ADJUSTMENTS & RANGES
3 Band Parametric
Q ................................................................................0.5 to 2 (0.5 steps)
Level ................................................................. -6 to +6 dB (1 dB steps)
Bass Frequency................................
Mid ..............................................
Treble .........................................................
Digital Crossovers ................................................................................. 2-Way
High Pass (@ -12 dB/oct)
F1................200, 220, 250, 280, 315, 360, 400, 450, 500, 560, 630, 710, 800, 900, 1k
..........................1.2k, 1.4k, 1.6k, 1.8k, 2k, 2.2k, 2.5k, 2.8k, 3.2k, 3.6k, 4k, 4.5k, 5k Hz
F2.......... 50, 60, 70, 80, 90, 100, 110, 120, 130, 140, 150, 160, 170, 180, 190, 200 Hz
R ........... 50, 60, 70, 80, 90, 100, 110, 120, 130, 140, 150, 160, 170, 180, 190, 200 Hz
Low Pass (@ -12 dB/oct)
F2................200, 220, 250, 280, 315, 360, 400, 450, 500, 560, 630, 710, 800, 900, 1k
..........................1.2k, 1.4k, 1.6k, 1.8k, 2k, 2.2k, 2.5k, 2.8k, 3.2k, 3.6k, 4k, 4.5k, 5k Hz
...............................................................................Normal (Full Range)
High Pass (@ -12 dB/oct)
F2.......... 50, 60, 70, 80, 90, 100, 110, 120, 130, 140, 150, 160, 170, 180, 190, 200 Hz
R ........... 50, 60, 70, 80, 90, 100, 110, 120, 130, 140, 150, 160, 170, 180, 190, 200 Hz
Subwoofer (@ -12/-24 dB/oct)
........................... 50, 60, 70, 80, 90, 100, 110, 120, 130, 140, 150, 160, 170, 180, 190, 200 Hz
General
User Memory .......................................................................................2 Presets
PC Control Interface ................................................................................... USB
Pre-amp Control ........................................... Volume/Balance/Fader/Sub Level
Source Select ........................................................................ HU (Factory)/AUX
Remote Turn-on .............................................. Automatic Input Signal Sensing
Turn-off Delay .......................................................................... 5 minutes
Fc = 30, 40, 50, 60, 80, 100, 125, 150 Hz
Fc = 0.5, 0.75, 1.0, 1.5, 2.0, 3.0, 4.0, 5.0 kHz
Fc = 6, 7.5, 10, 12.5, 15, 17.5 kHz
