PWD-CB1
Alpine ICE
In-Cooler Entertainment System
Assembly Manual
Introduction
Design and specifications are subject to change without notice for improvement
To Ensure Safe Use, Always Follow These Precautions
The installation of these parts require specialized skills and experience. We recommend that
you have the product installed by an Alpine authorized dealer.
Before you use this product, be sure to carefully read the separate user's manual so that you
can use the product correctly. Alpine Electronics bears no responsibility for problems that arise
as a result of failure to follow the instructions in the manual.
PWD-CB1
Alpine ICE
1/4
Advertisement
Table of Contents
Related Manuals for Alpine PWD-CB1
Summary of Contents for Alpine PWD-CB1
- Page 1 Before you use this product, be sure to carefully read the separate user’s manual so that you can use the product correctly. Alpine Electronics bears no responsibility for problems that arise as a result of failure to follow the instructions in the manual.
- Page 2 PWD-CB1 Warranty Exchange Policy Alpine Electronics of America, Inc. provides a one-year limited warranty for the PWD-CB1 speakers, control panel assembly, and amplifier assembly only. Any issues regarding the Grizzly Cooler, such as handles or latches should go directly to Grizzly at 800-553-0050.
- Page 3 Alpine ICE PWD-CB1 Tools Required Panel Removing Tool T20 Torx Removing Left Speaker Assembly 1) Remove (8) T20 torx screws. 2) Remove speaker grill 3) Pull entire speaker assembly 4) Disconnect speaker wire from speaker crossover. The entire assembly will now remove.
- Page 4 (6) clips behind panel. Note: it’s easiest to start on the angle toward the middle. DO NOT use a screwdriver. You will cause damage to the PWD-CB1. 2) Remove right speaker assembly (following instructions on page 3). 3) Remove amplifier assembly (following instructions above).
