Various Settings

Reading the AREA SHOT data

The AREA SHOT
downloaded from E-iSERV (web site) to a CD-R
or Memory Stick can be loaded into the main unit
and saved there.
1
Press the [FUNC] button.
The function mode is activated.
Turn the [SEL] button to select
2
AreaShot.
Turn the [SEL] switch to select
3
media types.
When the button is turned, the setting
item changes in the following order.
➔
Disc ➔ Memory Stick
4
Press the [SEL] button.
• When using a CD-R:
The front panel opens automatically and, if
a CD has already been loaded into the
deck, it will automatically eject.
• When using a Memory Stick:
If the Memory Stick containing the images
is not inserted, the front panel opens
automatically.
Insert the CD-R or Memory Stick to
5
be used for reading the Area Shot
data.
Press the [ ] button to close the
6
front panel.
If a CD-R has been inserted, the panel
closes automatically.
After the panel is closed, files in the
CD-R are read. While files are being
read, the [READING...]
appears. If there are incorrect files on
the CD-R, "No DATA" is displayed.
Turn the [SEL] button to select the
7
saving file.
The selected file name is highlighted.
44
data that has been
message
8
Press the [SEL] button.
The selected file will be saved.
"READING" is displayed while data
are being imported. When reading has
finished, [Completed] will appear on
the display and then it will return to the
display for selecting the function
mode.
