Quick reference guide
PROGRAM SELECTION
START/RESUME BUTTON
BUTTON
Push this button to start the selected program: the
Push "Programs" button
indicator lights up and goes off at the end of the
(repeatedly) until the indicator
program.
of the required program lights
When the door is opened during a washing cycle,
up (see "Table of programs"
the cycle is temporarily paused: the Start indicator
below).
blinks. To resume the cycle push the Start button
and close the door within 3 seconds.
Table of programs
P
Programs
1
Pre-Wash
cold
2
Rapid
40°C
3
2)
50°C
Eco
4
Intensive
65°C
1)
Program data obtained in conformity with European standard EN 50242, obtained under normal conditions (without any options) and may vary depending on
conditions. Differences of up to 20 minutes are possible with sensor programs as a result of the appliance's automatic calibration system.
2)
Reference program for energy label in compliance with EN 50242 regulations. - Note for Testing Institutes: for detailed information on the
EN/Standard loading comparison test and other tests, contact the following address: "contact_ignis@ignis.com".
*Power consumption in: Left-on mode: 0.70 W / Off mode: 0.40 W
Ignis is a registered trademark
CANCEL/OFF BUTTON
Push this button to switch off the control panel.
If pressed when a program is running it cancels the
program ongoing draining water for 1 minute.
If pressed when the dishwasher is switched off it
drains any possible liquids from dishwasher
(1 minute process).
If the indicator flashes repeatedly, see
page 6 - chapter "What to do if ...".
Deter-
gent
Loading instructions
Crockery to be washed later.
—
Lightly soiled crockery, with no dried-on
X
food.
Normally soiled crockery.
"Standard program" the most efficient in
X
terms of its combined energy and water
consumption.
Recommended program for heavily soiled
crockery, especially suitable for pans and
X
saucepans.
BEFORE USING THE APPLIANCE FOR THE FIRST TIME CAREFULLY READ THIS
THE CONTROL PANEL OF THIS DISHWASHER ACTIVATES PUSHING ANY
AUTOMATICALLY AFTER 30 SECONDS IF NO CYCLE HAS STARTED.
Consumption
Drying
Phase
1)
Litres
kWh
Minutes
5.0
0.02
10
NO
13.0
0.70
30
NO
15.0
1.02
165
Full
15.0
1.50
140
Full
QUICK REFERENCE GUIDE AND THE ASSEMBLY INSTRUCTIONS!
BUTTON EXCEPT CANCEL/OFF BUTTON.
FOR ENERGY SAVING THE CONTROL PANEL DEACTIVATES
Chart
5019 550 00321
EN -1-
