Time Delay Overview
MultEQ determines the default delay during initial Setup. However, there may be times
when the delay needs to be tweaked or temporarily modifi ed. Be advised, any changes
made causes deviation from MultEQ's default specs and no longer conforms to its ideal
sound stage. All channels have delays adjustable from 0 to 10ms in 0.1ms steps.
Time Delay
1. Press MODE twice to enter Custom Tuning mode.
2. With "PRESET 1" in the display, use the ▼ or ▲ buttons to choose the MIC position
to modify.
a) PRESET 1 refers to the Primary Mic position. PRESET 2 refers to the Second mic
position.
b) Upon making the Mic Position selection, use the
selection mode. The next parameter to modify (Crossover, or Time Delay) is
selected as described below.
* Use the
c) Use the ▼ or ▲ buttons to choose TIME DELAY.
d) Press the
e) Use the ▼ or ▲ buttons to select a Channel to modify (FRONT LEFT 1/RIGHT
1, FRONT LEFT 2/RIGHT 2, REAR LEFT,RIGHT, SUBWOOFER). Use the
button to return to the PRESET selection mode.
3. Time Correction
a) With the desired channel selected, press ENTER, to begin the adjustment.
b) Use the ▼ or ▲ buttons to change the delay (from 0 to 10ms) for each channel.
c) Upon completing the adjustment, press ENTER to exit back to the "TIME DELAY"
sub-menu.
d) If all "TIME DELAY" adjustments have been completed, use the
return to the PRESET selection mode. Press ENTER again to exit and save the
adjustments. Selecting "SAVE SETTINGS" stores changes in memory.
e) Use the MODE button at any point, to return to the previous sub-menu. to make
additional adjustments.
NOTES:
• Customization alters the MultEQ post-calibration settings. Doing this may or may not
result in an improvement of the overall sound quality.
• If setup includes a 2-Way output, the FRONT 1 High-pass and FRONT 2 Low-pass
cut-off frequencies should not be altered during customization. If these crossover
points must be changed, the MultEQ calibration must also be rerun.
button to return to the PRESET selection mode.
button to move to the Channel selection mode.
button to move to the next
button to
