the following hydraulic oil: Manufacturer Product Commercial MIL-5606 SAE 5W Commercial (Mobil DTE 24) or Equivalent Page 4.0 AGSE-E262-G05-LTLS PW1130G-JM/PW1400G-JM Engine Transport Stand Dec 18, 2023 Rev B...

  • Page 15: Scheduled Inspection

    The stand structure is to be visually inspected for damage, weld cracks, or corrosion. CAUT ION AGSE recommends that shock mounts be replaced every five (5) years. Additionally, periodic inspections should be performed and any of the following conditions are proper cause for replacement of the shock mounts prior to their expiration: Visible evidence of cracks.

  • Page 16: Hydraulic System Maintenance

    DO NOT fully tighten the pressure relief valve. This will make the output pressure on the hand pump too high, and will cause damage to the seals in the hydraulic system. Page 4.2 AGSE-E262-G05-LTLS PW1130G-JM/PW1400G-JM Engine Transport Stand Dec 18, 2023 Rev B...

  • Page 17: Pressure Release Valve

    LIFTING CYLINDER PRESSURE RELEASE VALVE FLOW DIVIDER BLEED PORT FLOW DIVIDER PISTON Figure 4.5-1 PRESSURE RELIEF VALVE Figure 4.5-2 Page 4.3 AGSE-E262-G05-LTLS PW1130G-JM/PW1400G-JM Engine Transport Stand Dec 18, 2023 Rev B...
  • Page 18 Periodic inspections of the hydraulic cylinder should be made to ensure that there is sufficient thread engagement between the hydraulic cylinder and the swivel foot. The dimensions should be 3-1/4” +/-1/4” (Illustration Figure 4.5-3). 3-1/4 Figure 4.5-3 Page 4.4 AGSE-E262-G05-LTLS PW1130G-JM/PW1400G-JM Engine Transport Stand Dec 18, 2023 Rev B...

  • Page 19: General Maintenance Schedule

    2* - Carry out function test if equipment has not been used for extended period of time. 3* - AGSE recommends that shock mounts be replaced within five (5) years. 4* - Check that manual is present before every use.

  • Page 20: Replacement Hardware And Repairs

    4.7 Replacement Hardware and Repairs To properly service the hydraulic system: It is important to recognize that all AGSE products are designed, built, tested and Engine OEM Qualified to very exacting AGSE and Engine OEM Standards. This is to protect the product that is being shipped from incurring any visible or non- visible damage during transportation and resulting in it becoming unserviceable.

  • Page 21: Operation

    2) Using a forklift or a hoisting system, raise the transport stand off the floor. 3) Remove the AGSE-E22115-S01 caster lift bar from its storage at the bottom of the base AFT end by removing the AM-90500-32T safety pin. (Illustration Figure 5.1-1).
  • Page 22 (4) locations. Secure the casters with the same hardware. (Illustration Figure 5.1-2). 5) Lower the stand to the floor then set the caster brakes. Page 5.1 AGSE-E262-G05-LTLS PW1130G-JM/PW1400G-JM Engine Transport Stand Dec 18, 2023 Rev B...
  • Page 23 AGSE-E22115-S01 CASTER LIFT BAR SAFETY PIN AM-91000-96T-H900 ENTFERNEN UND CASTER HERUNTER KLAPPEN CASTER MIT DEM GLEICHEN PIN SICHERN AM-91000-96T-H900 Figure 5.1-2 Caster Deployment Page 5.2 AGSE-E262-G05-LTLS PW1130G-JM/PW1400G-JM Engine Transport Stand Dec 18, 2023 Rev B...
  • Page 24 6) Remove eight (8) 5/8” hex head cap screws, eight (8) 5/8” flat washers, eight (8) 5/8” lock washers. (Illustration Figure 5.1-3). 7) Rotate AGSE-E26238-S01 LH front mounting leg and AGSE-E26238-S02 RH mounting leg to the upright position. (Illustration Figure 5.1-3).
  • Page 25 8) Secure with the removed hardware. (Illustration Figure 5.1-4). 9) Remove two (2) AM-90250-64L safety pins to free the AGSE-E26208-P01 AFT braces from their stow position. (Illustration Figure 5.1-4). 10) Rotate AGSE-E26208-P01 AFT braces and hold above storage position. (Illustration Figure 5.1-4).
  • Page 26 11) Remove two (2) AGSE-E25902-P01 safety pins. (Illustration Figure 5.1-5). 12) Rotate the AGSE-E26206-P01 frame weldment to the upright position. (Illustration Figure 5.1-5). NOTE Torsion springs are installed at the base of the frame weldment, to assist raising and lowering. If these torsion springs are removed or damaged, two or more people, an overhead hoist, or a forklift will be required to raise and lower the frame.
  • Page 27 13) Attach the AFT braces to the frame weldment and secure with two (2) AM-91000-34T safety pins. (Illustration Figure 5.1-6). 14) Re-insert two (2) AGSE-E25902-P01 safety pins. (Illustration Figure 5.1-6). RE-INSERT SAFETY PIN AGSE-E25902-P01 USE AM-91000-34T TO PIN AGSE-E26208-P01 AFT BRACE TO...
  • Page 28 15) Remove two (2) AM-91000-64T safety pins to remove AGSE-E26230-P01 RH bootstrap adapter and AGSE-E26230-P02 LH bootstrap adapter. (Illustration Figure 5.1-7). REMOVE AM-91000-64T SAFETY PIN TO REMOVE AGSE-E26230-P01 BOOTSTRAP ADAPTER - RH REMOVE AM-91000-64T SAFETY PIN TO REMOVE AGSE-E26230-P02 BOOTSTRAP ADAPTER - LH...
  • Page 29 16) Rotate AGSE-E26230-P01 RH bootstrap adapter and AGSE-E26230-P02 LH bootstrap adapter 180° clockwise. (Illustration Figure 5.1-8). 17) Re-insert AM-91000-64T safety pin. (Illustration Figure 5.1-8). 18) Before installing the engine into the stand, verify the functional operation of the hydraulic lift system.

  • Page 30: Engine Installation Onto Stand (Engine Not Installed On Aircraft)

    3) Remove the AGSE-E25960-S1 FWD mount adapter (LH) and AGSE-E25960-S2 FWD mount adapter (RH) from the AGSE-E26297-S01 storage box and install on the FWD engine ground handling mounts using eight (8) 5/16” socket head hex cap screws, eight (8) 5/16”...
  • Page 31 9) Secure the FWD adapters to the stand using the AM-90750-64T safety pins. 10) Lower the engine until the engine weight is fully supported by the stand then remove the engine sling. Page 5.10 AGSE-E262-G05-LTLS PW1130G-JM/PW1400G-JM Engine Transport Stand Dec 18, 2023 Rev B...
  • Page 32 INSTALL AM-1928-D10 CAP AM-90500-41T SAFETY PIN INSTALL AM-90750-64T SAFETY PIN INSTALL AM-90750-64T SAFETY PIN Figure 5.2-2 Page 5.11 AGSE-E262-G05-LTLS PW1130G-JM/PW1400G-JM Engine Transport Stand Dec 18, 2023 Rev B...
  • Page 33 FIXED FWD MOUNT - LH ADJUSTABLE FWD MOUNT - RH STELLRING 1.95” REF 1.95” ± .13 FIXED AFT MOUNT - LH ADJUSTABLE AFT MOUNT - RH VIEW AFT LOOKING FWD Figure 5.2-3 Page 5.12 AGSE-E262-G05-LTLS PW1130G-JM/PW1400G-JM Engine Transport Stand Dec 18, 2023 Rev B...

  • Page 34: Preparing The Stand For Bootstrapping (Engine Installed On Aircraft)

    2) Ensure the base and cradle are securely pinned together. 3) Remove eight (8) (4 on each side) AM-91000-90T cradle safety pins to free the cradle from the AGSE-E26219-P01 shipping spacers. (Illustration Figure 5.3-1). NOTE Sequence steps 3 through 7 and 18, spacer removal to lower the cradle, maybe omitted from the procedure if the operator determines sufficient clearance exists between the engine, stand, pylon firex and starter duct.
  • Page 35 Use the hand pump as necessary to aid installing the pins. 7) Store the shipping spacers as shown in Illustration Figure 5.3-2. AGSE-E26219-P01 SPACER IN STORAGE POSITION Figure 5.3-2 Page 5.14 AGSE-E262-G05-LTLS PW1130G-JM/PW1400G-JM Engine Transport Stand Dec 18, 2023 Rev B...
  • Page 36 8) Remove the AGSE-E25960-S1 FWD mount adapter (LH) and AGSE-E25960-S2 FWD mount adapter (RH) from the AGSE-E26297-S01 storage box and install on the FWD engine ground handling mounts using eight (8) 5/16” socket head hex cap screws, eight (8) 5/16”...
  • Page 37 BOOTSTRAP ADAPTER) IRKUT AFT BOOTSTRAPPING IRKUT FWD POINT (WITH AVAILABLE IRKUT BOOTSTRAPPING POINT BOOTSTRAP ADAPTER) IRKUT FWD BOOTSTRAPPING POINT Figure 5.3-4 Irkut Bootstrapping Points with Available AFT Bootstrap Adapter Page 5.16 AGSE-E262-G05-LTLS PW1130G-JM/PW1400G-JM Engine Transport Stand Dec 18, 2023 Rev B...
  • Page 38 20) Reinstall the shipping spacers removed in steps 3 - 7. WAR NING Do NOT tow the stand with engine until the shipping spacers have been reinstalled. Page 5.17 AGSE-E262-G05-LTLS PW1130G-JM/PW1400G-JM Engine Transport Stand Dec 18, 2023 Rev B...

  • Page 39: Stowing The Stand For Transport

    E26207-P02 RH AFT mount adapter from the engine and store in the AGSE-E26297-S01 storage box. 3) If needed, reinstall the AGSE-E26219-P01 shipping spacers, by following steps 4 through 7. 4) Remove eight (8) (4 on each side) AM-91000-90T cradle safety pins to free the cradle from the base.
  • Page 40 THE CRADLE ONTO THE SPACERS. SECURE WITH AM-91000-90T SAFETY PINS AT 8 PLACES REMOVE AM-91000-90T SAFETY PIN (8 PLACES) THEN USE THE HYDRAULIC HAND PUMP TO RAISE THE CRADLE 5-1/2" Figure 5.4-1 Page 5.19 AGSE-E262-G05-LTLS PW1130G-JM/PW1400G-JM Engine Transport Stand Dec 18, 2023 Rev B...

  • Page 41: Forklifting

    5.5.1 Fork Tube Covers The AGSE-E26250-P01 fork tube center cover is designed to prevent the engine from contacting the fork tines. The fork tube center cover is joined by a hinge which allows it to be raised when the fork tine is inserted.
  • Page 42 TINE IS INSERTED AGSE-E26250-P01 TUBE COVER IN UP POSITION WHEN FORK TINE IS INSERTED CRADLE NOT SHOWN FOR CLARITY Figure 5.5-1 Fork Tube Covers and Fork Tube Blockers Page 5.21 AGSE-E262-G05-LTLS PW1130G-JM/PW1400G-JM Engine Transport Stand Dec 18, 2023 Rev B...
  • Page 43 FORK TUBE BLOCKER WHEN CRADLE IS IN LOWER POSITION DEPLOY AGSE-E26288-S01 BLOCKER BEFORE FORKLIFTING A STAND WITH ENGINE (RH OPPOSITE) CRADLE NOT SHOWN FOR CLARITY Figure 5.5-2 Fork Tube Blockers Page 5.22 AGSE-E262-G05-LTLS PW1130G-JM/PW1400G-JM Engine Transport Stand Dec 18, 2023 Rev B...

  • Page 44: Shipping Tie-Down

    LOWERED position. There is not enough sway space below the engine for the shock mounts system to operate. Damage to the engine is likely to occur. Page 5.23 AGSE-E262-G05-LTLS PW1130G-JM/PW1400G-JM Engine Transport Stand Dec 18, 2023 Rev B...
  • Page 45 Figure 5.6-1 Truck Tie-Down (Stand and Casters in Stow Position) - Optional Page 5.24 AGSE-E262-G05-LTLS PW1130G-JM/PW1400G-JM Engine Transport Stand Dec 18, 2023 Rev B...
  • Page 46 Figure 5.6-2 Truck Tie-Down (Casters in Stow Position) Page 5.25 AGSE-E262-G05-LTLS PW1130G-JM/PW1400G-JM Engine Transport Stand Dec 18, 2023 Rev B...

  • Page 47: Component Storage Box

    SPINDLE ASSEMBLY RH AFT MOUNT ADAPTER AGSE-E25960-S02 RH ADJUSTABLE FWD MOUNT ASSEMBLY AGSE-E25948-S04 RH AFT ADJUSTABLE MOUNT SPINDLE ASSEMBLY AGSE-E26207-P01 LH AFT MOUNT ADAPTER Figure 5.7-1 AGSE-E26297-S01 Storage Box Page 5.26 AGSE-E262-G05-LTLS PW1130G-JM/PW1400G-JM Engine Transport Stand Dec 18, 2023 Rev B...

  • Page 48: Safety

    6.4 Risk Assessment 6.4.1 Limits of the Machinery The AGSE-E262-G05-LTLS (PWA211430REVB) Engine Transport Stand is a commercial product designed specifically only to store and/or transport the Pratt & Whitney PWA1130G-JM/PW1400G-JM engines in QEC configuration. The equipment is to be used only by trained mechanics free from physical impairment and who are familiar with this or similar fixture.
  • Page 49 Transport Stand Operation Manual along with instructions. Stencils also have been put on the equipment to identify hazardous and/or potential risk areas. The operation of the AGSE-E262-G05-LTLS Engine Transport Stand can be with medium risk of injury and is considered safe to use under supervision. Low residual risks include potential pinch points during operation of the equipment.
  • Page 50 Engine Transportation Stand, PW 1130G  Model:  AGSE‐E262  Part Number:  AGSE‐E262‐G05‐LTLS (PWA211430)  Serial Number:        Harmonized Standards:   ISO 12100:2010 Safety of Machinery ‐ General Principles for Design ‐ Risk  Assessment and Risk Reduction   ISO/TR 14121‐2:2012 Safety of Machinery ‐ Risk Assessment ‐ Part 2: Practical  Guidance and Examples of Methods    Standards and Specifications:   Pratt & Whitney GSE Specifications No. 3028, FULL ENGINE BOOTSTRAP  TRANSPORT STAND FOR THE PW1130G/PW1400G ENGINE, 2014/09/22 REV A.   AGSE Quality System Procedure Number QSP‐006   Aerospace Recommended Practice Standard, SAE ARP 1840, 2007/02 Rev B      Place:  Santa Fe Springs, California, USA    Date:        Signed:             Quality Representative ...

  • Page 51: Warranty

    AGSE expressly excludes all implied warranties of merchantability and fitness for a particular purpose and all non-infringement warranties as well as disclaims all liabilities to third parties. In no event shall AGSE be liable for any amounts in excess of the purchase price of the product.

  • Page 52: Parts Breakdown

    “ITEM” numbers are for reference to the Illustrated Parts Breakdown (IPB) only. Do not order replacement parts by “ITEM” number. Order parts by “PART NUMBER” only. 8.2 Illustrated Parts Breakdown Page 8.0 AGSE-E262-G05-LTLS PW1130G-JM/PW1400G-JM Engine Transport Stand Dec 18, 2023 Rev B...
  • Page 53 IPB Figure 1 – AGSE-E262-G05-LTLS Engine Transport Stand Assembly ITEM PART NUMBER QTY PART DESCRIPTION AGSE-E262-G05 Engine Transport Stand Assy (Illustration Figure 8.1-2) AGSE-E26201-S02-LTLS 1 Base Assy (See IPB Figure 2 for Details) AGSE-E26219-P01 Spacer AM-91000-90T Safety Pin - 1” Dia. x 5-5/8” Grip...
  • Page 54 Figure 8.1-1 AGSE-E262-G04 Engine Transport Stand Figure 8.1-2 AGSE-E262-G05 Engine Transport Stand Page 8.2 AGSE-E262-G05-LTLS PW1130G-JM/PW1400G-JM Engine Transport Stand Dec 18, 2023 Rev B...

  • Page 55: Base Assembly

    Caster Lift Bar Assy AGSE-E22116-P01 Tow Bar Storage Clamp AGSE-E26261-S01-LTLS 2 Tow Bar Assy (See IPB Figure 11 for Details) AM-2079-2 Shock Absorbing Swivel Caster Assy AGSE-E16911-P01 Caster Steering Bar Page 8.3 AGSE-E262-G05-LTLS PW1130G-JM/PW1400G-JM Engine Transport Stand Dec 18, 2023 Rev B...
  • Page 56 Screw, Socket Head AGSE-S00131-08A17 Washer, Locking AGSE-S00135-08A17 Washer, Locking AGSE-S00104-10C040A01 8 Screw, Hex Head AGSE Screw, Hex Head -S00104-10C044A01 AGSE-S00135-10A17 Washer, Locking AGSE-S00131-10A17 Washer AGSE-S00150-10CA01 AGSE-S00131-1212A17 Washer AGSE-S00153-12CA01 Page 8.4 AGSE-E262-G05-LTLS PW1130G-JM/PW1400G-JM Engine Transport Stand Dec 18, 2023 Rev B...
  • Page 57 Amber Traffic, Reflector AGSE-S00111-P02 Red Traffic, Reflector AGSE-S00135-03A05 Washer, Locking AGSE Screw, Pan head -S00102-04C008A01 AGSE-S00131-03A05 Flat Washer AGSE-E26258-P01-LTLS 1 Hydraulic Divider Cover AGSE-S00118-03F008A05 4 Screw, Socket Head Page 8.5 AGSE-E262-G05-LTLS PW1130G-JM/PW1400G-JM Engine Transport Stand Dec 18, 2023 Rev B...
  • Page 58 (4 PLACES) (4 PLACES) (4 PLACES) (12 PLACES) (4 PLACES) (4 PLACES) (8 PLACES) (2 PLACES) (4 PLACES) (4 PLACES) 9 56 (4 PLACES) Figure 8.2-1 AGSE-E26201-S02-LTLS Base Assembly Page 8.6 AGSE-E262-G05-LTLS PW1130G-JM/PW1400G-JM Engine Transport Stand Dec 18, 2023 Rev B...
  • Page 59 (32 PLACES) (32 PLACES) DETAIL A Figure 8.2-2 AGSE-E26201-S02-LTLS Shock Mount Page 8.7 AGSE-E262-G05-LTLS PW1130G-JM/PW1400G-JM Engine Transport Stand Dec 18, 2023 Rev B...
  • Page 60 Figure 8.2-2 AGSE-E26201-S02-LTLS Base Assembly Page 8.8 AGSE-E262-G05-LTLS PW1130G-JM/PW1400G-JM Engine Transport Stand Dec 18, 2023 Rev B...

  • Page 61: Ipb Figure 3 - Agse-E26202-S03 Cradle Assembly

    Rubber Pad - 1/8” x 3” x 2” AM-90250-64L Safety Pin - 1/4” OD x 4” Grip AGSE-E25902-P01 Safety Pin - 3/8” OD x 5-1/2” Grip - Drilled Collar Page 8.9 AGSE-E262-G05-LTLS PW1130G-JM/PW1400G-JM Engine Transport Stand Dec 18, 2023 Rev B...
  • Page 62 AGSE-S00135-08A17 Washer, Locking AGSE-S00131-08A17 Washer AGSE Screw, Hex Head -S00104-10C040A01 AGSE-S00135-10A03 Washer, Locking AGSE-S00131-10A17 Washer AGSE-S00131-12A17 Washer AGSE Screw, Socket Head -S00118-05F020A07 AGSE-S00135-05A17 Washer, Locking AGSE-S00153-08CA01 Lock Nut Page 8.10 AGSE-E262-G05-LTLS PW1130G-JM/PW1400G-JM Engine Transport Stand Dec 18, 2023 Rev B...
  • Page 63 AGSE-S00135-08A17 Washer, Locking AGSE-S00135-08A05 Flat Washer AGSE-S00135-06A05 Flat Washer AGSE Pan Head Screw -S00355-04C006A05 AGSE-E25960-S01 Fixed FWD Mount Assy AGSE-E25960-S02 Adjustable FWD Mount Assy AGSE-E26297-S01 Storage Box Assy Page 8.11 AGSE-E262-G05-LTLS PW1130G-JM/PW1400G-JM Engine Transport Stand Dec 18, 2023 Rev B...
  • Page 64 59 (2) (2 PLACES) 59 (2) 42 (2) 58 (2) 32 (2) 58 (2) 33 (2) 34 (2) 59 (4) (2 PLACES) (2 PLACES) Figure 8.3-1 AGSE-E26202-S03 Cradle Assembly Page 8.12 AGSE-E262-G05-LTLS PW1130G-JM/PW1400G-JM Engine Transport Stand Dec 18, 2023 Rev B...
  • Page 65 Figure 8.3-2 AGSE-E26202-S03 Cradle Assembly Page 8.13 AGSE-E262-G05-LTLS PW1130G-JM/PW1400G-JM Engine Transport Stand Dec 18, 2023 Rev B...

  • Page 66: Ipb Figure 4 - Agse-E26288-S01 Blocker Assembly

    Clevis Pin - 3/4” Dia. x 2” Lg - Adjustable Grip - SS AGSE-S00204-P17 Ball Lock Pin AGSE Button Head Screw -S00308-04C008A05 S00166-125D016A17 Cotter Pin Figure 8.4-1 AGSE-E26288-S01 Blocker Assembly Page 8.14 AGSE-E262-G05-LTLS PW1130G-JM/PW1400G-JM Engine Transport Stand Dec 18, 2023 Rev B...
  • Page 67 5 (2 PLCS) 7 (2 PLCS) 6 (2 PLCS) 7 (2 PLCS) AGSE-E26238-S01 AGSE-E26238-S02 FRONT MTG LEG, LH FRONT MTG LEG, RH Figure 8.5-1 AGSE-E26238-S01/S02 Front Mounting Leg Assemblies Page 8.15 AGSE-E262-G05-LTLS PW1130G-JM/PW1400G-JM Engine Transport Stand Dec 18, 2023 Rev B...
  • Page 68 Cotter Pin - 3/32” Dia. x 3/4” Grip -S00166-093D012A05 AGSE Roll Pin - 3/8” Dia. x 2” Lg -S00170-380D032A17 (Detail of AGSE-E25948-S03) AGSE Pan Head Screw -S00356-04C006A05 (Detail of AGSE-E25948-S01) AG545 Washer Page 8.16 AGSE-E262-G05-LTLS PW1130G-JM/PW1400G-JM Engine Transport Stand Dec 18, 2023 Rev B...
  • Page 69 (2 PLACES) (2 PLACES) (AGSE-E25948-S03 FIXED AFT MOUNT SPINDLE ASSY - LH) Figure 8.6-1 Fixed AFT Mount Assembly - LH Page 8.17 AGSE-E262-G05-LTLS PW1130G-JM/PW1400G-JM Engine Transport Stand Dec 18, 2023 Rev B...
  • Page 70 AGSE Cotter Pin -S00166-093D012A05 AGSE Slotted Spring Pin -S00170-380D032A17 (Detail of AGSE-E25948-S04) AGSE-S00193-P05 Threaded Collar - 1-1/2”12UNC (Detail of AGSE-E25948-S04) AGSE Screw, Round Head -S00116-04C008A17 (Detail of AGSE-E25948-S02) Page 8.18 AGSE-E262-G05-LTLS PW1130G-JM/PW1400G-JM Engine Transport Stand Dec 18, 2023 Rev B...
  • Page 71 (AGSE-E25948-S04 ADJUSTABLE AFT MOUNT SPINDLE ASSY - RH) Figure 8.7-1 Adjustable AFT Mount Assembly - RH Page 8.19 AGSE-E262-G05-LTLS PW1130G-JM/PW1400G-JM Engine Transport Stand Dec 18, 2023 Rev B...

  • Page 72: Ipb Figure 8 - Agse-E26233-S01 Hydraulic Installation

    A/R Tube Clamp - Cushioned - 3/8” ID AGSE A/R Screw, Socket Head -S00118-04C008A07 AGSE-S00131-04A17 A/R Washer AGSE-S00135-04A17 A/R Washer, Locking AGSE-E26261-P01 Hand Pump 6 FNTX-S Cap - 3/8” Tube Fittings Page 8.20 AGSE-E262-G05-LTLS PW1130G-JM/PW1400G-JM Engine Transport Stand Dec 18, 2023 Rev B...
  • Page 73 Hydraulic Installation (Continued) ITEM PART NUMBER QTY PART DESCRIPTION 6 WETX-S Bulkhead Union - 3/8” NPT x 3/8” NPTF AGSE-S00140-09FA17 3225T26 Tube Clamp - 3/8” ID AGSE-S00325-B27 Hydraulic Hose Assy Page 8.21 AGSE-E262-G05-LTLS PW1130G-JM/PW1400G-JM Engine Transport Stand Dec 18, 2023 Rev B...
  • Page 74 22 (4) 10 (3) 13 (4) 9 (3) BOTH ENDS SECTION A-A AGSE-E26204-P01 BASE WELDMENT REFERENCE Figure 8.8-1 AGSE-E26233-S01 Hydraulic Installation Page 8.22 AGSE-E262-G05-LTLS PW1130G-JM/PW1400G-JM Engine Transport Stand Dec 18, 2023 Rev B...
  • Page 75 FWD Mount Bracket Support AGSE-E25950-P01 Slide Assy AGSE-E25950-P02 Slide Bar AGSE-E25956-P01 Fixed FWD Mount Adapter AGSE-S00104-10C016A01 4 Spiral Retaining Ring AGSE Screw, Hex Head -S00104-10C016A01 AGSE-S00131-10A17 Washer AGSE-S00135-10A03 Washer, Locking Page 8.23 AGSE-E262-G05-LTLS PW1130G-JM/PW1400G-JM Engine Transport Stand Dec 18, 2023 Rev B...
  • Page 76 3 x2 7 x4 6 x4 8 x4 Figure 8.9-1 AGSE-E25960-S1 Fixed FWD Mount Assembly - LH Page 8.24 AGSE-E262-G05-LTLS PW1130G-JM/PW1400G-JM Engine Transport Stand Dec 18, 2023 Rev B...
  • Page 77 AGSE-S00118-06C040A07 2 SHCS - 3/8”-16 UNC x 2-1/2” Lg Alloy Stl - Zinc Plt AGSE-S00135-06A17 Lock Washer - 3/8” - Stl - Zinc Plt AGSE-S00170-04A008A17 1 Slotted Spring Pin Page 8.25 AGSE-E262-G05-LTLS PW1130G-JM/PW1400G-JM Engine Transport Stand Dec 18, 2023 Rev B...
  • Page 78 13 x2 12 x2 2 x2 10 x4 9 x4 8 x4 Figure 8.10-1 AGSE-E25960-S2 Adjustable FWD Mount Assembly (RH) Page 8.26 AGSE-E262-G05-LTLS PW1130G-JM/PW1400G-JM Engine Transport Stand Dec 18, 2023 Rev B...
  • Page 79 A/R Sash Chain, Size 8, SS (Used on AGSE-22117-S02) AGSE-S00212-P01 Cable Ring (Used on AGSE-22117-S02) AGSE Cross-Recessed Pan Head Screw - 1/4”-20UNC x 3/8” -S00102-04C006A05 Lg - SS Page 8.27 AGSE-E262-G05-LTLS PW1130G-JM/PW1400G-JM Engine Transport Stand Dec 18, 2023 Rev B...
  • Page 80 AGSE-E22117-S01 TELESCOPING TOWBAR ASSEMBLY AGSE-E22117-S02 TELESCOPING TOWBAR ASSEMBLY Figure 8.11-1 AGSE-E22117-S01/S02 Telescoping Towbar Assy Page 8.28 AGSE-E262-G05-LTLS PW1130G-JM/PW1400G-JM Engine Transport Stand Dec 18, 2023 Rev B...

  • Page 81: Stencils, Decals And Placards

    These items should be reviewed and understood by maintenance and user personnel. 9.2 Stencils and Placards ITEM PART NUMBER QTY PART DESCRIPTION AGSE Stencil Kit Package - E262-G05-LTLS -E26263-S01-LTLS Page 9.0 AGSE-E262-G05-LTLS PW1130G-JM/PW1400G-JM Engine Transport Stand Dec 18, 2023 Rev B...
  • Page 82 AMERICAN 5,625 KG" (1/2") FLAG (1/2") DECAL "SPACER STOW" (1/2") 2 PLCS "C G ENGINE & CRADLE 9,600 LB 4,355 KG" (1/2") -G04/-G05 ONLY “PWA211430B” (2”) Figure 9.2-1 Page 9.1 AGSE-E262-G05-LTLS PW1130G-JM/PW1400G-JM Engine Transport Stand Dec 18, 2023 Rev B...
  • Page 83 180° FOR STORAGE" (1/2") 2 PLCS ROTATE 180° FOR STORAGE "REAR BOOTHSTRAP MOUNT" (1/2") 2 PLCS REAR BOOTHSTRAP MOUNT AGSE-E26230-P02 (1") DETAIL E SCALE: 1 / 4 Figure 9.2-2 Page 9.2 AGSE-E262-G05-LTLS PW1130G-JM/PW1400G-JM Engine Transport Stand Dec 18, 2023 Rev B...

  • Page 84: Recommended Spares

    10.0 – Recommended Spares 10.1 Critical Items AGSE defines “critical” items as those items, if broken or missing, that would render the equipment inoperable or severely impair equipment operation. Since most of these items are also long leads, it is AGSE’s recommendation that such items be identified, purchased, and stocked by the customer.
