DAILY REFERENCE
GUIDE
THANK YOU FOR BUYING A IGNIS PRODUCT. You can download the Safety Instructions and the User
Manual, by visiting our website docs.whirlpool.eu and following the Instructions on the back of this
booklet.
PRODUCT DESCRIPTION
APPLIANCE
7
8
9
11
Service:
0000 000 00000
12
CONTROL PANEL
1
1.
On-Off/Reset button with indicator light
2.
Program selection button with indicator light
3.
Half Load button with indicator light
4.
Rinse Aid refill indicator light
5.
Salt refill indicator light
Questo manuale d'istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per
o cerca il tuo prodotto tra le
Before using the appliance carefully read Safety Instructions.
2
3
4
migliori offerte di Lavastoviglie
1.
1
2.
3.
2
4.
5.
6.
3
7.
8.
4
9.
5
10. Detergent and Rinse Aid dispensers
6
11. Rating plate
12. Control panel
10
5
6
7
6.
Program indicator lights
7.
Delay indicator light
8.
Delay button with indicator light
9.
Tablet (Tab) button with indicator light
10. Start/Pause button with indicator light / Drain out
Upper rack
Foldable flaps
Upper rack height adjuster
Upper spray arm
Lower rack
Cutlery basket
Lower spray arm
Filter Assembly
Salt reservoir
8
9
Ignis ABE 2B19 A X
EN
10
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ABE 2B19 A X and is the answer not in the manual?

Questions and answers

Related Manuals for Ignis ABE 2B19 A X

Summary of Contents for Ignis ABE 2B19 A X

  • Page 1 Lavastoviglie DAILY REFERENCE GUIDE THANK YOU FOR BUYING A IGNIS PRODUCT. You can download the Safety Instructions and the User Manual, by visiting our website docs.whirlpool.eu and following the Instructions on the back of this booklet. Before using the appliance carefully read Safety Instructions.
  • Page 2 FIRST TIME USE SALT, RINSE AID AND DETERGENT ADVICE REGARDING THE FIRST TIME USE FILLING THE RINSE AID DISPENSER Rinse aid makes dish DRYING easier. The rinse aid dispenser A should be After installation, remove the stoppers from the racks and the retaining filled when the RINSE AID REFILL indicator light in the control elastic elements from the upper rack.

  • Page 3: Programs Table

    PROGRAMS TABLE Duration Water Energy Available of wash Program consumption consumption options program (litres/cycle) (kWh/cycle) (h:min) 1 Eco 50° 3:20 12.0 1.05 2 Intensive 65° 2:30 16.0 1.50 3 Mixed 55° 2:25 16.0 1.35 4 Fast&Clean 28’ 45° 0:28 0.60 5 Pre-Wash 0:10 0.01...
  • Page 4 OPTIONS AND FUNCTIONS OPTIONS can be selected directly by pressing the corresponding button (see CONTROL PANEL). If an option is not compatible with the selected program see PROGRAMS TABLE, the corresponding LED flashes rapidly 3 times and beeps will sound. The option will not be enabled. TABLET (Tab) HALF LOAD This setting allows you to optimize the performance of the...

  • Page 5: Loading The Racks

    LOADING THE RACKS UPPER RACK LOWER RACK Load delicate and light dishes: For pots, lids, plates, salad bowls, glasses, cups, saucers, low salad cutlery etc. Large plates and lids bowls. should ideally be placed at the si- des to avoid interferences with the spray arm.

  • Page 6: Daily Use

    DAILY USE 1. CHECK WATER CONNECTION The machine will switch off automatically during certain extended Check that the dishwasher is connected to the water supply and periods of inactivity, in order to minimise electricity consumption. that the tap is open. If the crockery is only lightly soiled or if it has been rinsed with water before being placed in the dishwasher, reduce the amount 2.

  • Page 7: Care And Maintenance

    CARE AND MAINTENANCE CLEANING THE FILTER ASSEMBLY CLEANING THE SPRAY ARMS Regularly clean the filter assembly so that the filters do not clog and On occasions, food residue may become encrusted onto the spray arms that the waste water flows away correctly. and block the holes used to spray the water.

  • Page 8: Troubleshooting

    TROUBLESHOOTING In case your dishwasher doesn’t work properly, check if the problem can be solved by going through the following list. For other errors or issues please contact authorized After-sales Service which contact details can be found in the warranty booklet. The manufacturer ensures the availability of spare parts for at least 10 years after production date of this appliance.
