D-Box G3 HAPTIC SYSTEM Quick Start Manual page 2

6 SYSTEM CONNECTION
Connect your haptic system per the plan below. See
for detailed wiring diagrams.
7 D-BOX CONNECT ACCOUNT CREATION
Create your D-BOX account on the D-BOX Connect
This is mandatory to install haptic codes for games (D-BOX Coded
Gaming mode) and to have access to D-BOX Coded Video mode.
You will be prompted later to log in when opening D-BOX
HaptiSync Center.
8 D-BOX HAPTISYNC CENTER INSTALLATION
1 Download D-BOX HaptiSync Center from our
2 Install the software on the computer (PC) that will be
connected to your haptic system.
D-BOX HaptiSync Center software suite includes system's
drivers in addition to the following software and utilities:
• D-BOX Adaptive Gaming Configurator
• D-BOX System Monitor
• D-BOX Stimuli Presenter
Address: 2172 de la Province, Longueuil, QC Canada J4G 1R7
Email: support@d-box.com
9
G3 User Guide
website.
website.
Phone: US: 1 888 442-3269 ext.931
Other regions: +1 450 442-3003 ext.931
G3 HAPTIC SYSTEM
QUICK START GUIDE
FIRMWARE UPDATE
As D-BOX upgrades the ACM firmware on a regular basis, we
recommend that you update your equipment to the latest
firmware version using the D-BOX System Configurator.
1 Download D-BOX System Configurator from our
2 Extract the compressed file and run the installer. Note that
the User Guide is in the Windows Start menu/D-BOX folder.
3 Firmware update:
a) Make sure your haptic system is powered on.
b) Open the D-BOX System Configurator from the
Windows Start menu/D-BOX folder.
c) From the Firmware Update tab, click Refresh
Firmware Status.
d) If the system shows ''Outdated (Update firmware)'', click
Update Firmware and follow the on-screen instructions:
website.
246-914-0004-EN1
January 2025
