D-Box G3 HAPTIC SYSTEM Quick Start Manual page 3

10 SYSTEM CONFIGURATION (OPTIONAL)
Your G3 haptic system comes with a default configuration. If your
requirements differ from the factory configuration, you need to
change the configuration before installing your haptic system,
using the D-BOX System Configurator.
1 Select the Configuration Update tab. Click Refresh
Information. Make sure the Actuator Count matches with
your system. If not, make sure that all power cables and
ethernet cables are firmly connected.
2 Enter the configuration number matching your system or select
the axes you want for your system. Click Apply Configuration.
Close the System Configurator when completed.
Address: 2172 de la Province, Longueuil, QC Canada J4G 1R7
Email: support@d-box.com
11 TEST & PLAY
1 From the Windows Start menu, open D-BOX HaptiSync
Center and enter your D-BOX Connect account
credentials.
2 Make sure your HaptiSync Mode is set to D-BOX Coded
Gaming.
3 Click on the Haptic Output tab, then click Start Haptic
System Test.
Your haptic system should start moving and vibrate
following a factory haptic pattern.
4 Click Stop Haptic System Test to stop the test.
It's now the time to enjoy your new haptic
system with your favorite game or movie!
Phone: US: 1 888 442-3269 ext.931
Other regions: +1 450 442-3003 ext.931
G3 HAPTIC SYSTEM G3 HAPTIC SYSTEM
QUICK START GUIDE QUICK START GUIDE
246-914-0004-EN1
January 2025
