Quick reference guide
PROGRAM SELECTION
START/RESUME BUTTON
BUTTON
Push this button to start the selected program: the
Push "Programs" button
indicator lights up and goes off at the end of the
(repeatedly) until the indicator
program.
of the required program lights
When the door is opened during a washing cycle,
up (see "Table of programs"
the cycle is temporarily paused: the Start indicator
below).
blinks. To resume the cycle close the door and
push Start button again.
Table of programs
P
Programs
1
Pre-Wash
cold
2
Quickwash 40°C
2)
3
50°C
Eco
4
Intensive
70°C
5
Half Load
50°C
1) Program data obtained in conformity with European standard EN 50242, obtained under normal conditions
(without additional options) and may vary depending on conditions. Differences of up to 20 minutes are possible
with sensor programs as a result of the appliance's automatic calibration system.
2) Reference program for energy label in compliance with EN 50242 regulations. - Note for Testing Institutes: for
detailed information on the EN/Standard loading comparison test and other tests, contact the following address:
"nk_customer@whirlpool.com".
CANCEL/OFF BUTTON
Push this button to switch off the control panel.
If pressed when a program is running it cancels the
program ongoing draining water for 1 minute.
If pressed when the dishwasher is switched off it
drains any possible liquids from dishwasher (1
minute process).
If the indicator flashes repeatedly, see page 6 -
chapter "What to do if ...".
Deter-
Loading instructions
Crockery to be washed later.
Lightly soiled crockery, with no
dried-on food.
Normally soiled crockery.
Energy-saving program.
Recommended program for heavily
soiled crockery, especially suitable
for pans and saucepans.
Ideal for washing a half load of
lightly or normally soiled crockery.
BEFORE USING THE APPLIANCE FOR THE FIRST TIME CAREFULLY READ
THIS QUICK REFERENCE GUIDE AND THE ASSEMBLY INSTRUCTIONS!
THE CONTROL PANEL OF THIS DISHWASHER ACTIVATES PUSHING
AUTOMATICALLY AFTER 30 SECONDS IF NO CYCLE HAS STARTED.
Consumption
gent
1)
Litres
kWh
Minutes
—
5.0
0.02
10
X
13.0
0.70
30
X
15.0
1.05
165
X
15.0
1.50
140
X
13.0
1.00
130
ADL 444
ANY BUTTON EXCEPT CANCEL/OFF BUTTON.
FOR ENERGY SAVING THE CONTROL PANEL DEACTIVATES
Chart
5019 596 01528
GB -1-
