Savio KW-01 User Manual

ENGLISH
Thank you for choosing our product!
If our product meets your expectations, share your opinion with
other people on the portal ceneo.pl, on social media or on the
website of the store where you made the purchase. If you want
to show off our device on Savio.net.pl FanPage on Facebook, we
will be very pleased.
If there is something that we could improve on our products, please
write to us at support@savio.net.pl
Thanks to your feedback, we will be able to better adapt the product
to your expectations.
Before starting the use of purchased device it is recommended
to read the whole manual.
1. Package content:
• Mini wireless keyboard
• USB receiver
• USB(M) – Micro USB(M) Cable
• Li-ion battery
• User manual
2. Basic information:
Wireless keyboard KW-01 / KW-02 / KW-03 is a compact, multifunctional de-
vice, that combines features of full-size QWERTY keyboard and a touchpad.
Thanks to a KW-01 / KW-02 / KW-03 keyboard you can browse internet web-
sites or use installed applications in a quick and easy way.
3. Device compatible with:
• PC computer / Laptop
• Smart TV / Android TV
• TV BOX
• Xbox / PlayStation
• Raspberry Pi
• Smartphone / Tablet (OTG)*
*Smartphone and a tablet need to have an OTG function (connection
through USB OTG Cable)
4. Indicator diodes description:
• Diode – backlit while charging the battery, fully charged battery is
indicated by turned off backlit.
• Diode – blinking diode indicates, that the USB receiver is not connected
or a keyboard is not paired.
• Diode – backlit with constant light when the keyboard is connected
to adevice.
• Diode – indicates pressing of a button.
5. Touchpad use:
The integrated touchpad enables to browse internet websites and use of the
installed application same way, as with a traditional computer mouse.
• A single touch of touchpad replaces the click of the left mouse button
• Double click of the touchpad replaces the right mouse click
• To use the scroll function, you need to use two fingers, one should be held
still on the touchpad and the other will move up and down
6. Connecting the device:
Put the USB receiver into the desired USB port in the device, After plugging it
in you need to turn on the keyboard by moving the power switch in the lower
part of the keyboard to the "ON" position. The device pairs automatically. After
finishing the use of the device, the switch needs to be in the "OFF" position. Not
turning off the device may cause the battery to discharge and wear off faster.
7. Auto sleep mode and wake up:
• Keyboard has the functions of automatic sleep mode and wake up.
• Keyboard automatically switches into the sleep mode within 3 minutes
when idle. Pressing any button will cause the keyboard to wake up instantly.
8. Technical specification of the keyboard:
• Range: up to 10 meters
• Battery capacity: 300 mAh
• Power consumption: 8-15 mA, <15 mA in sleep mode
• Frequency bands in which the radio equipment operates: 2400 – 2483.5 MHz
• Maximum radio-frequency power transmitted in the frequency band in
which the radio equipment operates: 5 dBm
• Working Voltage: 3.7 V
• Dimensions: 147 × 85 × 16 mm
• Weight: 96 g
9. Comments:
• When the device is not being used for a long period of time, the battery
may discharge.
• When the keyboard is fully charged, it should be plugged off from power source.
• Making any self-repairs and modifications cause instant loss of guarantee.
• Protect against high and low temperatures, to save the battery from damage.
• It is recommended to clean the keyboard with a soft cloth or cleaning
agents for this type of devices. Use of the improper cleaning agents may
damage the keyboard. Keep the keyboard away from water, the device is
not water resistant.
• In the case of connecting the keyboard to a SMART TV – the TV must sup-
port USB HID function or have an external controller support function.
• Before the first use of the keyboard, it should be fully charged.
• After the battery is fully charged, plug off the power cable.
• If the power cable is plugged when the keyboard is fully charged, it may
cause damage to the battery or shorten its lifespan.
10. Troubleshooting:
Wireless keyboard
model: KW-01, KW-02, KW-03
User manual
Problem Possible cause
The keybard is 1. Low battery
not reacting 2. Device is off
1. The USB receiver
The keyboard is disconnected
cannot connect 2. The device has
to the receiver
not been paired
automatically.
The mouse
1. The device can
pointer is
be out of reach
not moving
2. Low battery level
properly or 3. Touchpad is dirty
does not react 4. The touchpad is off
11. Diagram of key combinations:
FN FN FN
+ + +
RF
Pairing Turn on Sensor Main
the / off the sensi- menu
device touch- tivity
pad
12. The backlit colour setting of the keyboard (for KW-03 model):
12.1 Press buttons: FN+
, to activate the keyboard backlit.
12.2 Press buttons FN+RGB, to get to the backlit colour setting.
12.3 Set a backlit colour by using the touchpad.
12.4 Confirm a backlit colour by pressing key combination FN+RGB Backlit
colour is now saved, the keyboard is ready to use.
13. Charging the keyboard:
13.1 Connect the power cable to micro USB in the keyboard (LED diode will
backlight in red colour).
13.2 If the LED diode will go off, it means that the keyboard is fully charged.
13.3. Plug off the power cable, the keyboard is ready to use.
14. Safety conditions:
• Use the product in accordance with its intended use, as improper use may
damage the product.
• Do not expose the device to moisture, heat or sunlight, do not use the
product in a dusty environment.
• The device should be cleaned only with a dry cloth.
• Independent repairs and modification result automatic loss of the warranty.
• Hitting or dropping may damage the product.
POLSKI
Dziękujemy za zakup produktu marki Savio!
Jeśli nasz produkt spełnił Twoje oczekiwania, podziel się swoją
opinią z innymi osobami na portalu ceneo.pl, w mediach społec-
znościowych lub na stronie sklepu, w którym dokonałeś zakupu.
Będzie nam niezmiernie miło, jeśli zechcesz również pochwalić się
naszym urządzeniem na profilu Savio.net.pl na Facebooku.
Jeśli jest coś, co moglibyśmy poprawić w naszych produktach,
napisz nam o tym na adres: support@savio.net.pl
Dzięki Twojej opinii będziemy mogli jeszcze lepiej dopasować produkt
do Twoich oczekiwań.
Przed przystąpieniem do korzystania z zakupionego urządzenia zaleca
się przeczytanie całej instrukcji obsługi.
1. Zawartość opakowania:
• Mini klawiatura bezprzewodowa
• Odbiornik USB
• Kabel USB(M) – Micro USB(M)
• Akumulator li-ion
• Instrukcja obsługi
2. Informacje podstawowe:
Bezprzewodowa klawiatura KW-01 / KW-02 / KW-03 to wielofunkcyjne, kom-
paktowe urządzenie, łączące w sobie cechy pełnowymiarowej klawiatury
QWERTY oraz panelu dotykowego (touchpad). Dzięki klawiaturze KW-01 / KW-
02 / KW-03 można w szybki i wygodny sposób przeglądać strony internetowe
lub korzystać z zainstalowanych aplikacji.
3. Urządzenie kompatybilne z:
• Komputer PC / Laptop
• Smart TV / Android TV
• TV BOX
• Xbox / PlayStation
• Raspberry Pi
• Smartfon / tablet z funkcją (OTG)*
*Podłączenie za pomocą kabla USB OTG.
1
Solution
1. Start charging the device
and wait 15 minutes.
2. Move the switch to "ON"
1. Connect the USB
receiver to the device
2. Press FN+RF at once
for 3 seconds
1. Closen up the distance
between the receiver
and keyboard
2. Recharge the battery
3. Clean the touchpad
4. Turn on touchpad
by pressing the key
combination(FN+
V+ V-
L
Appli- Volume Volume Left
cations up down mouse
menu button
Klawiatura bezprzewodowa
model: KW-01, KW-02, KW-03
Instrukcja obsługi
)
FN
+
R
KW-02
KW-03
Right On / Off
mouse key-
button board
back-
light
