PGO27QFV
User Manual
Version 1.0
Published October 2024
Copyright©2024 ASRock INC. All rights reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PGO27QFV and is the answer not in the manual?

Questions and answers

Summary of Contents for ASROCK PGO27QFV

  • Page 1 PGO27QFV User Manual Version 1.0 Published October 2024 Copyright©2024 ASRock INC. All rights reserved.
  • Page 2: Table Of Contents

    Contents Chapter 1 Introduction Package Contents Chapter 2 Setting up the Monitor Attaching the Stand Arm and Base Detaching the Stand Arm and Base Making Connections Adjusting the Viewing Angle Using the Security Slot Chapter 3 Monitor Overview Front View Rear View Bottom View Chapter 4 Specifications...
  • Page 3 Chapter 7 Troubleshooting Chapter 8 Safety Instructions...
  • Page 5: Chapter 1 Introduction

    Chapter 1 Introduction Thank you for purchasing PGO27QFV, a reliable monitor produced under ASRock’s consistently stringent quality control. It delivers excellent performance with robust design conforming to ASRock’s commitment to quality and endurance. 1.1 Package Contents Your monitor ships with the components shown below. Please make sure that you have...
  • Page 6: Chapter 2 Setting Up The Monitor

    Chapter 2 Setting up the Monitor 2.1 Attaching the Stand Arm and Base Step 1. Installing the Stand Base • Leave the monitor in its protective foam packaging. ⚠ Important Place the monitor in its protective foam packaging, or on a soft, protected surface to avoid scratching the display screen.
  • Page 7 Step 2. Installing the Stand Arm • Align and slide the two tabs on the stand arm to the groove on the back of the monitor until it snaps into place. • Push the stand lock to the locked position to ensure the stability.
  • Page 8 Step 3. Placing the Monitor Upright Lift the monitor carefully out of the foam packaging and into its upright position on a flat, stable surface. ⚠ Important Be careful not to touch or press the display screen areawhen lifting or moving the monitor to avoid any scratches or damage.
  • Page 9: Detaching The Stand Arm And Base

    2.2 Detaching the Stand Arm and Base Before removing the stand, be sure to turn off the monitor and disconnect all cables. Push the stand lock to the unlock position. Lift upward to disengage the tabs on the stand arm from the monitor. Remove the stand (arm and base). Release the screw at the bottom of the stand base.
  • Page 10: Making Connections

    2.3 Making Connections Connecting the Power Cord Connect the power cord to the monitor and to an electrical wall outlet. Pass the cable through the cable management hole on the stand arm. ⚠ Important Please make sure to make a grounding connection before connecting the power plug to the power source.
  • Page 11 Connecting the Monitor to the PC / Laptop HDMI Connection Connect one end of the HDMI cable to the HDMI connector on the rear side of the monitor. Then connect the other end to the HDMI connector on the PC or laptop. Pass the cable through the cable management hole on the stand arm.
  • Page 12 DisplayPort Connection Connect one end of the DisplayPort cable to the DisplayPort input connector on the rear side of the monitor. Then connect the other end to the DisplayPort output connector on the PC or laptop. Pass the cable through the cable management hole on the stand arm.
  • Page 13 USB Type-C Connection (for Display and Power Delivery) The type-C port on the rear side of the monitor is compatible with the DP Alt mode and USB power delivery. Use a Type-C cable to connect the monitor to your laptop for an external display. You can also connect it to our smartphones or tablets to mirror your device's screen on the monitor, enabling you to share videos and photos with others.
  • Page 14 Antenna Cable Connection This monitor has a built-in Wi-Fi antenna. Placed on the table, the integrated antenna on the back of the monitor provides great Wi-Fi connectivity up to 7dBi peak gain. If your motherboard comes with built-in Wifi, use the provided antenna cables to turn your monitor a powerful wireless antenna.
  • Page 15 Audio Cable Connection You can connect headphones to the headphone jack on the bottom side of the monitor. Pass the cable through the cable management hole on the stand arm.
  • Page 16: Adjusting The Viewing Angle

    2.4 Adjusting the Viewing Angle Tilt Angle Adjustment For optimal viewing, it is recommended to look at the full face of the monitor, and then adjust the monitor’s angle to your own preference. Hold the stand firmly with one hand while tilting the monitor forwards or backwards with the other hand so you do not topple the monitor when you adjust the monitor’s angle.
  • Page 17 Height Adjustment You can lower or raise the monitor to the desired height. 100mm Swivel Angle Adjustment You are able to swivel the monitor for the angle. ⚠ Important Be careful not to touch or press the display screen area when adjusting the monitor.
  • Page 18: Using The Security Slot

    2.5 Using the Security Slot This monitor supports a Kensington-type security slot. The Kensington lock can be used to secure the monitor and prevent it from being stolen in public locations. NOTE: Kensington lock is not included. You need to purchase an additional locking device.
  • Page 19: Chapter 3 Monitor Overview

    Chapter 3 Monitor Overview 3.1 Front View Item Description Display screen The display part of a monitor The color definition of the power indicator: • Solid White - Power on mode • Solid Orange - Standby mode (no signal input) •...
  • Page 20: Rear View

    3.2 Rear View Item Description Volume Button Press to activate the volume control function. Press to activate the OSD Main Menu. Menu Button Please see the sections entitled "Hot Keys" and Hot Keys/Joystick "Using the Joystick Control" for more information. Press to turn the monitor on.
  • Page 21 Secures monitor with security lock (security lock Kensington Lock Slot not included). Cable management Hole Organize cables by passing them through the hole. Antenna Ports Connect the Wi-Fi antenna cables.
  • Page 22: Bottom View

    3.3 Bottom View 4 5 6 Item Description AC-IN port Connect the power cord. HDMI 1 port Connect your computer with the HDMI cable. HDMI 2 port Connect your computer with the HDMI cable. DisplayPort Connect your computer with the DisplayPort cable. Connect your devices, such as laptops, smartphones, or tablets with the Type-C cables.
  • Page 23: Chapter 4 Specifications

    Chapter 4 Specifications 4.1 Monitor Specifications Model PGO27QFV Panel Size 27" Viewing Area 587 x 330 mm (H x V) Aspect Ratio 16:9 Panel Type QD-OLED Viewing Angle 178°(H) / 178°(V) Resolution QHD (2560 x 1440) Pixel Pitch 0.2292 mm...
  • Page 24 Power Consumption (Max) ≦ 100W Power Saving Mode ≦ 0.5 W Power Consumption Power Off Mode ≦ 0.3 W Voltage 100~240VAC, 50/60Hz, 2.7A Tilt Adjustment -7° ~ +20° Swivel Adjustment -20° ~ +20° Mechanical Height Adjustment 0~100 mm Design 100x100 mm (4 screw holes) VESA Mount M4*12 mm Dimension with Stand...
  • Page 25: Supported Timing List

    4.2 Supported Timing List PGO27QFV Standard Resolution HDMI IBM MODE DOS 720x400 @70Hz 640x480 @60Hz 640x480 @67Hz 640x480 @72Hz 640x480 @75Hz 800x600 @56Hz 800x600 @60Hz SVGA 800x600 @72Hz 800x600 @75Hz 1024x768 @60Hz 1024x768 @70Hz 1024x768 @75Hz 1280x1024 @60Hz SXGA 1280x1024 @75Hz...
  • Page 26 640x480P 59.94/60Hz 4:3 1280x720P 50Hz 16:9 1280x720P 59.94/60Hz 16:9 1920x1080P 59.94/60Hz 16:9 Video Timing 1920x1080P 119.88/120Hz 16:9/1:1 Resolution 2160P @30Hz 2160P @50Hz 2160P @60Hz 2160p @120Hz...
  • Page 27: Chapter 5 Operating The Monitor

    Chapter 5 Operating the Monitor 5.1 Powering On/Off the Monitor Press the Power button (the rightest one on the rear side of the monitor) to turn on the monitor. The power indicator on the front of the monitor lights up in solid white to show that the monitor is ON.
  • Page 28 The color definition of the power indicator: LED Indicator Status Description Solid White Solid white light indicates the monitor is turned on. Solid orange light indicates the monitor is in standby Solid Orange Standby mode. LED Off No light indicates the monitor is turned off.
  • Page 29: Hot Keys

    5.2 Hot Keys When the OSD screen is off, press the control buttons on the rear side of the monitor to access the OSD menu, change the input source, and adjust the brightness and the volume. Icon Hot Key (When OSD is OFF) VOLUME Press to activate the Volume control function.
  • Page 30: Using The Joystick Control

    5.3 Using the Joystick Control When the OSD screen is on, use the joystick on the rear side of the monitor to navigate the OSD menu and adjust the settings. To access the OSD menu, press the joystick button to launch the OSD main menu. Move the joystick up/down/left/right to toggle between options.
  • Page 31 Toggle right (when facing the front side of the monitor) to select menu items or go to the Toggle Right next menu (Move). Increases the parameters of the selected menu item (Adjust). Toggle Up Toggle up to select menu items (Move). Toggle Down Toggle down to select menu items (Move).
  • Page 32: Chapter 6 Osd Setup

    Chapter 6 OSD Setup This chapter provides you with essential information on OSD Setup. ⚠ Important All information is subject to change without prior notice. 6.1 Accessing the OSD Menu After you press the Menu button, the OSD menu appears on the lower right corner of your monitor screen.
  • Page 33: Osd Menus

    6.2 OSD Menus Function: Luminance Luminance Contrast Brightness Preset Modes Standard :Down :Right :Left :Enter Main Menu Item Sub Menu Item Sub Menu Description Luminance Contrast 0-100 Contrast adjusts the degree of difference between darkness and lightness on the monitor screen. Brightness 0-100 Brightness adjusts the luminance of...
  • Page 34 Function: Image Setup Image Setup Image Ratio Full FreeSync Premium Pro Auto Sharpness Dark Boost :Down :Right :Left :Enter Main Menu Item Sub Menu Item Sub Menu Description Image Setup Image Ratio Full Select Image Aspect Ratio. Aspect FreeSync The AMD FreeSync Premium Pro Premium Pro technology effectively prevents screen tearing and stuttering,...
  • Page 35 Function: Color Temp. Color Temp. Color Temp. Normal Green Blue Low Blue Light :Down :Right :Left :Enter Main Menu Item Sub Menu Item Sub Menu Description Color Temp. Warm ─ Increases the color temperature. The screen appears warmer with a red/yellow tint. Normal ─...
  • Page 36 Function: OSD Setup OSD Setup H.Position V.Position Timeout Language English :Down :Right :Left :Enter Main Menu Item Sub Menu Item Sub Menu Description OSD Setup H. Position 0-100 Adjusts the horizontal position of OSD. V. Position 0-100 Adjusts the vertical position of OSD.
  • Page 37 Input Select Auto USB Charging DDC/CI Reset Resolution 2560H x 1440V H.Frequency 585KHz V.Frequency 360Hz Model Name PGO27QFV :Down :Right :Left :Enter Main Menu Item Sub Menu Item Sub Menu Description Extra Input Select Auto Search for an available input source and select automatically.
  • Page 38 Function: OLED Care OLED Care Pixel Shift Slow Pixel Clear Standby Static Screen Detection Starting in 50sec Time required 120sec Reducing Level :Down :Right :Left :Enter Main Menu Item Sub Menu Sub Menu Description Item OLED Care Pixel Shift Slow The Pixel shift feature moves the image a couple of pixels at Normal...
  • Page 39 OLED Care Static Screen Static Screen Detection can Detection protect against burn-in from prolonged display of static content. When enabled, it detects if there are static images on the screen for a preset period of time, and the monitor will reduce brightness automatically.
  • Page 40 OLED Care Multi Logo 0-2 (Level) The Multi Logo Detection feature Detection can prevent image retention by detecting multiple static logos on the screen and decreasing brightness in those areas. You can select the brightness reduction level, ranging from Level 0 to Level 2.
  • Page 41 OLED Care Protect Auto Protect Notice will remind users Notice time to run Pixel Clear. When it is set to "Auto", a notice will appear after every 4 hours of cumulative use. Users can skip doing Pixel Clear until continuously 16 hours of usage and the system will force users to do Pixel Clear then for protecting the OLED panel.
  • Page 42: Chapter 7 Troubleshooting

    Chapter 7 Troubleshooting Problem and Question Possible Solution • Check if the Power button is pressed and the Power LED is not on monitor is power on. • Power Cord should be connected. • Check that the video cable is properly connected. If the connector is loose, tighten the connector’s No signal screws.
  • Page 43: Chapter 8 Safety Instructions

    • Place the power cord in a way that people are unlikely to step on it. Do not place anything on the power cord. • If this device comes with an adapter, use only the ASRock provided AC adapter approved for use with this device.
  • Page 44: European Union

    European Union: Batteries, battery packs, and accumulators should not be disposed of as unsorted household waste. Please use the public collection system to return, recycle, or treat them in compliance with the local regulations. California, USA: The button cell battery may contain perchlorate material and requires special handling when recycled or disposed of in California.
  • Page 45 Environment • To reduce the possibility of heat-related injuries or of overheating the device, do not place the device on a soft, unsteady surface or obstruct its air ventilators. • Use this device only on a hard, flat and steady surface. •...
  • Page 46: Technical Support

    (2009/125/EC) and RoHS directive (2011/65/EU). This product has been tested and found to comply with the harmonized standards for Information Technology Equipment published under Directives of Official Journal of the European Union. ASRock Contact Information ASRock EUROPE B.V. Address : Bijsterhuizen 11-11, 6546 AR Nijmegen,The Netherlands...
  • Page 47: Fcc-B Radio Frequency Interference Statement

    FCC-B Radio Frequency Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 48 ASRock Contact Information ASRock America, Inc. Address : 13848 Magnolia Ave, Chino, CA91710, U.S.A. Phone: +1-909-590-8308 Technical Support Phone: +1-909-590-8308 Online Support https://event.asrock.com/tsd.asp...
  • Page 49: Weee Statement

    Chemical Substances Information In compliance with chemical substances regulations, such as the EU REACH Regulation (Regulation EC No. 1907/2006 of the European Parliament and the Council), ASRock provides the relevant information at: https://asrock.com/general/about.asp?cat=Responsibility RoHS Statement Japan JIS C 0950 Material Declaration...
  • Page 50: Copyright And Trademarks Notice

    Copyright and Trademarks Notice Copyright © ASRock Inc. All rights reserved. The ASRock logo used is a registered trademark of ASRock Inc. All other marks and names mentioned may be trademarks of their respective owners. No warranty as to accuracy or completeness is expressed or implied.
  • Page 51: Copyright Notice

    ASRock’s website without further notice. If you require technical support related to this monitor, please visit our website for specific information about the model you are using. You may find the latest monitor support list on ASRock’s website as well.
