- Page 1 H12+ CONTROLLER User manual EU Version A Minicam Ltd, Unit 33, Ravenscraig Road, Little Hulton,Salford, M38 9PU SCAN ME AND Tel: +44 (0) 1942 270524 • Email: info@minicam.co.uk FIND MANUAL www.minicam.co.uk ONLINE...
-
Page 2: Table Of Contents
Contents User manual for H12+ Camera System Disclaimer ··········································································································· 3 Warranty ··········································································································· 4 Limited Warranty ················································································ 4 Extent of the Limited Warranty ························································ 4 Conditions of the Limited Warranty ················································ 4 Warranty Limitations ·········································································· 4 Text Conventions ································································································ 5 Danger, Caution and Note ·································································5 Bold Font ······························································································... -
Page 3: Disclaimer
This document is applicable to the Minicam Hathorn H12+ A standard system and available options are covered by this document. Depending on your system configuration you may lack some of the features mentioned in this document. Disclaimer Hardware and software mentioned in this document are subject to continuous development and improvement. Consequently, there may be minor difference between the information in the document and the performance or design of the product. -
Page 4: Warranty
WARRANTY Limited Warranty Congratulations on the purchase of your new Hathorn Inspection System. Our products are the result of many years experience and continuous developments. Conscientious manufacturing and checking are essential objectives in our company. Nevertheless failures cannot be excluded totally. If this occurs, you are covered by our generous warranty. Please consider that even the best products can only be durable and work properly with the correcthandling and maintenance. -
Page 5: Text Conventions
TEXT CONVENTIONS Danger, Caution and Note In this user manual the following symbols are used: DANGER! Danger means a potentially dangerous situation that can cause death or severe bodily injury. The icon identifies the type of risk. CAUTION! Caution means that the system or equipment can be damaged or data lost. The icon identifies the type of risk. -
Page 6: Eu Declaration Of Conformity
EU DECLARATION OF CONFORMITY CE Declaration We Minicam Ltd, Raven Locks, Unit 33-35 Ravenscraig Road, Little hulton, United Kingdom, M38 9PU hereby declare that the product Minicam Hathorn H12+ to which this declaration refers is in compliance with the following standards or standardizing documents: EN61326-1: 2021 Electrical equipment for measurement, control and laboratory use –... -
Page 7: Weee Statement
WEEE Statement Under the European Union (EU) Directive on Waste Electrical and Electronic Equipment, Directive 2002/96/EC, products of electrical and electronic equipment cannot be discarded as municipal waste anymore and manufacturers of covered electronic equipment are obligated to take back such products at the end of their useful life. Minicam will comply with the product take back requirements at the end of life of Minicam products that are sold into the EU. -
Page 8: Product Specifications
H12+ MINICAM HATHORN CONTROLLER Product Specifications Weight 4.3 Kg (9.5 lbs) Length × Width × Depth 38 cm × 30 cm × 14 cm (15” × 12” × 5.5”) Power AC/DC Adapter 12V - 4.1A Battery Only Milwaukee M18 18V or equivalent ®... -
Page 9: Keypad Icons
KEYPAD ICONS Keypad Icons POWER ON/OFF SONDE ON/OFF CAMERA LEDS UP CAMERA LEDS DOWN FOOTAGE COUNTER RESET HATHORN INFO BAR MIC/SPEAKER ON/OFF ZOOM 1X, 2X, 4X, 8X MENU ENTER/EXIT NAVIGATION BUTTONS ENTER/CONFIRM SELECTION STOP RECORDING & PAUSE RECORDING & PLAYBACK PLAYBACK RECORD VIDEO TAKE SCREEN SHOT... -
Page 10: Information Bar Icons
INFORMATION BAR ICONS Information Bar Icons Hathorn Inspection Cameras BATTERY MONITOR Information Bar 512 Hz MICROPHONE SONDE ON/OFF & FREQUENCY +0.0' RECORDING MEDIA FOOTAGE (FT. OR M) Zoom 11/22/2022 DATE & TIME ZOOM 2:35 pm Setting up Your System for First Use Your controller comes from the factory set for us using factory default settings. -
Page 11: Keyboard Functions
KEYBOARD FUNCTIONS The keyboard can be used to type information onto the screen overlay. Anything shown on the screen while recording will show up on the recording. Hide Page Save Page Page 1 to Page 8 Hides the selected page. Saves what is visible on the Brings up the corresponding Please not that anything typed... -
Page 12: User Instructions
H12+ MINICAM HATHORN CONTROLLER User Instructions Turning Your Monitor On Press the POWER button to turn on the controller. At this point you should see the Hathorn logo on the screen while the system boots up. Boot up takes ~12 seconds. NOTE: It is good practice to remove batteries from electronic equipment after use. - Page 13 HATHORN H12+ ® CONTROLLER User Instructions Selecting a Menu Language In the main menu, you can select the language you prefer to read menuinformation. Your choices are English, French, or Spanish. To select thepreferred language, press the MENU button, then press enter again on theCONTROLLER SETTINGS icon.
-
Page 14: Setting Up The System
WI-FI USER INSTRUCTIONS Wi-fi User Instructions Download the Wi-Fi App • Turn on the mobile device and enter App Store for either Apple or Android • Search for the Minicam Viewer app ) latest version Install the app software • Note: You must be running iOS 13 or later for Apple Setting Up the System Connect DC power plug to the jack on the reel hub using AC/DC adapter or 18V external battery. - Page 15 Wi-fi User Instructions Video viewing and recording Open the app and click “CONNECT”. If the connection between the camera and the mobile device was successful, the video will begin playing automatically. If it does not, then repeat the Wi-Fi pairing steps. No option exists to pause during recording.
-
Page 16: Recording Video
RECORDING VIDEO Recording Video Select the media location you wish to record to in the Controller Menu. You can choose USB, HDD or both USB & HDD. Insert the USB stick into the USB port if you wish to record to USB. All videos are stored in MPEG4 format. Press the VIDEO RECORDING key on the control pad. -
Page 17: Deleting Folders
Playing Media Files Press the MENU key, then enter the FILE STORAGE OPTIONS menu. Select the date on which files were recorded, then highlight the file you wish to play and press the RIGHT ARROW or ENTER key on the keypad or enter key on the keyboard. -
Page 18: Inspection Procedure
INSPECTION PROCEDURE Locating the Sonde Signal (512 Hz or 640 Hz) Skids or sleeves should ALWAYS be used to protect the camera head. Depending on the size of the pipe you are inspecting, you may need to use a skid, so the camera is centered or off the floor of the line. Care should be taken so the skids do not snag in the line. - Page 19 Locating the Sonde Signal (512 Hz or 640 Hz) Insert the sonde into the drain and locate it while it is still just in view at the drain or duct entrance. Hold the locator vertically - directly over the sonde with the antenna in line with the sonde. Adjust the locator sensitivity so the bar graph reads between 60% and 80%.
-
Page 20: Maintenance
MAINTENANCE Inspection Camera After every use, the camera should be cleaned and checked for possible damage. External scuffing of the camera case is normal and should be of no concern. The camera view port is made of sapphire and should be cleaned with a soft, damp cloth. -
Page 21: Troubleshooting
TROUBLESHOOTING APPLY POWER TO UNIT DO LIGHTS COME ON? IS AC OUTLET LIVE? PRESS POWER BUTTON ON MONITOR. DOES PICTURE APPEAR? CHECK DC OUTPUT OF AC ADAPTOR FOR 12 VOLTS DC CAMERA IS OPERATING PROPERLY REPLACE AC ADAPTER CONTACT SERVICE DEPARTMENT AT +44 (0) 1942 270524 INFO@MINICAM.CO.UK If a problem not shown on this chart is found, please contact a Minicam service center. -
Page 22: Repair Facilities
REPAIR FACILITIES North Service Centre Minicam Ltd, Unit 33-35 Ravenscraig Road, Little Hulton, Salford, M38 9PU Email: info@minicam.co.uk Phone: +44 (0) 1942 270524 South Service Centre Minicam Ltd, Unit 41, Acorn Industrial Park Dartford Kent DA1 4AL Email: info@minicam.co.uk Phone: +44 (0) 1942 270524 www.minicam.co.uk USER MANUAL H12+ CONTROLLER... - Page 23 Minicam Ltd, Unit 33, Ravenscraig Road, Little Hulton,Salford, M38 9PU Tel: +44 (0) 1942 270524 • Email: Email: info@minicam.co.uk www.minicam.co.uk...
