- Page 1 EN User Manual | Steam oven EB4GL70KCN EB4GL70KSP...
-
Page 2: Table Of Contents
Welcome to Electrolux! Thank you for choosing our appliance. Get usage advice, brochures, trouble shooter, service and repair information: www.electrolux.com/support Subject to change without notice. CONTENTS 1. SAFETY INFORMATION................2 2. SAFETY INSTRUCTIONS................4 3. PRODUCT DESCRIPTION................7 4. CONTROL PANEL..................7 5. -
Page 3: General Safety
be kept away from the appliance unless continuously supervised. • Children should be supervised to ensure that they do not play with the appliance. • Keep all packaging away from children and dispose of it appropriately. • WARNING: The appliance and its accessible parts become hot during use. -
Page 4: Safety Instructions
• Always use oven gloves to remove or insert accessories or ovenware. • Use only the food sensor (core temperature sensor) recommended for this appliance. • To remove the shelf supports first pull the front of the shelf support and then the rear end away from the side walls. Install the shelf supports in the opposite sequence. - Page 5 • Make sure that the parameters on the • Be careful when you open the appliance rating plate are compatible with the door while the appliance is in operation. electrical ratings of the mains power Hot air can release. supply. •...
-
Page 6: Steam Cooking
2.4 Care and cleaning • Concerning the lamp(s) inside this product and spare part lamps sold separately: These lamps are intended to withstand WARNING! extreme physical conditions in household Risk of injury, fire, or damage to the appliances, such as temperature, appliance. -
Page 7: Product Description
3. PRODUCT DESCRIPTION 3.1 General overview Descaling pipe outlet Shelf support, removable Shelf positions 3.2 Accessories • Wireshelf For cake tins, ovenproof dishes, roast dishes, cookware / dishes. • Baking tray For moist cakes, baked items, bread, large roasts, frozen meals and to catch dripping liquids, e.g. - Page 8 Sensor Function Comment field Heating Functions or Press the sensor field once to choose a heating function or the Assisted Cooking menu: Assisted Cooking. Press the sensor field again to switch between the menus: Heating Functions, Assisted Cooking. To turn on or turn off the light, press the field for 3 seconds. You can turn on the light also when the oven is off.
-
Page 9: Before First Use
Weight Automatic Heat + Hold The display shows that the automatic The function is on. weight system is on or that weight can be changed. 5. BEFORE FIRST USE Use the test paper supplied with the steam WARNING! set. Refer to Safety chapters. 1. -
Page 10: Daily Use
Water hardness Test paper Calcium depos‐ Calcium de‐ Water classifi‐ it (mmol/l) posit (mg/l) cation Level (dH) 0 - 7 0 - 1.3 0 - 50 soft 8 - 14 1.4 - 2.5 51 - 100 moderately hard 15 - 21 2.6 - 3.8 101 - 150 hard... -
Page 11: Heat-Up Indicator
8. Empty the water drawer after the cooking is completed. Symbol / Menu Application Refer to the cleaning function: Tank item Emptying. Contains a list of cleaning CAUTION! programmes. Cleaning The oven is hot. There is a risk of Used to set the appliance burns. -
Page 12: Submenu For: Cleaning
Symbol / Menu Description Symbol / Menu Description item item Adjusts the volume of press- Reminds you when to clean tones and signals by de‐ the appliance. Buzzer Volume Cleaning Reminder grees. Activation / deactivation Activates and deactivates the code: 2468. tone of the touch fields. - Page 13 Heating function Application Heating function Application To roast large meat joints or To preserve vegetables and poultry with bones on one fruits, place canning jars in a shelf position. To bake gratins baking tray filled with water, Turbo Grilling Preserving and to brown.
-
Page 14: Assisted Cooking
The oven door should be closed during cooking so that the function is not interrupted Dish and the oven operates with the highest Chicken wings, fresh energy efficiency possible. Chicken wings, frozen When you use this function the lamp automatically turns off after 30 sec. Chicken legs, fresh For the cooking instructions refer to "Hints Chicken legs, frozen... - Page 15 Dish Dish Chipolatas Lasagne / Cannelloni, fro‐ Spare ribs Pasta Pork knuckle, pre-cooked Potato gratin Pork joint Vegetables au gratin Loin of pork Sweet dishes Loin of pork Food Category: Pizza / Quiche Pork Loin of pork, smoked Dish Loin of pork, poached Pizza, thin Pork neck Pizza, extra topping...
- Page 16 Dish Dish Pastry strips Bread crown Cream puffs White bread Puff pastry Yeast plait Eclairs Brown bread Bread Macaroons Rye bread Short pastry biscuits Wholegrain bread Christmas stollen Unleavened bread Apple strudel, frozen Bread/Rolls, frozen Sponge dough Food Category: Vegetables Cake on tray Yeast dough Dish...
-
Page 17: Clock Functions
Dish Dish White haricot beans Croquettes Savoy cabbage Wedges Hash browns Food Category: Custards / Terrines Boiled potatoes, quar‐ Dish tered Egg custard Boiled potatoes Flan caramel Potatoes in their jacket Terrine Potato dumplings Eggs, soft boiled Bread dumplings Eggs, medium boiled Yeast dumplings, salty Eggs Eggs, hard boiled... -
Page 18: Time Extension
When the time ends, the signal sounds. The 5. Press to confirm. oven turns off. Press any sensor field to stop When the function ends, a signal sounds. the signal. 7.4 Time Extension 7.3 Heat + Hold The function: Time Extension makes the Conditions for the function: heating function continue after the end of Duration. -
Page 19: Food Sensor
Insert the shelf between the guide bars of the 2. Insert the tip of the food sensor into the shelf support and make sure that the feet centre of meat or fish, in the thickest part point down. if possible. Make sure that at least 3/4 of the food sensor is inside of the dish. -
Page 20: Additional Functions
food sensor. The tip of the food sensor The display shows the food sensor symbol. should not touch the bottom of a baking 6. Press in less than 5 seconds to dish. set the food core temperature. 7. Set a heating function and, if necessary, the oven temperature. -
Page 21: Using The Child Lock
Function Lock is on during the heating Activating the programme function works. 1. Turn on the oven. When the heating function ends, a signal 2. Select the menu: Favourite Programme. sounds. 3. Press to confirm. 10.5 Automatic switch-off 4. Select your favourite programme name. 5. -
Page 22: Hints And Tips
11. HINTS AND TIPS The function allows you to warm plates and dishes before serving. The temperature is set automatically to 70 °C. Refer to Safety chapters. Place plates and dishes in stacks evenly on 11.1 Cooking recommendations the wire shelf. Use the first shelf position. After half of the warming time switch their The temperature and cooking times in the places. -
Page 23: Information For Test Institutes
Rice pudding 180 - 200 55 - 70 White bread 200 - 210 55 - 70 Apple cake, made 160 - 170 70 - 80 of sponge cake mixture (round cake tin) 11.5 Information for test institutes Tests according to EN 60350 and IEC 60350. Use the function: Full Steam. -
Page 24: Steam Cleaning
3. Pull the front end of the shelf support Use the function: Steam Cleaning Plus. away from the side wall. You can enable and disable the reminder in 4. Pull the supports out of the rear catch. the menu: Basic Settings . 12.5 Descaling Use it to descale the steam system. -
Page 25: Tank Emptying
These reminders activate each time you turn 1. Fully open the door. off the appliance. 2. Press the clamping levers on the two door hinges. 12.7 Rinsing Use it to clean the steam system after frequent use of the steam functions. 1. -
Page 26: Troubleshooting
2. Remove the metal ring and clean the glass cover. 3. Replace the lamp with a halogen, 230 V, 40 W, 300 °C heat-resistant lamp 4. Attach the metal ring to the glass cover and install it. 13. TROUBLESHOOTING WARNING! Refer to Safety chapters. -
Page 27: Service Data
Problem Possible cause Remedy The appliance is activated and does The demo mode is activated. Refer to "Daily Use chapter, Basic not heat up. The fan does not oper‐ Settings. ate. The display shows "Demo". The descaling procedure is interrup‐ There was a power cut. -
Page 28: Energy Efficiency
14. ENERGY EFFICIENCY 14.1 Product Information Sheet and Product Information according to EU Energy Labelling and Ecodesign Regulations Supplier's name Electrolux EB4GL70KCN 944066504 Model identification EB4GL70KSP 944066505 Energy Efficiency Index 80.8 Energy efficiency class Energy consumption with a standard load, conventional mode 0.89 kWh/cycle... -
Page 29: Guarantee
When you turn off the appliance, the display Cooking with the lamp off shows the residual heat. Turn off the lamp during cooking. Turn it on only when you need it. If a programme with Duration / End Time is activated and the cooking time is longer than Moist Fan Baking 30 min, the heating elements automatically... - Page 30 For Switzerland: Where should you take your old equipment? Anywhere that sells new equipment or hand it in to official SENS collection points or official SENS recycling firms. The list of official SENS collection points can be found at www.erecycling.ch ENGLISH...
- Page 32 867343775-G-102024...
