PGO32UFS
User Manual
Version 1.0
Published December 2023
Copyright©2023 ASRock INC. All rights reserved.

Advertisement

loading
Need help?

Need help?

Do you have a question about the PGO32UFS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ASROCK PGO32UFS

Summary of Contents for ASROCK PGO32UFS

  • Page 1 PGO32UFS User Manual Version 1.0 Published December 2023 Copyright©2023 ASRock INC. All rights reserved.

  • Page 2: Table Of Contents

    Contents Chapter 1 Introduction Package Contents Chapter 2 Setting up the Monitor Attaching the Stand Arm and Base Detaching the Stand Arm and Base Making Connections Adjusting the Viewing Angle Using the Security Slot Chapter 3 Monitor Overview Front View Rear View Bottom View Chapter 4 Specifications...
  • Page 3 Chapter 7 Troubleshooting Chapter 8 Safety Instructions...

  • Page 5: Chapter 1 Introduction

    Chapter 1 Introduction Thank you for purchasing PGO32UFS, a reliable monitor produced under ASRock’s consistently stringent quality control. It delivers excellent performance with robust design conforming to ASRock’s commitment to quality and endurance. 1.1 Package Contents Your monitor ships with the components shown below. Please make sure that you have...

  • Page 6: Chapter 2 Setting Up The Monitor

    Chapter 2 Setting up the Monitor 2.1 Attaching the Stand Arm and Base Step 1. Installing the Stand Base • Leave the monitor in its protective foam packaging. ⚠ Important Place the monitor in its protective foam packaging, or on a soft, protected surface to avoid scratching the display screen.

  • Page 7: Step 2. Installing The Monitor Stand

    Step 2. Installing the Monitor Stand • Align and slide the two tabs on the stand arm to the groove on the back of the monitor until it snaps into place. • Push the stand lock to the locked position to ensure the stability. LOCK...
  • Page 8 Step 3. Placing the Monitor Upright Lift the monitor carefully out of the foam packaging and into its upright position on a flat, stable surface. ⚠ Important Be careful not to touch or press the display screen areawhen lifting or moving the monitor to avoid any scratches or damage.

  • Page 9: Detaching The Stand Arm And Base

    2.2 Detaching the Stand Arm and Base Before removing the stand, be sure to turn off the monitor and disconnect all cables. Push the stand lock to the unlock position. Lift upward to disengage the tabs on the stand arm from the monitor. Remove the stand (arm and base). UNLOCK Release the screw at the bottom of the stand base.

  • Page 10: Making Connections

    2.3 Making Connections Connecting the Power Cord Pass the cable of the power adaptor through the cable management hole on the stand arm. Connect the power adaptor to the monitor and to the power cord. Connect the power cord to an electrical wall outlet. ⚠...
  • Page 11 Connecting the Monitor to the PC / Laptop HDMI Connection Connect one end of the HDMI cable to the HDMI connector on the rear side of the monitor. Then connect the other end to the HDMI connector on the PC or laptop. Pass the cable through the cable management hole on the stand arm.
  • Page 12 DisplayPort Connection Connect one end of the DisplayPort cable to the DisplayPort input connector on the rear side of the monitor. Then connect the other end to the DisplayPort output connector on the PC or laptop. Pass the cable through the cable management hole on the stand arm.
  • Page 13 USB Type-B Connection (to Host) Connect the USB type-B end of the USB cable to the USB type-B upstream port on the rear side of the monitor. Then connect the other end of the cable to USB port on your PC or laptop.
  • Page 14 USB Type-A Connection (to Device) Use the Type-A downstream port(s) on the rear side of the monitor to connect to your USB devices, such as a USB keyboard, a USB mouse, a USB portable hard drive, or a USB flash drive.
  • Page 15 USB Type-C Connection (for Display and Power Delivery) The type-C port on the rear side of the monitor is compatible with the DP Alt mode and USB power delivery. Use a Type-C cable to connect the monitor to your laptop for an external display. You can also connect it to our smartphones or tablets to mirror your device's screen on the monitor, enabling you to share videos and photos with others.
  • Page 16 Audio Cable Connection You can connect headphones to the headphone jack on the bottom side of the monitor. Pass the cable through the cable management hole on the stand arm.
  • Page 17 Antenna Cable Connection This monitor has a built-in Wi-Fi antenna. Placed on the table, the integrated antenna on the back of the monitor provides great Wi-Fi connectivity up to 7dBi peak gain. If your motherboard comes with built-in Wifi, use the provided antenna cables to turn your monitor a powerful wireless antenna.

  • Page 18: Adjusting The Viewing Angle

    2.4 Adjusting the Viewing Angle The monitor adopts an ergonomically-designed stand. It offers swivel, tilt, and height adjustments, which give gamers more flexibility to find an optimal viewing position. Tilt Angle Adjustment For optimal viewing, it is recommended to look at the full face of the monitor, and then adjust the monitor’s angle to your own preference.
  • Page 19 Height Adjustment You can lower or raise the monitor to the desired height. 100mm Swivel Adjustment Swivel the monitor to the left or right for the desired viewing angle. ⚠ Important Be careful not to touch or press the display screen area when adjusting the monitor.

  • Page 20: Using The Security Slot

    2.5 Using the Security Slot This monitor supports a Kensington-type security slot. The Kensington lock can be used to secure the monitor and prevent it from being stolen in public locations. NOTE: Kensington lock is not included. You need to purchase an additional locking device.

  • Page 21: Chapter 3 Monitor Overview

    Chapter 3 Monitor Overview 3.1 Front View Item Description Display screen The display part of a monitor The color definition of the power indicator: • Solid White - Power on mode • Solid Orange - Standby mode (no signal input) •...

  • Page 22: Rear View

    3.2 Rear View Item Description Press to turn the monitor on. Press and hold for 3 seconds to turn the monitor off. The color definition of the power indicator: Power On/Off button • Solid White - Power on mode • Solid Orange - Standby mode •...
  • Page 23 There are vents on the back of the monitor for Air vent heat dissipation and ventilation. The RGB LED backlights enhance gaming and movie watching experiences. You can adjust LED Backlights the lighting in the OSD menu: Select "System" > "Lighting".

  • Page 24: Bottom View

    3.3 Bottom View 10 11 Item Description Connect the USB cable from the host (your USB 3.2 Gen1 Type-B computer) to the monitor when using the USB hub Port (upstream) function. Connect the USB cable from the keyboard, mouse, USB 3.2 Gen1 Type-A etc.
  • Page 25 HDMI1 Input Connect your computer with the HDMI cable. HDMI2 Input Connect your computer with the HDMI cable. DisplayPort1 Input Connect your computer with the DisplayPort cable. DisplayPort2 Input Connect your computer with the DisplayPort cable. USB 3.2 Gen1 Type-C Connect the USB cable from your laptop, Port smartphone or tablet for external display and...

  • Page 26: Chapter 4 Specifications

    Chapter 4 Specifications 4.1 Monitor Specifications Model PGO32UFS Panel Size 32" Viewing Area 697 x 391 mm (H x V) Aspect Ratio 16:9 Panel Type WOLED Viewing Angle 178°(H) / 178°(V) Resolution UHD (3840 x 2160) Pixel Pitch 0.1814mm Curvature...
  • Page 27 Power Consumption (Max) ≦ 235W Power Saving Mode ≦ 0.5 W Power Power Off Mode ≦ 0.3 W Consumption 100~240VAC, 50/60Hz, Voltage (Adapter 240W) Tilt Adjustment -7° ~ +20° Swivel Adjustment -20° ~ +20° Mechanical Height Adjustment 0~100 mm Design 100 x 100 mm (4 screw holes) VESA Mount M4 x 12 mm...

  • Page 28: Supported Timing List

    4.2 Supported Timing List PGO32UFS Standard Resolution HDMI 640x480 @60Hz 640x480 @67Hz 640x480 @72Hz 640x480 @75Hz 800x600 @56Hz 800x600 @60Hz SVGA 800x600 @72Hz 800x600 @75Hz 1024x768 @60Hz 1024x768 @70Hz 1024x768 @75Hz 1280x1024 @60Hz SXGA 1280x1024 @75Hz WXGA+ 1440x900 @60Hz WSXGA+...
  • Page 29 640x480P 59.94/60Hz 4:3 720x480P 59.94/60Hz 4:3 720x480P 59.94/60Hz 16:9 720x576P 50Hz 4:3 720x576P 50Hz 16:9 Video Timing Resolution 1280x720P 50Hz 16:9 1280x720P 59.94/60Hz 16:9 1920x1080p 50Hz 16:9 1920x1080P 59.94/60Hz 16:9 1920x1080P 119.88/120Hz 16:9/1:1...

  • Page 30: Chapter 5 Operating The Monitor

    Chapter 5 Operating the Monitor 5.1 Powering On/Off the Monitor Press the Power button (at the top most position) to turn on the monitor. The power indi- cator on the bottom edge of the monitor lights up in solid white to show that the monitor is ON.

  • Page 31: Hot Keys

    5.2 Hot Keys When the OSD screen is off, press the control buttons on the rear side of the monitor to access the OSD menu, change the preset mode, or adjust the brightness. The labels on the side of the monitor correspond to the buttons on the back. Icon Hot Key (When OSD is OFF) POWER...

  • Page 32: Using The Joystick Control

    5.3 Using the Joystick Control When the OSD screen is on, use the joystick on the rear side of the monitor to navigate the OSD menu and adjust the settings. To access the OSD menu, press the joystick button to launch the OSD main menu. Move the joystick up/down/left/right to toggle between options.
  • Page 33 Toggle right to select menu items or go to the next menu (Move). Toggle Right Increases the parameters of the selected menu item (Adjust). Toggle Up Toggle up to select menu items (Move). Toggle Down Toggle down to select menu items (Move).

  • Page 34: Chapter 6 Osd Setup

    Chapter 6 OSD Setup This chapter provides you with essential information on OSD Setup. ⚠ Important All information is subject to change without prior notice. 6.1 Accessing the OSD Menu After you press the Menu button, the OSD menu appears on the lower right corner of your monitor screen.

  • Page 35: Osd Menus

    6.2 OSD Menus Function: Input Select DisplayPort1 3840x2160 59.8 Hz Standard Input Select HDMI1 Image Setup HDMI2 Picture DisplayPort1 Gaming DisplayPort2 Type C Audio System Down Right Left Enter Main Menu Item Sub Menu Item Description Input Select HDMI1 Select an available input source. HDMI2 DisplayPort1 DisplayPort2...
  • Page 36 Function: Image Setup DisplayPort1 3840x2160 59.8 Hz Standard Input Select Standard Image Setup sRGB Picture FPS Game Gaming RTS Game MOBA Game Audio Movie System Internet Down Right Left Enter Main Menu Item Sub Menu Item Description Image Setup Standard This scene mode is for document editing.
  • Page 37 Function: Picture DisplayPort1 3840x2160 59.8 Hz Standard Input Select Brightness Image Setup Contrast Picture Aspect Gaming Sharpness Dark Boost Audio Peak Brightness System Color Temp. Down Right Left Enter Main Menu Item Sub Menu Item Sub Menu Description Picture Brightness 0-100 Brightness adjusts the luminance of the backlight.
  • Page 38 Color Temp. Cold Select the color temperature. Cool Normal Warm User Color 0-100 Customize the color temperature by adjusting the Green 0-100 red (R), green (G), or blue (B) level Blue 0-100 according to your preference. 6-axis Color 0-100 Adjust the tint of each color (red, Green 0-100...
  • Page 39 Function: Gaming DisplayPort1 3840x2160 59.8 Hz Standard Input Select DFR Mode Image Setup FreeSync Picture Game Assist Gaming Audio System Down Right Left Enter Main Menu Item Sub Menu Item Sub Menu Description Gaming DFR Mode Enables users to set the DFR (Dynamic Frequency and Resolution) On or Off.
  • Page 40 Function: KVM DisplayPort1 3840x2160 59.8 Hz Standard Input Select Source 1 HDMI1 Image Setup Source 2 HDMI2 Picture DisplayPort1 Gaming DisplayPort2 Type C Audio System Down Right Left Enter Main Menu Item Sub Menu Item Sub Menu Description ─ Disables the KVM feature.
  • Page 41 Function: Audio DisplayPort1 3840x2160 59.8 Hz Standard Input Select Volume Image Setup Audio Mute Picture Gaming Audio System Down Right Left Enter Main Menu Item Sub Menu Item Sub Menu Description Audio Volume 0-100 Adjust the volume level. Audio Mute Enables the mute function.
  • Page 42 Function: System DisplayPort1 3840x2160 59.8 Hz Standard Input Select Language English Image Setup Resolution Русский Picture PIP / PBP Deutsch Gaming OLED Care Français Lighting Español Audio Information Italiano System USB-Update Nederlands Down Right Left Enter Main Menu Sub Menu Sub Menu Description Item...
  • Page 43 System PIP / PBP Display Switch Use this item to switch the main source and sub source. The sub source is displayed in the sub screen by default. Audio HDM1 Select the second audio Switch source under the PIP HDMI2 mode.
  • Page 44 System OLED Care Screen Enable the Screen Move Move feature to shift the position of the image on your screen slightly at regular intervals and protect your screen from burn-in. Logo Enable the Logo Auto Auto Dimming feature to Dim- automatically adjust the ming brightness of static logos...
  • Page 45 System Menu Enable or disable the Transparency OSD menu transparency feature. LED Indicator Enable or disable the LED Control Indicator Control feature. Auto Power Enable or disable the Auto Power off feature. Timed 30 Minutes Turn on the timed Shutdown shutdown, and the display 45 Minutes will be automatically...

  • Page 46: Chapter 7 Troubleshooting

    Chapter 7 Troubleshooting Problem and Question Possible Solution • Check if the Power button is pressed and the Power LED is not on monitor is power on. • Power Cord should be connected. • Check that the video cable is properly connected. If the connector is loose, tighten the connector’s No signal screws.

  • Page 47: Chapter 8 Safety Instructions

    • Place the power cord in a way that people are unlikely to step on it. Do not place anything on the power cord. • If this device comes with an adapter, use only the ASRock provided AC adapter approved for use with this device.

  • Page 48: European Union

    European Union: Batteries, battery packs, and accumulators should not be disposed of as unsorted household waste. Please use the public collection system to return, recycle, or treat them in compliance with the local regulations. California, USA: The button cell battery may contain perchlorate material and requires special handling when recycled or disposed of in California.
  • Page 49 Environment • To reduce the possibility of heat-related injuries or of overheating the device, do not place the device on a soft, unsteady surface or obstruct its air ventilators. • Use this device only on a hard, flat and steady surface. •...

  • Page 50: Technical Support

    (2009/125/EC) and RoHS directive (2011/65/EU). This product has been tested and found to comply with the harmonized standards for Information Technology Equipment published under Directives of Official Journal of the European Union. ASRock Contact Information ASRock EUROPE B.V. Address: Bijsterhuizen 11-11, 6546 AR Nijmegen, The Netherlands...
  • Page 51 FCC-B Radio Frequency Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 52 ASRock Contact Information ASRock America, Inc. Address: 13848 Magnolia Ave, Chino, CA91710, U.S.A. Phone: +1-909-590-8308 Technical Support Phone: +1-909-590-8308 Online Support https://event.asrock.com/tsd.asp...
  • Page 53 Chemical Substances Information In compliance with chemical substances regulations, such as the EU REACH Regulation (Regulation EC No. 1907/2006 of the European Parliament and the Council), ASRock provides the relevant information at: https://asrock.com/general/about.asp?cat=Responsibility RoHS Statement Japan JIS C 0950 Material Declaration...

  • Page 54: Copyright And Trademarks Notice

    Copyright and Trademarks Notice Copyright © ASRock Inc. All rights reserved. The ASRock logo used is a registered trademark of ASRock Inc. All other marks and names mentioned may be trademarks of their respective owners. No warranty as to accuracy or completeness is expressed or implied.

  • Page 55: Copyright Notice

    ASRock’s website without further notice. If you require technical support related to this monitor, please visit our website for specific information about the model you are using. You may find the latest monitor support list on ASRock’s website as well.
