- Page 1 Washing Machine User Manual Masină de spălat automată Manual de utilizare B5WF U78435 WB EN/RO Document Number : 1911861728_EN/ 13-01-22.(10:50)
-
Page 2: Explanation Of Symbols
Please read this user manual first! Dear Customer, Thank you for selecting a Beko product. We hope that you get the best results from your product which has been manufactured with high quality and state-of-the-art technology. Therefore, please read this entire user manual and all other accompanying documents carefully before using the product. -
Page 3: General Safety Instructions
General safety instructions This section contains safety instructions that will help protect from risk of personal injury or property damage. Our company shall not be liable for any damages that may arise in case of failure to follow these instructions. Always have the installation and repairing procedures carried out by the Authorised Service Agent. -
Page 4: Electrical Safety
Children should not perform cleaning and user maintenance works without an adult’s supervision. Keep packaging materials away from children. Danger of injury and drowning. Keep all detergents and additives used for the product away from children’s reach. Cut the power cable and break and deactivate the locking mechanism of the loading door before disposing of the product for children’s safety. -
Page 5: Installation Safety
1.5 Installation Safety Check the information on the manual and installation instructions to prepare the product for installation and make sure the electrical mains, clean water mains and water outlet are suitable. If not, call a qualified electrician and plumber to have them make the necessary arrangements. These operations are the responsibility of the customer. -
Page 6: Usage Safety
Do not install the product behind a door, a sliding door or at another location that will prevent the door from opening completely. If a drier is to be placed on the product, fix with a suitable connection apparatus obtained from the authorized service. There is a risk of contact with electrical pieces when the upper trays is removed. - Page 7 Do not place your hand or a metal object under the washing machine. If washing laundry at high temperatures, the discharged washing water would burn your skin if in contact with your skin, for ex. When the discharge hose is connected to the tap. Do not touch the discharge water. Take the following precautions to prevent formation of biofilm and malodours: - Make sure the room where the washing machine is placed is well ventilated.
-
Page 8: Important Instructions For Environment
Important instructions for environment 2.1 Compliance with the WEEE Directive and Disposing of the Waste Product: This product complies with EU WEEE Directive (2012/19/EU). This product bears a classification symbol for waste electrical and electronic equipment (WEEE). This symbol indicates that this product shall not be disposed with other household wastes at the end of its service life. -
Page 9: Technical Specifications
Technical specifications Supplier name or trademark Beko B5WF U78435 WB Model name 7002340002 Rated capacity (kg) Maximum spin speed (rpm) 1400 Built-in Height (cm) Width (cm) Depth (cm) Single Water inlet / Double Water inlet • / - • Available... -
Page 10: Appropriate Installation Location
4.1 Installation Please read the “Safety Instructions” section first! • Apply to the nearest authorized service agent for the installation of your product. • Preparation of the location and electrical, tap water and waste water installations at the place of installation is under customer's responsibility. -
Page 11: Connecting To Water Supply
4.1.4 Connecting to water supply Models with a single water inlet shall not be connected to the hot water tap. In such a case the laundry will get damaged or the product will switch to protection mode and will not operate. WARNING Do not use old or used water inlet hoses on a new product. -
Page 12: Adjusting The Feet
4.1.6 Adjusting the feet In order to ensure that the product operates more silently and vibration-free, it must stand level and balanced on its feet. Ensure that the product is balanced by adjusting the feet. Otherwise, the product may move from its place and cause WARNING crushing, noise and vibration problems. -
Page 13: Preparing Laundry For Washing
4.2 Preparation Please read the “Safety Instructions” section first! 4.2.1 Sorting the laundry • Sort laundry according to type of fabric, colour, and degree of soiling and allowable water temperature. • Always observe the instructions given on the garment care labels. 4.2.2 Preparing laundry for washing •... -
Page 14: Using Detergent And Softener
4.2.6 Using detergent and softener Read the manufacturer instructions on the package while using detergents, softeners, starch, bleach and decolourants, anti- WARNING limescale and follow the dosage information provided. Use a measuring cup, if any. The detergent drawer comprises of three compartments: –... -
Page 15: Using Liquid Detergents
Using liquid detergents If the product has a liquid detergent apparatus • Press and rotate the apparatus at where it is shown when you want to use liquid detergents. The part falling below will serve as a barrier for liquid detergent. •... -
Page 16: Tips For Efficient Washing
4.2.7 Tips for efficient washing Clothes Light Colours and Black/Dark Delicates/ Colours Colours Woollens/Silks Whites (Recommended (Recommended (Recommended temperature (Recommended temperature temperature range temperature range range based on soiling level: range based on soiling level: based on soiling level: based on soiling level: 40-90 oC) cold -40°C) cold -40°C) -
Page 17: Operating The Product
4.3 Operating the product Please read the “Safety Instructions” section first! 4.3.1 Control panel 1 - Programme Selection knob 7 - End Time Setting button 2 - Temperature level lights 8 - Auxiliary Function button 3 3 - Spin level indicator lights 9 - Auxiliary Function button 2 4 - Display 10 - Auxiliary Function button 1... -
Page 18: Programme And Consumption Table
4.3.3 Programme and consumption table Auxiliary functions Selectable Programme (°C) temperature range °C 2,40 1400 • • • • • Cold-90 Cottons 1,80 1400 • • • • • Cold-90 0,97 1400 • • • • • Cold-90 40*** 0,990 1400 40-60 Eco 40 - 60... -
Page 19: Programme Selection
The auxiliary functions in the table may vary according to the model of your machine. Water and power consumption may vary subject to the changes in water pressure, water hardness and temperature, ambient temperature, type and amount of laundry, selection of auxiliary functions and spin speed, and changes in electric voltage. You can see the washing duration on the display of your machine while selecting a programme. - Page 20 4.3.5 Programmes • Eco 40-60 The Eco 40-60 programme is able to clean normally soiled cotton laundry declared to be washable at 40 °C or 60 °C, together in the same cycle, and that this programme is used to assess the compliance with the EU ecodesign legislation.
- Page 21 • Xpress / Super Xpress Use this programme to wash your lightly soiled or unspotted cotton clothes in a short time. The programme duration can be reduced down to 14 minutes when the quick wash function is selected. When the quick wash function is selected, maximum 2 (two) kg of laundry must be washed.
-
Page 22: Temperature Selection
• Soft Toys***** Soft toys must be washed in a delicate programme due to their delicate fabrics, and the fibre and accessories they contain. Thanks to its delicate washing movements and spinning profile, the soft toys programme protects the toys during washing. It is recommended to use liquid detergent. Fragile toys with hard surfaces must not be washed under any circumstances. -
Page 23: Rinse Hold
Rinse hold If you are not going to unload your clothes immediately after the programme completes, you can use rinse hold function to keep your laundry in the final rinsing water in order to prevent them from getting wrinkled when there is no water in the machine. Press Start / Pause button after this process if you want to drain the water without spinning your laundry. -
Page 24: Functions/Programmes Selected By Pressing The Function Keys For 3 Seconds
When the Customized Programme auxiliary function is selected, the washing performance and energy consumption will be different than the declared value. 4.3.8.2 Functions/Programmes Selected by Pressing the Function Keys for 3 Seconds • Drum Clean Press and hold the auxiliary function button 1 for 3 seconds to select the programme. Use regularly (once in every 1-2 months) to clean the drum and provide the required hygiene. -
Page 25: Starting The Programme
First setup of the HomeWhiz application must be complete for the bluetooth connection to be activated. After setup, pressing the remote control function button while the knob is at Download Programme/Remote Control position will automatically activate the bluetooth connection. 4.3.9 End Time Time display Remaining time for the completion of the programme while it is running is displayed as “01:30”... -
Page 26: Loading Door Lock
4 Programme follow-up indicator lights on the display will show the current programme step. 4.3.11 Loading door lock There is a locking system on the loading door of the machine that prevents opening of the loading door in cases when the water level is unsuitable. "Door Locked"... -
Page 27: Switching The Machine To Pause Mode
4.3.12 Changing the selections after programme has started Adding laundry after the programme has started If the water level in the machine is suitable when you press Start/Pause button, the door lock will be deactivated and the door will open, allowing you to add garments. The door lock icon on the display goes off when the door lock is deactivated. -
Page 28: End Of Programme
4.3.14 End of programme End symbol appears on the display when the programme is completed. If you do not press any button for 10 minutes, the machine will switch to OFF mode. Display and all indicators are turned off. Completed programme steps will be displayed if you press On/Off button. 4.3.15 HomeWhiz Feature and Remote Control Function HomeWhiz allows you to use your smart device to check your washing machine and get information about its status. - Page 29 • Return to the HomeWhiz application and wait until the setup is complete. When setup is complete, give your washing machine a name. Now, you can tap and see the product you have added in the HomeWhiz Aplication. If you cannot successfully perform the setup within 5 minutes, your washing machine will turn off automatically. In this case, you will have to start over the setup procedure.
- Page 30 When the Remote Control is on, you can only manage, turn-off and status follow-up operations through your washing machine. And all functions except child lock can be managed through the application. You can follow whether the Remote Control function is On or Off through the function indicator on the button. If the Remote Control function is Off, all the operations are handled on the washing machine and only status follow-up is allowed on the application.
-
Page 31: Maintenance And Cleaning
4.4 Maintenance and cleaning Please read the “Safety Instructions” section first! Service life of product extends and frequently experienced problems will be reduced if it is cleaned at regular intervals. 4.4.1 Cleaning the detergent drawer Clean the detergent drawer at regular intervals (every 4-5 washing cycles) as shown below in order to prevent accumulation of powder detergent in time. -
Page 32: Draining Remaining Water And Cleaning The Pump Filter
4.4.5 Draining remaining water and cleaning the pump filter The filter system in your machine prevents solid items such as buttons, coins and fabric fibres clogging the pump impeller during discharge of washing water. Thus, the water will be discharged without any problem and the service life of the pump will extend. -
Page 33: Troubleshooting
Troubleshooting Please read the “Safety Instructions” section first! Problem Cause Solution Programmes do not start after the Start / Pause / Cancel button is not pressed. • Press Start / Pause / Cancel button. loading door is closed. It may be difficult to close the loading door in case of •... - Page 34 Problem Cause Solution Washing takes longer than Water pressure is low. • Product waits until taking in adequate amount specified in the user manual.(*) of water to prevent poor washing quality due to the decreased amount of water. Therefore, the washing time extends.
- Page 35 Problem Cause Solution Washing performance is poor: Insufficient amount of detergent is used. • Use the recommended amount of detergent Stains persist or the laundry is not appropriate for water hardness and the laundry. whitened. (**) Excessive laundry is loaded in. •...
- Page 36 Problem Cause Solution Detergent residue in the detergent Detergent was put in wet drawer. • Dry the detergent drawer before putting in drawer. (**) detergent. Detergent has gotten damp. • Keep detergents closed in an environment free of humidity and do not expose them to excessive temperatures.
- Page 37 When the appliance is turned off, pressing 1 and 2 auxiliary function buttons are pressed for a long time, a 3-2-1 countdown, and the total washing cycles completed on the appliance is displayed. After the total washing cycle is displayed, the failure codes, if any, are displayed. Check the information on the screen through the table below.
- Page 38 Beko, and will void the warranty of the product. Therefore, it is highly recommended that end-users refrain from the attempt to carry out repairs falling outside the mentioned list of spare parts, contacting in such cases authorized professional repairers or registered professional repairers.
