GB
ADL 335
Programme selector
START button
The indicator lights up during operation, flashes when a
fault occurs, and goes off at the end of the programme.
START button RESET function:
Press this button for at least 2 seconds; the selected
programme and options are cancelled. Main failure
displays (repeated flashing of the START indicator lamp)
can be cancelled by RESETTING. Detailed instructions are
given in chapter 5 "What to do, in case of...".
P
Programmes
1
Quickwash
2
Bio Normal
3
Intensive
1)
Programme data obtained in conformity with European standard EN 50242. The data may vary, for example, according to
different loads, extra functions, sensor settings (only with sensor programmes), water supply temperatures, water hardness
and power supply voltage.
2)
Energy label programme in compliance with EN 50242. - Information for Test Laboratories: for more detailed information on
the EN comparison test and other tests, contact the following address: "nk_customer@whirlpool.com".
Whirlpool is a registered trademark of Whirlpool USA
Before using the dishwasher, read the
installation and maintenance instructions carefully!
1. OVERVIEW
Table 1.1.
Table of programmes
Lightly soiled crockery, without dry
40°C
residuals.
Normally soiled crockery. Energy-
2)
50°C
saving programme.
Recommended programme for
70°C
heavily soiled crockery, especially
suitable for pans and saucepans.
On / Off button
Loading instructions
Detergent
Consumption
dispenser
large
small
Litres
kWh
X
—
13.0
0.70
X
X
16.0
1.24
X
X
17.0
1.65
5019 596 01013
1)
Minutes
1)
30 ±
1)
133 ±
1)
145 ±
1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Ignis ADL 335
Summary of Contents for Ignis ADL 335
- Page 1 Before using the dishwasher, read the installation and maintenance instructions carefully! ADL 335 1. OVERVIEW Programme selector On / Off button START button The indicator lights up during operation, flashes when a fault occurs, and goes off at the end of the programme.
- Page 2 2. QUICK REFERENCE GUIDE Detailed instructions are given on the following pages; also see section “5. What to do, in case of...” 1. Switch on the Press the ON/OFF button. appliance Press the button “Select programme” or the programme selector to display the 2.
-
Page 3: How To Use The Appliance
3. HOW TO USE THE APPLIANCE PROGRAMME SELECTION Press the button “Select programme” or the programme selector to display the selected programme. The appliance must be switched on. If required, select possible options. The corresponding indicator lights up. The correct programme and the selectable functions are given in table 1.1 on page 1. Programme times stated in the table were obtained under normal conditions and may vary depending on conditions. - Page 4 3. HOW TO USE THE APPLIANCE c. How to adjust the rinse aid dosage regulator The rinse aid dosage can be adjusted to the detergent used. The lower the setting, the less rinse aid is dispensed (factory setting: position 4). Press the lever 2 to open the cover.
-
Page 5: How To Load The Racks
3. HOW TO USE THE APPLIANCE HOW TO LOAD THE RACKS UPPER RACK - depending on the model Multifunction support A Three possible positions for long utensils, cups and glasses. Crockery holder B In horizontal position: cups/long utensils, in raised position for plates and stemware. -
Page 6: Precautions And General Recommendations
4. PRECAUTIONS AND GENERAL RECOMMENDATIONS 1. Packing The packaging materials are 100% recyclable and marked with the recycling symbol. 2. Removing the packaging and inspecting the contents After unpacking, make sure that the dishwasher is undamaged and that the door closes correctly. If in doubt, contact a qualified technician or your local retailer. - Page 7 5. WHAT TO DO IF... If a fault occurs, before contacting the After-sales Service, make the following checks to try and remedy the problem. Most faults can be remedied by taking the following courses of action, quickly restoring normal appliance operation. The appliance...
- Page 8 5. WHAT TO DO IF... Crockery and cutlery ... Possible causes/solutions ...are not perfectly clean/have food In the event of frequent use of low temperature programmes residues (50°C or lower) (if available), every now and again select a higher temperature programme The spray arms must not be clogged, the filters must not be dirty and must be fitted correctly (see the instructions in “Maintenance and installation”).
