Bullseye Crack Shot
(2PL / Single)
MANUAL
Please read the manual before installation and use.
Please put the manual together with the machine.
Bullseye Crack Shot Manual
Warning
ACE Amusement Technologies Co., Ltd.
ADD: #5 Building, No. 6, HengFeng 6
Gangkou Town, Zhongshan City, Guangdong,
P. R. China
TEL: (+86) 760 8848 8920
E-Mail: Sales@ACE-Amusement.com
Web: www.ACE-Amusement.com
Road,
th
PC: 528447
Advertisement
Table of Contents
Related Manuals for Ace Amusement Bullseye CrackShot
Summary of Contents for Ace Amusement Bullseye CrackShot
- Page 1 MANUAL Warning Please read the manual before installation and use. Please put the manual together with the machine. ACE Amusement Technologies Co., Ltd. ADD: #5 Building, No. 6, HengFeng 6 Road, Gangkou Town, Zhongshan City, Guangdong, P. R. China...
-
Page 2: Table Of Contents
Bullseye Crack Shot Manual CONTENTS Machine Introduction and Features: ..............2 Special Feature: ..................... 2 I. Specifications and Technical Parameters ............2 II Accessory List ....................3 (I) The accessory list is below:： ..............3 III How to Handle and Position the Machine ............4 (I) Handling Method .................. -
Page 3: Machine Introduction And Features
Bullseye Crack Shot Manual Machine Introduction and Features: With unique science fiction style, streamlined brilliant light and reasonable ergonomic design, Bullseye Crack Shot is an indoor middle and high-end simulated shooting amusement machine newly developed by our company, dazzling and eye-catching.At a safe distance of 0.9m (approx. 3 feet) from the screen, pick up the laser gun and aim at the enemy in the screen through the aiming point on the pistol and pull the trigger to shoot the enemy. -
Page 4: Accessory List
Bullseye Crack Shot Manual 1) Operating voltage: AC220V - 240V 50/60 Hz (or AC 110V±5%, 60Hz.) For the specific voltage, see the nameplate on the machine 2) Maximum power: 1300W (2PL) 1000W (Single) 3) Overall dimensions: 2PLVersion: D170 * W173 * H224 (cm) Single Version: D86 * W173 * H232 (cm) 4) Weight: About 300 KGS (2PL) 110KGS (Single) -
Page 5: How To Handle And Position The Machine
Bullseye Crack Shot Manual distributor of the machine for check. III How to Handle and Position the Machine (I) Handling Method The machine is equipped with caster under the base plate. When moving the machine for a short distance, you should raise foot to make the casters touch the ground and push the machine. (II) Fixing method Please place it on flat ground where it won’t slide easily, loosen the locked nuts of the foot, tighten the anchor bolts with a wrench, and keep the caster approximately 5mm away from the ground. -
Page 6: (Iv) Installation Location Dimension
Bullseye Crack Shot Manual (IV) Installation Location Dimension The machine should be placed according to the following dimensions for customers’ safety and enough space to run the machine. Game area: IV Wiring and Precautions (I) Caution Connect one end of the cable to the terminal box of the machine, and connect the other end to the socket. -
Page 7: (Ii) Air Compressor Drainage Instructions
Bullseye Crack Shot Manual (II) Air compressor drainage instructions 1、Drain the machine after switching it off. 2、Drain once every two weeks. 3、Take out the bottle from the back door as shown in the picture below, pull out the drainage tube and insert it into the drainage bottle, open the drainage valve for drainage. Caution: The bottle must be held tightly, as drainaging will be accompanied by a large amount of gas discharge. -
Page 8: Game Introduction
Bullseye Crack Shot Manual V. Game Introduction (I) Game play 1、 Lift the hand gun, aim with the iron sight and rear sight, and pull the trigger to shoot the enemies, targets or objects by the safe distance of 0.9 meters from muzzle to the screen. Iron sight Rear sight 2、There are 3 buttons underneath the gun panel, which are Left key, Confirm key and Right key. -
Page 9: (Iii) All Scenes Gameplay Instruction
Bullseye Crack Shot Manual (III) All scenes gameplay instruction (1) Accuracy test 1.This scene is to shoot the standard racing target. Player needs to pursue accuracy and speed, and hit the bullseye. 2.Every target will fade and shrink faster and faster as time goes on. Interface description: Target record Target summary... - Page 10 Bullseye Crack Shot Manual (3) Fire at will 1. Player needs to shoot and blow all the bottles and cans. 2. There are many permutation and combination for bottles and cans, some of which may move. 3. Hit all the cans fast by taking advantage of the physical characteristics skillfully. Mobile platform physical cans All types of bottles...
- Page 11 Bullseye Crack Shot Manual (5) Construction zone 1. There is a Boss element in the ending level compared to the Desert Assault. 2. It will be very difficult as the Boss has high HP and tricks, and can call NPC as well. Shoot the circle to Boss’s HP left stop the enemies’...
-
Page 12: (Iv) Mission System Instruction
Bullseye Crack Shot Manual (IV) Mission System Instruction During the Interior training or Fire at will, missions will come up, and player will be reminded to achieve some goal. There will be bonus scores or punishment of time deduction based on the goal accomplishment. -
Page 13: (V) Background Setup Instructions
Bullseye Crack Shot Manual Ranking of the Input and current level leave the (LAN) name on the ranking list leaderboard Player’s ranking (V) Background Setup Instructions... -
Page 14: (Vi) Background Setting
Bullseye Crack Shot Manual (VI) Background Setting (1) Main page 1. Game Play Setting: Set up number of insert-coins, game time etc. and other functions likewise. 2. Revenue data: Check the cost, tickets dispensed and playtime. 3. HardwareTest: Check whether the input and output of the hardware are normal. 4. - Page 15 Bullseye Crack Shot Manual (3) Revenue data 1. Recent revenue: Select the recent report(Daily Sheet, Month Sheet, Year Sheet). 2. Historical Data: After entering, select a year to view the revenue data for each month of the year; then select a month to see the daily revenue data for that month. 3.
- Page 16 Bullseye Crack Shot Manual (6) Basic Settings 1. Game Play Volume(off/1-10): Set up volume of game music and sound. 2. Demo Volume : Set the game in the standby state (that is, when no one game), the (OFF/ON) sound is open. 3.
-
Page 17: (Vii) Lan Connection Instructions
Bullseye Crack Shot Manual (VII) LAN connection instructions 1. Network cable must be connected to the LAN socket. 2. If there are multiple devices, use bridging between the devices. Make sure both side of the WAN Socket LAN Socket network cable light are ON... - Page 18 Bullseye Crack Shot Manual 1、Installation and Commissioning Before installation, please approve the parts according to the list and assemble the components. After installation, plug in the power cord and turn on the machine, and check whether the operation of the machine parts is normal. If abnormalities are found, stop the machine in time to remove obstacles.
-
Page 19: Failure Analysis And Solution
Bullseye Crack Shot Manual VI. Failure Analysis and Solution Common failures Failure Main reasons Exclusion method phenomenon After the Please reconnect the power cord or Display is not powered on machine is replace the power cord powered on, the power supply is working (power Display signal cord is not connected Please reconnect the signal cord or... - Page 20 Bullseye Crack Shot Manual powered on contact professionals and manufacturers to deal with it Can't start the Replace the key holder, replace the game after Start button holder is loose or switch switch wire, or replace the start pressing the start wire is loose button button...
-
Page 21: Error Tips
Bullseye Crack Shot Manual VII. Error Tips Cause: Disconnection with the IO board Solution: Restart the machine, and press the reset button on the IO board (there is only one button on the board) Cause: No enough tickets, or the ticket machine is damaged Solution: Replenish ticket;... -
Page 22: Wiring Diagram
Bullseye Crack Shot Manual VIII. Wiring Diagram... - Page 23 Bullseye Crack Shot Manual...
-
Page 24: Instructions For Using The Recovery System Usb
Step 6: Power on the machine again, the program will be upgraded successfully. Figure 4 Figure 5 The above technical parameters are subject to change without prior notice. ACE Amusement Technologies Co., Ltd. ADD: #5 Building, No. 6, HengFeng 6 Road, Gangkou Town, Zhongshan City, Guangdong, P.
