ENGLISH
Thank you for choosing Savio product!
If our product meets your expectations, share your opinion with
other people on the portal ceneo.pl, social media or on the web-
site of the store where you made the purchase. If you want to
show our device on SAVIO Facebook Page, we will be very pleased.
If there is something that we could improve on our products, please
write to us at support@savio.pl
Thanks to your feedback, we will be able to better adapt the product
to your expectations.
Before starting the use of purchased device it is recommended
to read the whole manual.
1. Keyboard's main features:
• OUTEMU Red / Brown / Blue (depending on a model).
• RGB backlight with 18 modes to choose from.
• Switch lifespan: 50 000 000 keystrokes.
• Keys are made with 'double injection' technology. It prevents wearing
off the keys while using.
• N-key rollover & Anti-ghosting – a feature enabling pressing many
keys at the same time.
• Functional balance and rubberized keyboard feet preventing unnec-
essary movement while using.
• Dedicated software allows full backlighting configuration and cre-
ating macros.
2. Package contents:
• Mechanical keyboard
• User manual
3. Technical specification:
• Keyboard type: Mechanical
• Keyboard layout: US (87 keys)
• Interface: USB
• Keycaps: ABS
• Switches: OUTEMU Red / Brown / Blue (depending on the model)
• Switch lifespan: 50 000 000 keystrokes
• Keyboard dimensions: 355 × 127 × 33 mm
• Keyboard weight: 560 ± 20 g
• Software: Yes
• N-key rollover & Anti-ghosting: Full
• Macro support: Yes
• Cable length: 1.5 m
• Compatibility: Windows XP, Vista, Win 7 / 8 / 10 / 11, Linux, macOS, Android
• Package content: Mechanical keyboard, manual
4. Device installation:
4.1 Connect the keyboard to USB-A port in your computer.
4.2 Operating system will automatically detect the keyboard and install
drivers.
4.3 The keyboard is ready to use.
5. Software installation:
To get full configuration access you have to download and install ded-
icated software from our website: www.savio.pl/download. After the
download, double click on the icon and follow the installation steps. After
the successful installation, you will see the software icon on the desktop.
Double click on the icon to open the settings interface.
6. Multimedia activation key shortcuts:
+
Music
Decrease volume
+
Increase volume
+
Mute
+
Stop
+
Previous track
+
7. Backlight mode:
7.1 The keyboard features 18 backlight modes. To activate the backlight
you need to press
.
7.2 Each time you press FN +
functionality works with some modes).
7.3 The keyboard also features changing the backlight intensity. Press
FN + Arrow Up / Down to increase / decrease light intensity. Press
FN + Arrow Left / Right to decrease / increase effects speed.
Change
backlight mode
(18 modes)
+
Change back-
light color
Increase back-
+
light intensity
7.4 To turn of the backlight, press FN + Arrow Down combination 4 times
(counting from maximum brightness level).
Mechanical keyboard
model: TEMPEST X2
User manual
Play / Pause
+
Next track
+
E-mail
+
Internet browser
+
Lock keyboard
+
Calculator
+
the backlight color will change (this
Decrease back-
+
light intensity
Decrease
+
effect speed
Increase
effect speed
+
+
7.5 To turn on the backlight, press FN + Arrow Up combination 4 times
(counting from no backlight).
8. Blocking the Windows key:
To block the Windows key, press FN + Windows. When the Windows key
lights up, it means that the key is blocked. To unblock the Windows key,
press FN + Windows once again. The Windows key will no longer light up.
9. Setting the user mode:
User mode enables the user to set the backlight for chosen keys.
9.1 Press FN + ~ twice to enter the lighting customization mode.
9.2 Choose and press keys that
of key change the color that will be displayed for individual key.
9.3 Press FN + ~ again to save the customized lighting combination and
exit the customizaition.
9.4 To enter the saved user mode settings while using another backlight
mode, press FN + ~.
10. Changing WASD to arrows:
The keyboard enables changing the functionality of WASD keys to arrows.
To activate this mode, press FN + W. To go back to default settings, press
the same key combination.
11. Keyboard default settings:
To restart the keyboard, press FN + Esc for 5 seconds.
12. Safety conditions:
• Use the product in accordance with its intended use, as improper
use may damage the product.
• Do not expose the device to moisture, heat or sunlight, do not use
the product in a dusty environment.
• The device should be cleaned only with a dry cloth.
• Independent repairs and modification result automatic loss of the
warranty.
• Hitting or dropping may damage the product.
POLSKI
Dziękujemy za zakup produktu marki Savio!
Jeśli nasz produkt spełnił Twoje oczekiwania, podziel się swoją opi-
nią z innymi osobami na portalu ceneo.pl, w mediach społeczno-
ściowych lub na stronie sklepu, w którym dokonałeś zakupu. Będzie
nam niezmiernie miło, jeśli zechcesz również pochwalić się naszym
urządzeniem na profilu SAVIO na Facebooku.
Jeśli jest coś, co moglibyśmy poprawić w naszych produktach, na-
pisz nam o tym na adres: support@savio.pl
Dzięki Twojej opinii będziemy mogli jeszcze lepiej dopasować produkt
do Twoich oczekiwań.
Przed przystąpieniem do korzystania z zakupionego urządzenia zaleca
się przeczytanie całej instrukcji obsługi.
1. Główne cechy klawiatury:
• Przełączniki OUTEMU Red / Brown / Blue (w zależności od modelu).
• Pełne podświetlenie RGB klawiszy wraz z możliwością wyboru 18 try-
bów podświetlenia.
• Żywotność klawiszy: 50 000 000 naciśnięć.
• Klawisze wykonane są w technologii „double injection" zapobiegającej
ścieraniu się klawiszy podczas użytkowania.
• N-key rollover & Anti-ghosting – funkcja umożliwiająca wciśnięcie
wielu klawiszy jednocześnie.
• Odpowiednie wyważenie oraz gumowe stopki zapobiegające prze-
mieszczaniu się klawiatury podczas użytkowania.
• Dedykowane oprogramowanie umożliwia pełną konfigurację pod-
świetlenia klawiatury oraz tworzenie makr.
2. Zawartość opakowania:
• Klawiatura mechaniczna
• Instrukcja obsługi
3. Specyfikacja techniczna:
• Typ klawiatury: Mechaniczna
• Układ klawiatury: US (87 klawiszy)
• Interfejs: USB
• Keycapy: ABS
• Przełączniki: OUTEMU Red / Brown / Blue (w zależności od modelu)
• Żywotność przełączników: 50 000 000 kliknięć
• Wymiary klawiatury: 355 × 127 × 33 mm
• Waga klawiatury: 560 ± 20 g
• Oprogramowanie: Tak
• N-key rollover & Anti-ghosting: Pełny
• Obsługa makr: Tak
• Długość kabla USB: 1.5 m
• Kompatybilność: Windows XP, Vista, Win 7 / 8 / 10 / 11, Linux, macOS,
Android
• Zawartość zestawu: Klawitura mechaniczna, instrukcja obsługi
1
+
+
+
should be backlit. Each press
+
+
+
+
Klawiatura mechaniczna
model: TEMPEST X2
Instrukcja obsługi
