- Page 1 V150 SG2E / V190 SG2E Instructions for use...
-
Page 2: Warning
Warning. In case this appliance contains hydrocar- WARNING: This appliance is not intended bon refrigerant please refer to guidelines for use by young children or listed below. infirm persons unless they have been adequately supervised by As the appliance contains a flammable a responsible person to ensure refrigerant, it is essential to ensure that the that they can use the appliance... -
Page 3: Get To Know Your Wine Cooler
Get to know your wine cooler Lighting Charcoal filter Wooden shelf Sealing strip Nameplate Door handle Kick plate Control panel Lock Adjustable feet fig.1... -
Page 4: Table Of Contents
Contents Installation and start-up. Placement. Warning ..........2 For safety and operational reasons, the ap- Get to know your wine cooler....3 pliance must not be installed outdoors. Before use..........4 The appliance should be placed on a level Installation and start-up ......4 surface in a dry, well ventilated room (max. - Page 5 fig. 3 fig. 2 The appliance viewed from above. If the app.liance is placed beside a wall, there must be sufficient room for its door to be opened wide enough to allow the shel- ves to be pulled out (fig. 4). 1075 fig. 4...
- Page 6 Ventilation. It is important that the appliance be well ventilated and that air can circulate unhin- dered above, below and around it. The figures below illustrate how the neces- sary air circulation around the appliance can be ensured (figs 5-6). fig.
-
Page 7: Technical Data
Setting up. It is important that the appliance be absolu- tely level. It can be levelled by screwing the adjustable feet at the front of the appliance up or down (figs 8-9). Use a spirit level to check that the appliance is absolutely level sideways. -
Page 8: Reversible Door
4. You will need to remove the magnet on the underside of the door by depressing the clips in pulling the magnet away from the door. Also with a small Philips head screwdriver remove the Vintec logo badge and swap the magnet where the badge was and vice versa. - Page 9 8. When the lock pin has been 9. Click the covers into place 10. Fit the door onto the bottom loosened completely, pull on the plinth sides on the op- pin, fit the top hinge and it up together with the lock posite side.
-
Page 10: Operation And Function
Operation and function. fig. 9 Electronic control a built-in filter which simulates the actual temperature in the bottles. Consequently, The electronic control ensures that the the indicator does not react on short-term temperatures set at the top and at the bot- fluctuations of the air temperature tom of the appliance are maintained. -
Page 11: Alarm Devices
Temperature setting at the bot- displayed when the light is lit. tom of the appliance To turn off the lights, press once Push SET2. Then the temperature at the Permanent lighting bottom of the appliance can be adjusted up For presentation purposes of your wine, and down by means of the “up and down” you can turn the lights permanently. -
Page 12: Defrosting, Cleaning And Maintenance
Defrosting, cleaning and maintenance. Automatic defrosting. cabinet through its door and sides, creating a slight temperature gradient from top to The wine cooler is defrosted automatically. bottom. The controls will maintain the set Defrost water runs through a pipe and is temperature at the bottom of the cabinet, collected in a tray above the compressor and any deviation from the setting will where the heat generated by the compres-... -
Page 13: Fault Finding
Fault finding. Fault Possible cause Remedy The appliance is not The appliance is switched off. Press the on/off switch. working. Power failure; the fuse is blown; Check that power is connected. the appliance is not plugged in Reset the fuse. correctly. Water collects in The defrost water pipe is Clean the defrost water channel the bottom of the... -
Page 14: Warranty, Spare Parts And Service
Warranty, spare parts and service. Warranty disclaimer Spare parts Faults and damage caused directly or When ordering spare parts, please state indirectly by incorrect operation, misuse, the type, serial and product numbers of insufficient maintenance, incorrect building, your appliance.This information is given on installation or mains connection. Fire, ac- the rating plate. -
Page 15: Disposal
Disposal Information for Users on Collection For business users in the Euro- and Disposal of Old Equipment and pean Union. used Batteries If you wish to discard electrical and electronic equipment, please contact These symbols on the products, your dealer or supplier for further packaging, and/or accompanying information. - Page 16 Reserving the right to alter specifications without prior notice. 0-9193127-02...
