Rush and Catch
MANUAL
* Please read the manual before installation and use.
* Please put the manual together with the machine.
Rush and Catch Manual
Warning
ACE Amusement Technologies Co., Ltd.
ADD: #5 Building, No. 6, HengFeng 6
Gangkou Town, Zhongshan City, Guangdong,
P. R. China
TEL: (+86) 760 8848 8920
E-Mail: Sales@ACE-Amusement.com
Web: www.ACE-Amusement.com
Road,
th
PC: 528447
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Ace Amusement Rush and Catch
Summary of Contents for Ace Amusement Rush and Catch
- Page 1 Rush and Catch Manual Rush and Catch MANUAL Warning * Please read the manual before installation and use. * Please put the manual together with the machine. ACE Amusement Technologies Co., Ltd. ADD: #5 Building, No. 6, HengFeng 6 Road, Gangkou Town, Zhongshan City, Guangdong, P.
-
Page 2: Table Of Contents
Rush and Catch Manual CONTENTS CONTENTS ...............................1 Introduction to the Product ..........................2 I Specifications and Technical Parameters ......................2 II Accessory List ..............................3 III How to Move and Position the Machine ...................... 4 (Ⅰ) How to Move the Machine ........................4 (Ⅱ) How to Position the Machine ...................... -
Page 3: Introduction To The Product
Rush and Catch Manual Introduction to the Product Rush and Catch is a new indoor medium and high-end animal racing simulation game machine developed by our company. The unique animal racing theme is beautiful and pleasing. Reasonable ergonomic design allows players to feel better the pleasure of the game. At the same time, it is a high-yield amusement product in the amusement park. -
Page 4: Accessory List
Rush and Catch Manual II Accessory List For the normal use of the machine, please open the package and carefully check whether the following items are included. The accessory list is below: Versi No./Speci Name Picture Unit Remark fication As per shipment... -
Page 5: How To Move And Position The Machine
Rush and Catch Manual III How to Move and Position the Machine (Ⅰ) How to Move the Machine There are trundles under the machine. When moving the machine for a short distance, you should raise foot to make the trundles touch the ground and push the machine. As there will be danger of overturning when the foot hits obstacle on the ground, you should move the foot up as much as you can and pay attention to obstacles ahead and uneven places when moving the machine along the ground. -
Page 6: Product Placement
Rush and Catch Manual (IV) Installation Location Dimension The machine should be placed according to the following dimensions for customers’ safety and enough space to run the machine. Game area: 50 cm Product Placement 50 cm 50 cm Area 50 cm IV Wiring and Precautions ... -
Page 7: Ⅴ Instructions On Game
Rush and Catch Manual Ⅴ Instructions on Game (Ⅰ) Game Logo/Standby Image (Ⅱ) Game Interface 1. Time: Player's remaining game time. 2. Score: Player's current score. 3. Ranking and Progress: Player's current ranking, and distance to the finish line. 4. Obstacles: Player will be injured and slowed down when hits an obstacle. -
Page 8: (Ⅵ) Game Scenes
Rush and Catch Manual (Ⅵ) Game Scenes 1) Mardi Gras West 2) Pearl Island 3) Arctic Adventure 4) Fantasy Land... -
Page 9: (Ⅴ) Gameplay
Rush and Catch Manual (Ⅴ) Gameplay 1) Select the game mode There are single player mode and two-player mode that players can choose. 2) Select the characters There are 5 characters that players can choose the one they like. 3) Select the scenarios There are 3 scenarios that players can choose. -
Page 10: Adjustment Of The Game Program Setting
Rush and Catch Manual VI Adjustment of the Game Program Setting KEY2 KEY1 Test (Choose) KEY3 KEY4 KEY1 Confirm KEY2 Option (Replenish lotteries) KEY3 Confirm (Modify) Return KEY4 (Previous Step) (I) Main Menu 1.Basic Setting: Enter the basic setting interface. -
Page 11: (Ⅱi) Input Test
Rush and Catch Manual (ⅡI) Input Test 1. 1-2P Coin: Test whether 1P, 2P coins selector work properly. Turn off: No inserting coins Turn on: Inserting coins 2. 1-2P Left Start Button: Test whether 1P, 2P left start button work properly. -
Page 12: (Ⅴ)Game Adjust
Rush and Catch Manual (Ⅴ)Game Adjust 1. 1-2P AD X: Read 1P, 2P Potentiometer -X 2. 1-2P AD Y: Read 1P, 2P Potentiometer -Y 3. 1-2P Joystick Adjust: Correct the potentiometer of 1P, 2P joystick. 4. Back: Directly return to the previous menu. -
Page 13: Fault Analysis And Maintenance
Rush and Catch Manual VII Fault Analysis and Maintenance (I) Installation and Commissioning Please check the components according to the list to assemble components before installation. After installation, plug the cable and turn on the machine to check whether each part runs normally. If no, immediately turn off the machine for troubleshooting. -
Page 14: Fault Analysis And Troubleshooting
Rush and Catch Manual VIII Fault Analysis and Troubleshooting Fault phenomena Main cause Corrective action Please reconnect the power cable or After the machine The monitor is not energized. replace it with new. is powered on,(the power supply fan The signal wire of the display is not... - Page 15 Rush and Catch Manual coin selector. The signal line of the coin selector is Check if the signal line of the coin loose. selector is loose. IO control board is damaged. Replace IO control board. Please check whether the sample coin is The sample coin is not placed well.
-
Page 16: Ⅸ Error Message
Rush and Catch Manual Ⅸ Error Message 1. Cause: Disconnection with the IO board. 2. Solution: Restart the machine, and press the reset button on the IO board (there is only one button on the board). 1. Cause: No enough lotteries, or the ticket machine is damaged. -
Page 17: Ⅹ Instructions On Restoring U Disk
Rush and Catch Manual Ⅹ Instructions on Restoring U Disk Method A : Using the Recovery System USB inside the game. Power off Step 1: the game machine. Step 2: Insert this software USB in the machine’s computer (Figure 1) Step 3: Turn on power again.
