About optional equipment

Other operations

Connecting portable audio
players to the AUX jack
Use an accessory cord commonly available. With
the RCA connector to connect a portable audio
players and other external inputs can be
connected to the system.
There are 2 connection terminals on this main
unit; one for RCA connector and the other for
optional LAN cable (AUX 105).
Turn on the portable audio player
1
and start its play function.
Switch to AUX mode by pressing
2
the [DISC] button for more than
one second.
Activation of the AUX mode will light
the "AUX" indicator and channel
audio player output to the system
speakers.
Press the button [3] to switch the
3
AUX mode.
Each time the button is pressed, the
mode will switch as follows:
AUX1(Input) ↔ AUX1(Sub Input)
ATTENTION
• While the AUX mode is activated, actions
such as turning off the audio player or pulling
out the connection cord may cause noise
spikes that can damage the system speakers.
Be sure to avoid this possibility by turning off
system power or switching from the AUX
mode to another mode before shutting off or
disconnecting the portable audio player.
• Audio output levels will differ for the various
devices that can be connected by this
method. Carefully adjust volume until the
output level of the connected player is known.
• Before using a portable audio player in a
vehicle, read the player's operation manual
carefully and confirm problem-free operation
in the vehicle before proceeding.
86

Changing auxiliary input sensitivity

The sensitivity of the auxiliary mode can be
changed.
1
Press the [FUNC] button.
The function mode is activated.
Turn the [SEL] button to select
2
AUX Sensitivity.
Only in the AUX mode.
3
Press the [SEL] button.
The AUX sensitivity
activated.
Turn the [SEL] button to select the
4
sensitivity mode.
Turning the button allows you to
toggle through sensitivity modes as
follows:
Low ➔ Mid ➔ Hi ➔ Low
ATTENTION
Input sensitivity modes are roughly as follows:
Low
Mid
Hi
5
Press the [SEL] button.
The selected settings will take effect.
6
Press the [RTN] button.
At this time, other adjustments can
also be mode in function mode.
Press the [FUNC] or [RTN] button
7
to exit function mode.
mode is
1 Vrms
480 mVrms
240 mVrms
