PXA-H900
Multimedia Manager
Guide for Installation and Connections
Hinweise über die Installation und Anschlüsse
Guide d'installation et de connexions
Guía de instalación y conexiones
Guida all'installazione ed ai collegamenti
Vägledning för montering och anslutningar
R
TM
English
Deutsch
Français
Español
Italiano
Svenska

Advertisement

loading
Need help?

Need help?

Do you have a question about the PXA-H900 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Alpine PXA-H900

Summary of Contents for Alpine PXA-H900

  • Page 1 PXA-H900 Multimedia Manager English Guide for Installation and Connections Deutsch Hinweise über die Installation und Anschlüsse Français Guide d’installation et de connexions Español Guía de instalación y conexiones Italiano Guida all’installazione ed ai collegamenti Svenska Vägledning för montering och anslutningar...

  • Page 2: Precautions

    GUIDE FOR INSTALLATION AND CONNECTIONS • Please read this GUIDE FOR INSTALLATION AND CONNECTIONS and the OWNER’S MANUAL thoroughly to familiarize yourself with each control and function. We at ALPINE hope that your new PXA-H900 will give you many years of listening enjoyment.
  • Page 3 DO NOT USE BOLTS OR NUTS IN THE BRAKE OR STEERING SYSTEMS TO MAKE GROUND CONNECTIONS. Bolts or nuts used for the brake or steering systems (or any other safety-related system), or tanks should NEVER be used for installations or ground connections. Using such parts could disable control of the vehicle and cause fire etc.
  • Page 4 Precautions • Be sure to disconnect the cable from the (–) battery post before installing your PXA-H900. This will reduce any chance of damage to the unit in case of a short-circuit. • Be sure to connect the color coded leads according to the diagram. Incorrect connections may cause the unit to malfunction or damage to the vehicle’s electrical system.

  • Page 5: Table Of Contents

    • If you add an optional noise suppressor, connect it as far away from the unit as possible. Your Alpine dealer carries various noise suppressors. Contact them for further information. • Your Alpine dealer knows best about noise prevention measures so consult your dealer for further information.

  • Page 6: Accessories

    Accessories Terminal board Ai-NET cable Display cable Stand Microphone cover (6m) (6m) Connection Spacer Bracket Spare fuse Hexagonal Cable (15A) wrench (M2.6) Velcro tape for Velcro tape for Battery (AAA) Flanged self- Hexagon screw mounting mounting stand tapping screw (M4 x 10) remote control (M4 x 14) unit holder...

  • Page 7: Installation

    Installation • Mounting the display 1. Remove the face plate. Face plate 2. Use a screwdriver, etc., to slide the locking pin, then take out the inner case. Inner case Locking pin 3. Mount the display using the included screws. Bracket Spacer Display...
  • Page 8 < JAPANESE CAR > 1. After step 2 on page 7, remove the included side bracket. Side bracket Side bracket 2. Mount the display using the included screws. Bracket Spacer Display Pan head screw (M3 x 5) x 2 3. Mount the spacer and bracket to the display. Next, securely mount the factory brackets re- moved from the factory radio, to the display assembly.
  • Page 9 • Flush Mounting the display 1. Make a cut-out approximately 178 (width) by 50 (height) mm (7 inches by 2 inches) in size at your desired mounting location. WARNING: When making cut-outs, be careful not to damage pipes, tanks, electric wires, etc. Doing so could lead to accidents or fire.
  • Page 10 • Mounting the base unit 1. Decide on the installation location. • The trunk, etc., is the best place. 2. Mark the positions of the mounting screws at the chosen location. 3. Drill 3mm (1/8”) holes or smaller. WARNING: When making holes, be careful not to damage pipes, tanks, electric wires, etc. Doing so could lead to accidents or fire.
  • Page 11 • Mounting the remote control unit holder • If the remote control unit is exposed to direct sunlight, remove it from the holder and store it in the glove compartment. • If the holder cannot be securely fastened in place with the Velcro, install it using screws. Remote Control Remote Control Holder Screw for mounting...

  • Page 12: Connections

    Computer terminal PC CONTROL Used to make settings and adjustments with a computer. A special cable and computer software are required. For details, contact your store of purchase or an Alpine Information Center. MIC. MEMORY LOCK Reset switch Microphone jack Memory on/off selector switch Use this to connect a microphone.
  • Page 13 Connect to: Connect to an Ai-NET product using an Ai-NET cord. • Changer input terminal (Ai-NET input) For connection to the PXA-H900, use the straight Used for system expansion (Ai-NET changer, etc.). side. Connect to an Ai-NET product using an Ai-NET cord.

  • Page 14: Examples Of System Expansion

    Examples of system expansion • PXA-H900 + CDA-7990R Head Unit + CD Changer + External Amplifier Fiber Optic Cable (Sold Separately) Input Side CHANGER DIGITAL1 DIGITAL2 DIGITAL3 RCA INPUT ANALOG 1 INPUT Ai-NET IN CHANGER IN DISPLAY ANALOG2 ANALOG3 Fiber Optic Cable (Sold Separately)
  • Page 15 • PXA-H900 + Ai-NET Compatible Head Unit + CD Changer + External Amplifier Input Side Fiber Optic Cable (Sold Separately) CHANGER DIGITAL1 DIGITAL2 DIGITAL3 RCA INPUT ANALOG 1 INPUT CHANGER IN Ai-NET IN DISPLAY ANALOG2 ANALOG3 Fiber Optic Cable (Sold Separately)
  • Page 16 The PXA-H900 can then be turned on using this switch. The PXA-H900 can be used with any head unit. However, only an Alpine Ai-NET compatible head unit will be able to take full advantage of all the features and functions of this processor.
  • Page 17 • PXA-H900 + CDA-7990R Head Unit + DVD Player + CD Changer + Navigation System + TV Monitor + External Amplifier Fiber Optic Cable (Sold Separately) CDA-7990R Head Unit Fiber Optic Cable (Included with DVD Player) Input Side CHANGER DIGITAL1...

  • Page 18: Installing With Wires Only (No Terminals)

    To PXA-H900’s lead terminal NOTES • If the exposed section is too short, the current will not flow properly, resulting in the PXA-H900 not operating or breaks in the sound. • Making the exposed section too long may lead to short-circuit.
