Prius Healthcare USA Dynaflow Manual

Lal, 3-1 alternation, anti-decubitus system
Hide thumbs Also See for Dynaflow:

Advertisement

Quick Links

Control Panel Guide
Power Switch
Therapy Mode- Press to toggle between Static,
Pulsation and Alternate modes on the mattress.
Patient Care/Maximum Inflation- Press to max Inflate
mattress to assist medical staff for patient bedside
treatment and help facilitate patient ingress/egress.
Cycle Time- When mattress is in Alternate Mode, this
feature allows you to select the duration of alternation in
3-95 minutes
Power Switch- After the unit is plugged in, the LED will
illuminate AMBER. Press the power switch to operate the
mattress, the LED will turn GREEN.
Audio Alarm ON/OFF- Press to silence alarm until
bed resets or alarm issue resolved.
Auto Set- When Auto Set is activated the control unit
is automatically optimizing patient's comfort setting
base on patient's BMI input.
Prius Healthcare USA
Therapy Mode:
Static,
Pulsation and
Alternate
Maximum
MODE
PATIENT
Inflation
CARE
+
Cycle Time
_
CYCLE
Preset Key
Audio Alarm
ON/OFF
Auto Set
Manual BMI
LCD Display
Selection
DynaFlow
+
_
Power
Failure
Panel Lock
Power Failure Alarm
Sensor Disconnect
Panel Lock- Press and hold for 3 seconds to lock/
unlock all controls from patients or other non-
caregivers.
Power Failure Alarm- Indicates loss of power to control unit.
Sensor Disconnect- Indicates the Auto Fowler sensor has been
disconnected. Please check the connection and inspect sensor
cable for damage.
Patients BMI Setting- Press to toggle for English/
Metric measurements, patients height setting, patients
weight setting.
Comfort Setting- Manually choose from selectable levels of
air pressure for support of the patient. Manufacturer
recommends using a hand check to select proper pressure
setting for an individual patient.
LCD Display- Shows active control unit settings.
www.priushcusa.com
Dynaflow
LAL, 3-1 Alternation,
Anti-Decubitus System
FC-PHR0028
Product Code-
Comfort Setting
+
SET
_
Sensor
Disconnect
Patient's BMI Setting
813-854-5464

Advertisement

loading
Need help?

Need help?

Do you have a question about the Dynaflow and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Prius Healthcare USA Dynaflow

  • Page 1 Auto Set- When Auto Set is activated the control unit setting for an individual patient. is automatically optimizing patient’s comfort setting base on patient’s BMI input. LCD Display- Shows active control unit settings. www.priushcusa.com Prius Healthcare USA 813-854-5464...
  • Page 2 Covers can be washed and thermally disinfected in a washing machine. Never use phenol based cleaning solutions. www. cusa.com 813-854-5464 Prius Healthcare USA...
  • Page 3 DynaFlow Suggested Weight Guideline Level *Suggested weight range (KG) *Suggested weight range (LB) 40-75kgs 88-165lbs 64-102kgs 141-225lbs 86-125kgs 190-275lbs 113-150kgs 250-330lbs 136-193kgs 300-425lbs 179-240kgs 395-530lbs 208-294kgs 459-648lbs 257-341kgs 568-753lbs 317-386kgs 701-851lbs 373-453kgs 823-1000lbs *Please note that the above charts are just a guideline, not a rule. Because of different body types, shapes and height we recommend using...

This manual is also suitable for:

Fc-phr0028
