In case any modifications of this documentation occur, the updated version will be available on ASRock’s website without further notice. If you require technical support related to this motherboard, please visit our website for specific information about the model you are using.
Chapter 1 Introduction Thank you for purchasing PG27FF1A, a reliable monitor produced under ASRock’s consistently stringent quality control. It delivers excellent performance with robust design conforming to ASRock’s commitment to quality and endurance. 1.1 Package Contents • ASRock PG27FF1A Monitor Head •...
1.2 Installation Instructions Leave the monitor in its protective foam packaging. Align the latches of the stand to the monitor. Tighten the stand with screws. Connect the stand base to the stand and tighten the screw to secure the stand base. Align the latches to place the stand cover.
Chapter 4 Adjusting the Viewing Angle For optimal viewing, it is recommended to look at the full face of the monitor, and then adjust the monitor’s angle to your own preference. Hold the stand so you do not topple the monitor when you adjust the monitor’s angle.
Chapter 5 Connecting the Monitor Turn off your computer. Connect the video cable from the monitor to your computer. Connect the power cord to the monitor power jack. (Figure A) Plug the power cord into the electrical outlet. (Figure B) Turn on the monitor.
Chapter 6 OSD Setup This chapter provides you with essential information on OSD Setup. ⚠ Important All information is subject to change without prior notice. 6.1 OSD Keys The monitor comes with OSD Keys that help navigate the On-Screen Display (OSD) menu.
6.2 OSD Menus (The descriptions for function control) Function: Luminance Main Menu Sub Menu Sub Menu Description Item Item Luminance Contrast Contrast from Digital- 0-100 register. Brightness Backlight Adjustment 0-100 Standard Standard Mode Text Text Mode Internet Internet Mode Preset Modes Game Game Mode...
Page 21
Function: Image Setup Main Menu Sub Menu Sub Menu Description Item Item Image Image Ratio Wide Select Image Aspect Setup Ratio Overdrive Adjustment FreeSync FreeSync Premium On Premium or Off Auto HDR Auto or Off...
Page 22
Function: Color Temp. Main Menu Sub Menu Sub Menu Description Item Item ─ Color Temp. Recall Warm Color Warm Temperature from EEPROM. ─ Recall Normal Color Temperature from Normal EEPROM. ─ Recall Cool Color Cool Temperature from EEPROM. Red Gain from Digital- register.
Page 23
Function: OSD Setup Main Menu Sub Menu Sub Menu Description Item Item OSD Setup 0-100 Adjust the horizontal H. Position position of OSD 0-100 Adjust the vertical V. Position position of OSD 5-100 Adjust the OSD Timeout Timeout Select the OSD ─...
Page 24
Function: Extra Main Menu Sub Menu Sub Menu Description Item Item Extra Auto Select input source HDMI1 Input Select HDMI2 DisplayPort Turn ON/OFF DDC/CI DDC/CI On or Off Support Reset the menu to Yes or No Reset default. Show the information ─...
Chapter 7 Troubleshooting Problem and Possible Solution Question Power LED is not on • Check if the Power Switch is in the ON position. • Power Cord should be connected. • Check that the signal-cable is properly connected. If the connector is No signal loose, tighten the connector’s screws.
• Place the power cord in a way that people are unlikely to step on it. Do not place anything on the power cord. • If this device comes with an adapter, use only the ASRock provided AC adapter approved for use with this device.
Page 27
Environment • To reduce the possibility of heat-related injuries or of overheating the device, do not place the device on a soft, unsteady surface or obstruct its air ventilators. • Use this device only on a hard, flat and steady surface. •...
Page 28
(2011/65/EU). This product has been tested and found to comply with the harmonized standards for Information Technology Equipment published under Directives of Official Journal of the European Union. ASRock Contact Information ASRock EUROPE B.V. Address : Bijsterhuizen 11-11, 6546 AR Nijmegen,The Netherlands...
Page 29
This device may not cause harmful interference, and This device must accept any interference received, including interference that may cause undesired operation. ASRock Contact Information ASRock America, Inc. Address : 13848 Magnolia Ave, Chino, CA91710, U.S.A. Phone: +1-909-590-8308...
Page 30
Chemical Substances Information In compliance with chemical substances regulations, such as the EU REACH Regulation (Regulation EC No. 1907/2006 of the European Parliament and the Council), ASRock provides the information of chemical substances in products at: RoHS Statement...
