  • Page 1 ThinkSystem 4450 Series Adapters Installation and User Guide...
  • Page 2 Before using this information and the product it supports, be sure to read and understand the safety information and the safety instructions, which are available at: https://pubs.lenovo.com/safety_documentation/ In addition, be sure that you are familiar with the terms and conditions of the Lenovo warranty for your server, which can be found at: http://datacentersupport.lenovo.com/warrantylookup First Edition (February 2025) ©...
  • Page 3: Table Of Contents

    Chapter 1. About this guide ........................... 5 Before you begin ..............................5 Terms ...................................5 Chapter 2. Adapter characteristics ......................6 About ThinkSystem 4450 Series host bus adapter ....................6 Standard features ............................6 Mechanical information ..........................6 About the ThinkSystem 4450-16i SAS/SATA PCIe Gen4 24Gb HBA ..............8 Chapter 3.
  • Page 4: Safety

    Put the adapter down only on an antistatic surface such as the bag supplied in your kit. • If you are returning the adapter to Lenovo Product Support, put it back in its antistatic bag immediately. If a wrist strap is not available, ground yourself by touching the metal chassis before handling the adapter...
  • Page 5: Chapter 1. About This Guide

    Chapter 1. About this guide This Installation and User Guide explains how to install and set up your ThinkSystem 4450 Series host bus adapter, including driver installation, BIOS operations, troubleshooting tips, and instructions for flashing the adapter firmware. These ThinkSystem 4450 Series adapter models are described in this guide:...
  • Page 6: Chapter 2. Adapter Characteristics

    Chapter 2. Adapter characteristics About ThinkSystem 4450 Series host bus adapter This chapter provides an overview of the features of the ThinkSystem 4450 Series adapters. Standard features • Low-profile, MD2 form factor on all boards with up to 16-ports •...
  • Page 7 LED states are described in the following tables. For LED locations, see the board images in Figure 1 “ThinkSystem 4450-16i adapters”. Table 2. ThinkSystem 4450 Series status LEDs Color Meaning HEARTBEAT (DS5) Green Heartbeat (blinks once per/second when firmware operating normally)
  • Page 8: About The Thinksystem 4450-16I Sas/Sata Pcie Gen4 24Gb Hba

    About the ThinkSystem 4450-16i SAS/SATA PCIe Gen4 24Gb HBA The ThinkSystem 4450-16i SAS/SATA PCIe Gen4 24Gb HBA is a SAS/SATA host bus adapter with these features: Figure 1. ThinkSystem 4450-16i adapters ① Side Band Recovery ② UART ③ Alarm Connector ④...
  • Page 9 Form Factor Half height; half length Bus compatibility PCIe 4.0 PCIe bus width ThinkSystem 4450-16i: x8 Data transfer rate (SAS) 24 Gb/s per port PHYs (Unified Serial Ports) Standard memory 32 MB SPI Flash Connectors, internal 2x SlimSAS x8 Maximum number of disk drives 238 (SAS/SATA) with expanders Enclosure Support UBM, VPP, SGPIO...
  • Page 10: Chapter 3. Hardware Installation

    Chapter 3. Hardware installation Installing the controller and disk drives This chapter explains how to install your ThinkSystem 4450 Series adapter in a computer cabinet or server and connect it to internal and external disk drives. Before you begin • Read Safety.
  • Page 11 3. Insert the adapter into the expansion slot and press down gently but firmly until it clicks into place. When installed properly, the adapter should appear level with the expansion slot. CAUTION: Be sure to handle the adapter by its bracket or edges only. Apply pressure only on the edges when inserting the card into expansion slot.
  • Page 12 6. Close your computer cabinet, reconnect the power cord and network cables, then power up the system.
  • Page 13: Chapter 4. Managing Sed

    Chapter 4. Managing SED Overview Introduction A Self-Encrypting Drive (SED) encrypts data through disk-based encryption with a Media Encryption Key (MEK). The MEK is known only to the SED and cannot be recovered through forensic analysis. Smart controllers enable the use of SEDs as logical drives or physical drives. The controller is responsible for managing and delivering the credentials required by the SED for enabling the disk-based encryption.
  • Page 14 Logical and physical drives Adapters support using SEDs for logical and physical drives with the disk-based encryption feature enabled. Encryption-enabled drives are referred to as secured drives. The controller delivers the credentials to the SEDs and unlocks them. SEDs can also be used for logical and physical drives without the disk-based encryption feature turned on (like a non-SED device) and is referred to as non-secured drives.
  • Page 15: Workflows

    Importing a foreign secured SED A foreign SED is defined as a secured physical or logical drive that was previously attached to a controller with credentials different from those stored in the current controller. The controller can detect that the drive was moved from a different controller and can import the drive to the new controller when the original credentials are entered.
  • Page 16 1. Connect the supported SED to the controller. 2. Refer to system vendor documentation to establish connection between system and remote key management server. ™ 3. Enable SED management from HII, ARCCONF, or maxView . Choose the key management mode as remote. Master key generated by the key management server will be used for encryption.
  • Page 17 the subsequent reboot if controller detects that the key management server is unavailable, then an unlock option will be provided in the UEFI HII menu. Controller can only unlock encrypted devices if the key management server is made available or by entering a valid controller password.
  • Page 18 2. From the main menu, select Configure Controller Settings > Self-Encryption Drive (SED) Based Encryption Setup. 3. Select Unlock Controller. 4. Enter controller password, then select Submit. Note: In local key management mode, it is recommended to supply the password, before performing any operations such as removing or adding the drives.
  • Page 19: Troubleshooting

    Importing foreign SED Use the following steps to import foreign SEDs: 1. Boot to system BIOS setup utility and select controller to enter HII configuration utility. 2. From the main menu, select Configure Controller Settings > Self-Encryption Drive (SED) Based Encryption Setup.
  • Page 20 and new Master Keys. The management tools support retrieving both the Key Identifier and the Reset Key Identifier from the foreign SED. After both the old and new foreign keys are provided, the controller completes the key change that was in progress prior to the move and then execute the additional key change to import the foreign SEDs.
  • Page 21: Chapter 5. Solving Problems

    This chapter provides basic troubleshooting information and solutions for solving problems with your ThinkSystem 4450 Series host bus adapter. Troubleshooting checklist If you encounter difficulties installing or using your ThinkSystem 4450 Series Host Bus Adapter, check these items first: •...
  • Page 22: Appendix A. Technical Specifications

    Appendix A. Technical specifications Environmental specifications Note: ThinkSystem 4450 Series adapters require adequate airflow to operate reliably. Forced airflow is required. See the Recommended airflow table below for more information. Ambient temperature with forced airflow 0 °C to 55 ° C...
  • Page 23: Appendix B. Getting Help And Technical Assistance

    Gathering information needed to call Support If you require warranty service for your Lenovo product, the service technicians will be able to assist you more efficiently if you prepare the appropriate information before you call. You can also go to http:// datacentersupport.lenovo.com/warrantylookup...
  • Page 24: Contacting Support

    Electronic Service Request. Submitting an Electronic Service Request will start the process of determining a solution to your problem by making the pertinent information available to the service technicians. The Lenovo service technicians can start working on your solution as soon as you have completed and submitted an Electronic Service Request.
  • Page 25: Appendix C. Notices

    Web sites. The materials at those Web sites are not part of the materials for this Lenovo product, and use of those Web sites is at your own risk. Any performance data contained herein was determined in a controlled environment. Therefore, the result obtained in other operating environments may vary significantly.
  • Page 26: Telecommunication Regulatory Statement

    This product may not be certified in your country for connection by any means whatsoever to interfaces of public telecommunications networks. Further certification may be required by law prior to making any such connection. Contact a Lenovo representative or reseller for any questions. Electronic emission notices When you attach a monitor to the equipment, you must use the designated monitor cable and any interference suppression devices that are supplied with the monitor.
  • Page 27: Taiwan Import And Export Contact Information

    Contacts are available for Taiwan import and export information. Trademarks LENOVO and THINKSYSTEM are trademarks of Lenovo. Microsoft and Windows are trademarks of the Microsoft group of companies. All other trademarks are the property of their respective owners. © 2021...
