Savio KW-04 User Manual

ENGLISH
Thank you for choosing Savio product!
If our product meets your expectations, share your opinion with other people
on the portal ceneo.pl, social media or on the website of the store where you
made the purchase. If you want to show our device on SAVIO Facebook Page,
we will be very pleased.
If there is something that we could improve on our products, please write to us
at support@savio.pl
Thanks to your feedback, we will be able to better adapt the product to your expec-
tations.
Before starting the use of purchased device it is recommended to read the
whole manual.
1. Package content:
• Mini wireless keyboard
• 2.4 GHz receiver
• USB-A - USB-C cable
• Li-ion battery
• User manual
2. Basic information:
SAVIO KW-04 BT + 2.4 GHz wireless keyboard is a multifunctional, compact de-
vice that combines the features of a full-size QWERTY keyboard and a touch
panel (touchpad). Thanks to the KW-04 keyboard, you can browse the Internet
websites or use installed applications in a quick and easy way.
3. Device compatible with:
• PC computer / Laptop
• Windows / Linux
• Smart TV / Android TV
• TV BOX
• Xbox / PlayStation*
• Projector with Android
• Smartphone / Tablet (OTG)**
* When using the keyboard with a console, certain features such as the touch-
pad or connection type may be limited.
** Smartphones and tablets need to have an OTG function (connection by USB
OTG cable).
4. Indicator diodes description:
• LED (Blue light): indicates the operating or battery status. If it lights up
continuously, it means that the device is in working mode. If the blue light is
off, it means that the keyboard has gone into auto sleep mode, if it flashes
slowly, it means that the keypad needs to be recharged.
• LED (Red light): indicates the charging status. After connecting the
charging cable, the red light will turn on.
• LED (Orange light): indicates the connection status of the device. It
flashes rapidly when connecting to a 2.4 GHz receiver or Bluetooth. When
correctly connected, it flashes with every command sent from the key-
board (key press or touchpad).
5. Touchpad use:
The integrated touchpad enables to browse the Internet websites and use of
the installed application same way, as with a traditional computer mouse.
• Single touch of touchpad replaces the click of the left mouse button.
• Double click of the touchpad replaces the right mouse click.
• To use the scroll function, you need to use two fingers, one should be held
still on the touchpad and the other will move up and down.
Single finger click
Left mouse button
6. Connecting the device:
6.1 Connection with 2.4 GHz receiver:
6.1.1 Connect the 2.4 GHz receiver to the USB port on your computer. The
2.4 GHz receiver is located under the battery cover on the back of the
keyboard.
6.1.2 Turn the keyboard on by moving the switch located on the back cov-
er of the keyboard to the ON position.
6.1.3 The device pairs automatically.
6.1.4 When device is in the Bluetooth mode use combination Fn + 2.4G to
switch to 2.4 GHz mode.
6.2 Connection with Bluetooth:
6.2.1 Turn the keyboard on by moving the switch to the ON position. The
switch is located on the back cover of the keyboard.
6.2.2 To pair your device to the keyboard via Bluetooth for the first time,
press and hold Fn + BT for 3 seconds. The orange LED will start flashing
indicating that the device is ready for pairing.
6.2.3 Turn on the Bluetooth on your device (e.g. computer), choose SAVIO
KW-04 keyboard from Bluetooth devices on the list and click to pair.
6.2.4 When device is working in 2.4 GHz mode, use combination Fn + BT to
switch to Bluetooth.
Note: Nowadays most wireless devices operate at 2.4 GHz. Therefore, it is
sometimes necessary to bring the keyboard close to the USB receiver for a
correct connection.
7. Auto sleep mode and wake up:
• Keyboard has the functions of automatic sleep mode and wake up.
• Keyboard automatically switches into the sleep mode within 3 minutes
when idle. Pressing any button will cause the keyboard to wake up instantly.
8. Technical specification of the keyboard:
• Bluetooth version: 5.2
• Range: up to 10 meters
• Battery capacity: 300 mAh, 3.7 V
• Power consumption: 8-15 mA, <15 mA in sleep mode
• Frequency bands in which the radio equipment operates: 2400 – 2483.5 MHz
• Maximum radio-frequency power transmitted in the frequency band in
Wireless keyboard
model: KW-04
User manual
One finger drag Two fingers click
Scroll up and down Right mouse button
(the mouse wheel)
which the radio equipment operates: 5 dBm
• Dimensions: 146 × 96 × 15 mm
• Weight: 115 g
• Number of keys: 82
9. Button programming:
The KW-04 keyboard supports up to six programmable keys that can be pro-
grammed to reproduce to the TV remote control buttons, including: power, TV
and four colored buttons on the keyboard (red, green, yellow and blue).
9.1 Press and hold the appropriate button to be programmed until the indi-
cator light is constantly on.
9.2 Release the programmable button, the indicator light will flash. The next
step will be to program the appropriate button on the TV remote control.
9.3 Bring the TV remote control close to the KW-04 infrared transmitter,
making sure that the distance between them is less than 5 centimeters.
Then press the corresponding button on the TV remote control, indicator
light flashes quickly:
grammed. If necessary, repeat the steps from the beginning.
9.4 Repeat the above steps to program the remaining buttons.
10. Reseting programmed buttons:
Press and hold Fn + for a few seconds until the light:
to restore factory settings.
Note: Please remember that the programmed buttons must correspond ex-
actly to the buttons on the TV remote control.
11. Diagram of key combinations:
Fn
Fn
+
+
Prtsc
Win
Sensor Print
sensitivity screen
settings
12. The backlight colour setting of the keyboard:
12.1 Press Fn + , to activate the keyboard backlight.
12.2 Press Fn + , to get to the backlight colour setting.
12.3 Confirm the backlight color by selecting the appropriate option. The
highlight color has now been saved. If you turn off the device, the key-
board will return to the basic backlight version.
13. Charging the keyboard:
13.1 Connect the power cable to the USB-C socket in the keyboard (LED diode
will light up in red colour).
13.2 If the LED diode will go off, it means that the keyboard is fully charged.
13.3. Plug off the power cable, the keyboard is ready to use.
14. Safety conditions:
• Use this device as intended.
• Incorrect use of the device may damage the device.
• Independent repairs and modification results in automatic loss of the warranty.
• Hitting or dropping the device could cause damage of the device.
• The device should be used in dry area, the device should be protected
from water and high humidity.
• Before the first use of the keyboard, it should be fully charged
• After the battery is fully charged, plug off the power cable.
• If the power cable is plugged when the keyboard is fully charged, it may
cause damage to the battery or shorten its lifespan.
• When the device is not being used for a long period of time, the battery may discharge.
POLSKI
Dziękujemy za zakup produktu marki Savio!
Jeśli nasz produkt spełnił Twoje oczekiwania, podziel się swoją opinią z inny-
mi osobami na portalu ceneo.pl,w mediach społecznościowych lub na stronie
sklepu, w którym dokonałeś zakupu. Będzie nam niezmiernie miło, jeśli zechcesz
również pochwalić się naszym urządzeniem na profilu SAVIO na Facebooku.
Jeśli jest coś, co moglibyśmy poprawić w naszych produktach, napisz nam
o tym na adres: support@savio.pl
Dzięki Twojej opinii będziemy mogli jeszcze lepiej dopasować produkt do Twoich
oczekiwań.
Przed przystąpieniem do korzystania z zakupionego urządzenia zaleca się
przeczytanie całej instrukcji obsługi.
1. Zawartość opakowania:
• Mini klawiatura bezprzewodowa
• Odbiornik 2.4 GHz
• Kabel USB-A – USB-C
• Akumulator li-ion
• Instrukcja obsługi
2. Informacje podstawowe:
Bezprzewodowa klawiatura SAVIO KW-04 BT + 2.4 GHz to wielofunkcyjne,
kompaktowe urządzenie, łączące w sobie cechy pełnowymiarowej klawiatury
QWERTY oraz panelu dotykowego (touchpad). Dzięki klawiaturze KW-04 można
w szybki i wygodny sposób przeglądać strony internetowe oraz korzystać z za-
instalowanych na urządzeniu aplikacji.
3. Urządzenie kompatybilne z:
• Komputer PC / Laptop
• Windows / Linux
• Smart TV / Android TV
• TV BOX
• Xbox / PlayStation*
• Projektor z Androidem
• Smartfon / Tablet z funkcją (OTG)**
* W przypadku użytkowania klawiatury z konsolą pewne funkcje takie jak to-
uchpad lub rodzaj połączenia mogą być ograniczone.
** Smartfony i tablety muszą posiadać funkcję OTG (połączenie za pomocą
kabla USB OTG).
1
means the button has been successfully pro-
flashes five times
Fn Fn Fn
+ + +
Backlight Keyboard Main
options combi- browser
settings nation:
CTRL + ALT
+ DELETE
Klawiatura bezprzewodowa
Instrukcja obsługi
FN
+
Google
Assistant
model: KW-04
