Summary of Contents for ASROCK PG25FFT

  • Page 2: Table Of Contents

    Contents Chapter 1 Introduction Package Contents Chapter 2 Setting up the Monitor Attaching the Stand Arm and Base Detaching the Stand Arm and Base Making Connections Adjusting the Viewing Angle Using the Security Slot Chapter 3 Monitor Overview Front View Back View Bottom View Chapter 4 Specifications...

  • Page 3: Chapter 1 Introduction

    Chapter 1 Introduction Thank you for purchasing PG25FFT, a reliable monitor produced under ASRock’s consistently stringent quality control. It delivers excellent performance with robust design conforming to ASRock’s commitment to quality and endurance. 1.1 Package Contents Your monitor ships with the components shown below. Please make sure that you have...

  • Page 4: Chapter 2 Setting Up The Monitor

    Chapter 2 Setting up the Monitor 2.1 Attaching the Stand Arm and Base Step 1. Installing the Stand Arm • Leave the monitor in its protective foam packaging. ⚠ Important Place the monitor in its protective foam packaging, or on a soft, protected surface to avoid scratching the display screen.
  • Page 5 Step 2. Installing the Stand Base Insert the stand base to the stand arm and make sure it is securely installed. Step 3. Placing the Monitor Upright Lift the monitor carefully out of the foam packaging and into its upright position on a flat, stable surface.

  • Page 6: Detaching The Stand Arm And Base

    2.2 Detaching the Stand Arm and Base Before removing the stand, be sure to turn off the monitor and disconnect all cables. Press and hold the stand release button and pull to disengage the tabs on the stand arm from the monitor. Remove the stand (arm and base). Press and hold the quick release tab at the bottom of the base and remove the stand base from the stand arm.

  • Page 7: Making Connections

    2.3 Making Connections Connecting the Power Cord Connect the power cord to the monitor and to an electrical wall outlet. ⚠ Important Please make sure to make a grounding connection before connecting the power plug to the power source. Additionally, when disconnecting the grounding connection, be sure to discon- nect the power plug from the power source before proceeding.
  • Page 8 Connecting the Monitor to the PC / Laptop HDMI Connection Connect one end of the HDMI cable to the HDMI connector on the rear side of the monitor. Then connect the other end to the HDMI connector on the PC or laptop.
  • Page 9 DisplayPort Connection Connect one end of the DisplayPort cable to the DisplayPort input connector on the rear side of the monitor. Then connect the other end to the DisplayPort output connector on the PC or laptop. Pass the cable through the cable management hole on the stand arm.
  • Page 10 Audio Cable Connection You can connect headphones to the headphone jack on the bottom side of the monitor. Pass the cable through the cable management hole on the stand arm.

  • Page 11: Adjusting The Viewing Angle

    2.4 Adjusting the Viewing Angle Tilt Angle Adjustment For optimal viewing, it is recommended to look at the full face of the monitor, and then adjust the monitor’s angle to your own preference. Hold the stand firmly with one hand while tilting the monitor forwards or backwards with the other hand so you do not topple the monitor when you adjust the monitor’s angle.

  • Page 12: Using The Security Slot

    2.5 Using the Security Slot This monitor supports a Kensington-type security slot. The Kensington lock can be used to secure the monitor and prevent it from being stolen in public locations. NOTE: Kensington lock is not included. You need to purchase an additional locking device.

  • Page 13: Chapter 3 Monitor Overview

    Chapter 3 Monitor Overview 3.1 Front View Item Display screen ⚠ Important Do not touch the display screen surface with sharp or hard objects.

  • Page 14: Back View

    3.2 Back View Item Description Press to turn the monitor on. Press and hold for 3 seconds to turn the monitor off. The color definition of the power indicator: Power On/Off button • Solid Blue - Power on mode • Flashing Blue - Standby mode •...

  • Page 15: Bottom View

    3.3 Bottom View Item Description AC-IN port Connect the power cord. HDMI 1 port Connect your computer with the HDMI cable. HDMI 2 port Connect your computer with the HDMI cable. DisplayPort Connect your computer with the DisplayPort cable. Connect your headphones with the audio cable. Audio output (Purchase separately)

  • Page 16: Chapter 4 Specifications

    Chapter 4 Specifications 4.1 Monitor Specifications Model PG25FFT Panel Size 24.5" Viewing Area 543.744(H) x 302.616(V) Aspect Ratio 16:9 Panel Type Viewing Angle 178°(H) / 178°(V) (Typ.) Resolution FHD (1,920 x 1,080) Pixel Pitch 0.2802 (mm) Curvature Flat Refresh Rate...
  • Page 17 Power Consumption (Max) ≦ 36W Power Saving Mode ≦ 0.5 W Power Consumption Power Off Mode ≦ 0.3 W Voltage 100~240Vac, 50/60Hz, 1.2A Tilt Adjustment -5°~+20° Mechanical 100x100 mm (4 screw holes) Design VESA Mount M4*12 mm Dimension with Stand 557 x 432 x 205 (mm) Dimension (W x H x D)

  • Page 18: Supported Timing List

    4.2 Supported Timing List Standard Mode HDMI DisplayPort IBM MODE DOS 720x400 @70Hz 640x480 @60Hz 640x480 @67Hz 640x480 @72Hz 640x480 @75Hz 800x600 @56Hz 800x600 @60Hz SVGA 800x600 @72Hz 800x600 @75Hz 832x624@75Hz 1024x768 @60Hz 1024x768 @70Hz 1024x768 @75Hz 1280x1024 @60Hz SXGA 1280x1024 @75Hz WXGA 1280x800 @60Hz...
  • Page 19 640x480P 59.94/60Hz 4:3 720x480P 59.94/60Hz 16:9 720x576P 50Hz 16:9 1280x720P 50Hz 16:9 Video Timing 1280x720P 59.94/60Hz 16:9 Resolution 1920x1080p 50Hz 16:9 1920x1080P 59.94/60Hz 16:9 1920x1080P 119.88/120Hz 16:9/1:1 2160P @60Hz...

  • Page 20: Chapter 5 Operating The Monitor

    Chapter 5 Operating the Monitor 5.1 Powering On/Off the Monitor Press the Power button to turn on the monitor. The power indicator lights up in solid blue to show that the monitor is ON. To turn the monitor off, press and hold the Power button about 3 seconds until the LED light on the Power button turns OFF.

  • Page 21: Using The Joystick Control

    5.2 Using the Joystick Control Use the joystick on the rear side of the monitor to navigate the OSD menu and adjust the settings. To access the OSD menu, press the joystick button to launch the OSD main menu. Use the joystick to toggle between options. Press the joystick button again to confirm the settings and exit.
  • Page 22 Action Description When the OSD menu is ON, press to confirm Press the selection (Enter) or save the settings (OK). Toggle left to select menu items (Move), go back to the previous menu (Back) or exit the Toggle Left OSD menu (Exit) Decreases the parameters of the selected menu item (Adjust).

  • Page 23: Chapter 6 Osd Setup

    Chapter 6 OSD Setup This chapter provides you with essential information on OSD Setup. ⚠ Important All information is subject to change without prior notice. 6.1 Accessing the OSD Menu After you press the joystick button, the OSD menu appears on the lower right corner of your monitor screen.

  • Page 24: Osd Menus

    6.2 OSD Menus Function: Picture Picture Colo Audio Gaming Low Blue Light System Information Main Menu Item Sub Menu Item Sub Menu Description Picture Modes Standard Users can choose the preferred picture mode based on the usage scenarios, including Standard, Graphics ECO, Graphics, HDR, Action, Racing, Sports and User modes.
  • Page 25 Black Boost 0-10 The higher the level, the more detailed the dark area. Low Blue Light Low Blue Light Technology reduces the emission of harmful blue lights on a display to prevent eye fatigue. Enables users to set the DCR (Dynamic Contrast Ratio) On or Off.
  • Page 26 Function: Color Mode - Standard Picture Gamma Colo Color Space Standard Color Temp. Warm Audio R Gain Gaming G Gain B Gain System Information Exit Enter Move Main Menu Item Sub Menu Item Sub Menu Description Color Gamma Allows users to adjust the luminance tone.
  • Page 27 Function: Audio Mode - Standard Picture Volume Colo Mute Audio Gaming System Information Exit Enter Move Main Menu Item Sub Menu Item Sub Menu Description Audio Volume 0-100 Adjust the volume level. Mute Allows users to enable or disable the mute function.
  • Page 28 Function: Gaming Mode - Standard Over Drive Normal Picture Adaptive-Sync Colo MPRT Audio Refresh Rate Num Gaming Aim Point System Information Exit Enter Move Main Menu Item Sub Menu Item Sub Menu Description Gaming Over Drive Boosts response time with Over Drive technology.
  • Page 29 Function: OSD Mode - Standard Language English Picture OSD Timeout Colo Transparency Audio Gaming System Information Exit Enter Move Main Menu Item Sub Menu Item Sub Menu Description Language ─ Select the OSD language. OSD Timeout 10-120 Adjusts the OSD timeout from 10 to 120 seconds.
  • Page 30 Function: System Mode - Standard Input HDMI1 Picture Auto Source Colo Wide Mode Full Audio DDC/CI Gaming Quick Start Mode System Information Exit Enter Move Main Menu Item Sub Menu Item Sub Menu Description System Input Select input source. HDMI Auto Source Turn On / Off auto source retrieval.

  • Page 31: Function: Information

    Function: Information Mode - Standard Main Source HDMI1 Picture Resolution 1920x1080 Colo H/V Frequency H:67KHz V:60Hz Audio Mode Normal Gaming Series Number Reset All Settings System Information Move Exit Enter Main Menu Item Sub Menu Item Sub Menu Description Information Main Source ─...

  • Page 32: Chapter 7 Troubleshooting

    Chapter 7 Troubleshooting Problem and Question Possible Solution • Check if the Power button is pressed and the Power LED is not on monitor is power on. • Power Cord should be connected. • Check that the video cable is properly connected. If the connector is loose, tighten the connector’s No signal screws.

  • Page 33: Chapter 8 Safety Instructions

    • Place the power cord in a way that people are unlikely to step on it. Do not place anything on the power cord. • If this device comes with an adapter, use only the ASRock provided AC adapter approved for use with this device.
  • Page 34 Environment • To reduce the possibility of heat-related injuries or of overheating the device, do not place the device on a soft, unsteady surface or obstruct its air ventilators. • Use this device only on a hard, flat and steady surface. •...

  • Page 35: Technical Support

    (2011/65/EU). This product has been tested and found to comply with the harmonized standards for Information Technology Equipment published under Directives of Official Journal of the European Union. ASRock Contact Information ASRock EUROPE B.V. Address: Bijsterhuizen 11-11, 6546 AR Nijmegen,The Netherlands...

  • Page 36: Fcc-B Radio Frequency Interference Statement

    FCC-B Radio Frequency Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 37 ASRock Contact Information ASRock America, Inc. Address: 13848 Magnolia Ave, Chino, CA91710, U.S.A. Phone: +1-909-590-8308 Technical Support Phone: +1-909-590-8308 Online Support https://event.asrock.com/tsd.asp...

  • Page 38: Weee Statement

    Chemical Substances Information In compliance with chemical substances regulations, such as the EU REACH Regulation (Regulation EC No. 1907/2006 of the European Parliament and the Council), ASRock provides the relevant information at: https://asrock.com/general/about.asp?cat=Responsibility RoHS Statement Japan JIS C 0950 Material Declaration...

  • Page 39: Copyright And Trademarks Notice

    Copyright and Trademarks Notice Copyright © ASRock Inc. All rights reserved. The ASRock logo used is a registered trademark of ASRock Inc. All other marks and names mentioned may be trademarks of their respective owners. No warranty as to accuracy or completeness is expressed or implied.

  • Page 40: Copyright Notice

    ASRock’s website without further notice. If you require technical support related to this motherboard, please visit our website for specific information about the model you are using. You may find the latest monitor support list on ASRock’s website as well.
