Lumena FORTRESS Instructions

PLEASE READ THESE INSTRUCTIONS CAREFULLY PRIOR TO INSTALLATION / MAINTENANCE
•
If a fitting is found to be damaged, cease use immediately.
•
This is a Class 1 product and must be earthed.
•
This unit must be fitted by a competent and qualified electrician.
•
Install in accordance with IEE wiring regulations and current Building
Regulations.
•
To prevent electrocution, switch off mains supply before installing or
maintaining this fitting. Ensure other persons cannot restore the electrical
supply without your knowledge.
•
This light fitting should be connected to a circuit with a 30Ma RCD fitted.
Maximum 12-15 fittings on each circuit recommended.
•
If replacing an existing fitting, make a careful note of the connections.
•
All connections should be made as watertight as possible to avoid electrical
shortage.
•
When changing the bulb, always switch off at the mains & allow to cool before
handling.
•
Always use the correct type & wattage bulb. Never exceed the wattage stated.
•
The unit may get warm whilst on for a period of time.
Voltage: 220 – 240V 50Hz
Max. Wattage: 60W
Bulb Holder: ES / E27
Recommended Bulb: 15w Corn Bulb
IP Rating: IP65
Product Heights: 0.8m / 1.0m above ground + 0.4m below ground (approx.)
Product Finishes: Graphite Black
Product Head Styles: Dome / Flat / Pillar
Materials: Aluminium and Polycarbonate (stainless steel screws)
Mount: Surface Mount
Sensor: PIR (Motion Sensor) ≤8m detection range / 100˚ detection angle
Sensor Settings: Time Control = 6s, 3m, 5m, 8m / Light Control = 5Lux ≤ all night
Working Temperature/Humidity: -20~+40˚C / ≤93%RH
INCLUDED: Root Mount Tube, Bollard Head, Bulb Holder with Connection Box, 3 x Bulb Holder Screws, 1 x Anchor Bar, 2 x Nuts, 2 x
Security Pin Hex Screws & Allen Key, M20 Cable Gland, PIR Sensor, LED Lamp (optional).
CLEANING:
Occasional cleaning and care is recommended for this product, particularly of the sensor. Please refer to our website for the best way to clean
different materials.
RETURNS & RECYCLING:
If purchased from a 3 party, please contact your supplier. If purchased direct, contact us by phone or email:
rd
Lumena Lights Ltd, Centre 33 Long March, Daventry, NN11 4NR
Our full returns policy is available on our website.
Waste Electrical Products must not be disposed of with household waste. Please check with your local authority or contact us for more
information. Please recycle packaging whenever possible.
SPARES, ALTERNATIVE MOUNTING OPTIONS & ACCESSORIES AVAILABLE FROM LUMENA
Corn Lamps sold separately.
Full product range & more information: www.lumenalights.com
FORTRESS Bollard Light (Root Mount)
WARNINGS
Tel: +44 1327 871161
Producer Registration Number: WEE/KC3440XY
INSTRUCTIONS
All Variations – PIR
✔✔✔✔✔
5 YEAR
GUARANTEE
see website for
more details
Reduced warranty for
specific components
Email: sales@lumenalights.com
Made in China to Lumena Specification
