ROLINE HDMI Dual Head KVM Switch 4K60
14.01.3047
User Manual
Version 1.0
Introduction
This ROLINE HDMI Dual Head KVM Switch 4K60 allows the control of two computers with 4K dual HDMI video
output via a single console set of USB keyboard/mouse/hub, as well as microphone, speaker and display. It has
built-in USB 2.0 compliant ports as well as 3.5mm mini stereo ports which allow sharing USB keyboard/mouse/hub
as well as speaker and microphone among the connected computers. The switching between the connected
computers is executed by using the front panel pushbutton and keyboard hotkey commands alternative. Product
set-up for use is quick and simple with no software to install, so you are ready to go right out of the box.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Roline 14.01.3047
Summary of Contents for Roline 14.01.3047
- Page 1 Version 1.0 Introduction This ROLINE HDMI Dual Head KVM Switch 4K60 allows the control of two computers with 4K dual HDMI video output via a single console set of USB keyboard/mouse/hub, as well as microphone, speaker and display. It has built-in USB 2.0 compliant ports as well as 3.5mm mini stereo ports which allow sharing USB keyboard/mouse/hub...
-
Page 2: Specifications
Features Features Description 2-Port KVM Switch Control two computers via one USB console. 4K HDMI video display Supports the computer with resolutions up to 4K UHD (3840 x 2160 @ 60 Hz) single/dual-head HDMI video output. HDMI & HDCP compliant HDMI 2.0 &... -
Page 3: Hardware Description
Hardware Description Dual-Head Front Panel Component Description Audio jack Microphone port at console Audio jack Speaker/Earphone port at console HDMI connector HDMI-2 output at console Reset button Press to reset the system to default HDMI connector HDMI-1 output at console USB Type A connector 2x USB keyboard &... -
Page 4: Installation
Installation Dual-Head Refer to the following steps and diagrams to set up your dual-head KVM switch. Connect HDMI monitors to the “HDMI Out” console ports on the front panel of the KVM switch. Connect your USB keyboard and USB mouse directly to the USB keyboard and mouse ports on the front panel of the KVM switch. -
Page 5: Operation
Operation PC Port Switching There are two ways of accessing computers and devices connected to the KVM switch: Push button Hotkey Push button Press the push button once to switch the selected PC port between the two connected computers ... - Page 6 Disclaimer Information in this document is subject to change without notice. The manufacturer does not make any representations or warranties (implied or otherwise) regarding the accuracy and completeness of this document and shall in no event be liable for any loss of profit or any other commercial damage, including but not limited to special, incidental, consequential, or other damages.
