Ace Amusement Nitro Speed Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
Nitro Speed (4PL)
MANUAL
\
 Please read the manual before installation and use.
 Please put the manual together with the machine.
Nitro Speed (4PL) Manual
Warning
ACE Amusement Technologies Co., Ltd.
ADD:
#5 Building, No. 6, HengFeng 6
Gangkou Town, Zhongshan City, Guangdong,
P. R. China
TEL: (+86) 760 8848 8920
E-Mail: Sales@ACE-Amusement.com
Web: www.ACE-Amusement.com
th
Road,
PC: 528447

Advertisement

loading
Need help?

Need help?

Do you have a question about the Nitro Speed and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Ace Amusement Nitro Speed

Summary of Contents for Ace Amusement Nitro Speed

  • Page 1 Nitro Speed (4PL) Manual Nitro Speed (4PL) MANUAL Warning  Please read the manual before installation and use.  Please put the manual together with the machine. ACE Amusement Technologies Co., Ltd. ADD: #5 Building, No. 6, HengFeng 6 Road, Gangkou Town, Zhongshan City, Guangdong, P.
  • Page 2 Nitro Speed (4PL) Manual CONTENTS Introduction........................3 Specifications and Technical Parameters..............5 Accessory List....................... 6 How to Move and Position the Machine..............7 How to Move the Machine..................7 How to Position the Machine.................. 8 Unsuitable places.....................8 Where to Place......................8 Installation Location Dimension................8 Precautions before Startup..................8...
  • Page 3 We hope it can help you to succeed! II. Introduction to the Product: Nitro Speed is an indoor redemption machine newly developed by our company and especially designed for any FEC or amusement locations. It is new design racing machine with photo-taking ater start the game, which is beautiful appearance, safe and reliable materials, and there is ranking while competition to win more scores that is easy to operate，...
  • Page 4 Nitro Speed (4PL) Manual Before use, please note the safety warning stickers on the machine; while reading the manual, please pay special attention to some signs. We divide the safety warnings into 3 categories as follows. They mean different levels of danger.
  • Page 5 Nitro Speed (4PL) Manual Specifications and Technical Parameters 1) Operating Voltage: AC 220V - 240V, 50/60 Hz or AC110V±5%, 50/60 Hz 2) Maximum Power: 750W 4) Dimensions: D137*W199*H265 (cm) 5) Weight: 500Kgs 6) Operating Environment: Temperature (indoors): 0℃～35℃; Humidity: ≤90%；...
  • Page 6 Nitro Speed (4PL) Manual Accessory list For the normal use of the machine, please open the package and carefully check whether the following items are included. The accessory list is below: Name Unit Picture Remark /Specification Cable 10A/250V-3M Φ5×20mm T5A...
  • Page 7 Nitro Speed (4PL) Manual How to Move and Position the Machine How to Move the Machine There are trundles under the machine. When moving the machine for a short distance, you should raise foot to make the trundles touch the ground and push the machine.
  • Page 8 Nitro Speed (4PL) Manual How to Position the Machine  Please place it on flat ground where it won’t slide easily;  Please use the following foot to fix the machine (as shown below) Loosen the tightly locked nuts of the foot, tighten the bolts of the foot with a wrench, and keep the trundle approximately 5mm away from the ground.
  • Page 9 Nitro Speed (4PL) Manual Installation Location Dimension The machine should be placed according to the following dimensions for customers’ safety and enough space to run the machine. Attention: The machine should not be placed at inclined place, or there may be an accident.
  • Page 10 Nitro Speed (4PL) Manual Wiring and Precautions  Connect one end of the cable to the terminal box of the machine, and connect the other end to the socket.  Connect the power supply according to the voltage on the label, or the machine might be damaged.
  • Page 11 Nitro Speed (4PL) Manual Installation and Maintenance Troubleshooting Common Failure Phenomenon Main cause Troubleshooting After the machine is Please reconnect the power cable or replace it The screen is not connected to power supply. powered on,(the with new. power supply...
  • Page 12 Nitro Speed (4PL) Manual same with that inserted in the coin collector The gear of the switch (normally on, normally off) Please check whether the gear of the switch is incorrect (normally on, normally off) is correct Please check whether the socket of the coin...
  • Page 13 Nitro Speed (4PL) Manual Error Code 1. Cause: Disconnection with the IO board 2. Solution: Restart the machine, and press the reset button on the IO board (there is only one button on the board) 1. Cause: The memory of the host is insufficient 2.
  • Page 14 Nitro Speed (4PL) Manual Instructions on Game Game interface: 1. UI interface of the player's status 2. The player's front sight to aim at the target 3. The current task bar 4. Game props to increase the shooting power Characteristics of the machine: The scene map of the game is divided into three backgrounds.
  • Page 15 Nitro Speed (4PL) Manual Game Scenes 1.City 2.Desert 3.Snow...
  • Page 16 Nitro Speed (4PL) Manual Game Result: Adjustment of the Game Program Setting KEY 4 KEY 3 KEY 2 KEY 1 KEY 1 Test (Choose） KEY 2 Confirm（modify） KEY 3 Confirm（replenish ticket） KEY 4...
  • Page 17 Nitro Speed (4PL) Manual Main Menu 1. Basic setting: Enter the basic setting interface 2. Adjustment setting: Enter the adjustment setting interface 3. Input test: Enter the input test interface 4. Output test: Enter the output test interface 5. Game reset: Enter the game reset interface 6.
  • Page 18 Nitro Speed (4PL) Manual 1.1P and 2P Potentiometer adjustment Step 1: Record the AD value of the throttle release. Action tip: "Please release the throttle, press the KEY 3 comfirm button on the back of front door to record the value"...
  • Page 19 Nitro Speed (4PL) Manual Input Test 1. Insert coins 1: Test the 1P coin collector Turn off: No inserting coins Turn on: Inserting coins 2. Insert coins 2: Test the 2P coin collector Turn off: No inserting coins Turn on: Inserting coins 3.
  • Page 20 Nitro Speed (4PL) Manual Output Test 1. 1P ticket dispenser test: Test whether the 1P ticket machine works well 2. 2P ticket dispenser test: Test whether the 2P ticket machine works well 3. 3P ticket dispenser test: Test whether the 3P ticket machine works well 4.
  • Page 21 Nitro Speed (4PL) Manual Check Game Data Installation Figures and Steps...
  • Page 22 Nitro Speed (4PL) Manual Step 1: Pull out the telescopic frame in the display and secure it with screws, please follow in the following image below. Step 2: Link the display to the control panel, connect the corresponding wires in the connector order before installation, and the area circled in the figure below will be secured by screws, please follow in the following image below.
  • Page 23 Nitro Speed (4PL) Manual Step 3: Install the light box, fix the light box above the rear of the display as shown in the figure below, and connect the wires in the light box to the wires in the display before installing the light...
  • Page 24 Nitro Speed (4PL) I/O Table V1.0...
  • Page 25 Instructions on Restoring U Disk When the machine is turned off, plug the U disk into the USB port behind the host, and the U disk will restore after machine restarts. shown in the figure, the system is restoring, and it needs about 20 minutes.
