DAILY REFERENCE
GUIDE
THANK YOU FOR BUYING A IGNIS PRODUCT. You can download the Safety Instructions and the User
Manual, by visiting our website docs.whirlpool.eu and following the Instructions on the back of this
booklet.
PRODUCT DESCRIPTION
APPLIANCE
7
8
9
11
Service:
0000 000 00000
12
CONTROL PANEL
1
1.
ON-OFF / Reset button with indicator light
2.
Program selection button
3.
Salt refill indicator light
4.
Program indicator lights
5.
START/Pause button with indicator light
Questo manuale d'istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per
cerca il tuo prodotto tra le
Before using the appliance carefully read Safety Instructions.
2
3
migliori offerte di Lavastoviglie
1.
1
2.
3.
2
4.
5.
6.
3
7.
8.
4
9.
5
10. Detergent and Rinse Aid dispensers
6
11. Rating plate
12. Control panel
10
4
Ignis AIE 2B19 A
Foldable flaps
Upper rack height adjuster
Upper spray arm
Lower spray arm
Filter Assembly
Salt reservoir
5
o
EN
1
Advertisement
Table of Contents
Related Manuals for Ignis AIE 2B19 A
Summary of Contents for Ignis AIE 2B19 A
- Page 1 Lavastoviglie DAILY REFERENCE GUIDE THANK YOU FOR BUYING A IGNIS PRODUCT. You can download the Safety Instructions and the User Manual, by visiting our website docs.whirlpool.eu and following the Instructions on the back of this booklet. Before using the appliance carefully read Safety Instructions.
- Page 2 FIRST TIME USE SALT, RINSE AID AND DETERGENT ADVICE REGARDING THE FIRST TIME USE FILLING THE RINSE AID DISPENSER Rinse aid makes dish DRYING easier. The rinse aid dispenser A should be After installation, remove the stoppers from the racks and the retaining filled when the dark optical indicator on the dispenser door C becomes elastic elements from the upper rack.
- Page 3 PROGRAMS TABLE Duration of wash Water Energy Program program consumption consumption (h:min) (litres/cycle) (kWh/cycle) 50° 3:20 12.0 1.05 Intensive 65° 2:30 16.0 1.50 Mixed 55° 2:25 16.0 1.35 Fast&Clean 28’ 45° 0:28 0.60 Pre-Wash 0:10 0.01 ECO program data is measured under laboratory conditions according to European Standard EN 60436:2020. Note for Test Laboratories: For information on comparative EN testing conditions, please send an email to the following address: dw_test_support@whirlpool.com Pre-treatment of the dishes is not needed before any of the programs.
- Page 4 LOADING THE RACKS UPPER RACK LOWER RACK Load delicate and light dishes: For pots, lids, plates, salad bowls, glasses, cups, saucers, low salad cutlery etc. Large plates and lids bowls. should ideally be placed at the si- des to avoid interferences with the spray arm.
- Page 5 DAILY USE 1. CHECK WATER CONNECTION The machine will switch off automatically during certain extended Check that the dishwasher is connected to the water supply and periods of inactivity, in order to minimise electricity consumption. If the crockery is only lightly soiled or if it has been rinsed with that the tap is open.
- Page 6 CARE AND MAINTENANCE CLEANING THE FILTER ASSEMBLY CLEANING THE SPRAY ARMS Regularly clean the filter assembly so that the filters do not clog and On occasions, food residue may become encrusted onto the spray arms that the waste water flows away correctly. and block the holes used to spray the water.
- Page 7 TROUBLESHOOTING In case your dishwasher doesn’t work properly, check if the problem can be solved by going through the following list. For other errors or issues please contact authorized After-sales Service which contact details can be found in the warranty booklet. The manufacturer ensures the availability of spare parts for at least 10 years after production date of this appliance.
- Page 8 400011500068 09/2020 jk - Xerox Fabriano...
