Summary of Contents for Beko BMTD37146W
- Page 1 Dryer User Manual BMTD37146W 2960313910/ EN/ / 24/07/2024 10:58...
-
Page 2: Please Read This Guide Before
1Please read this guide before! Dear Customer, Thank you for choosing Beko product. We hope you get the best efficiency from this product which has been manufactured with high quality and state of the art technology. Please make sure you read and understand this guide and supplementary documentation fully before using the product. -
Page 3: Table Of Contents
Program Selection and Consump- Table of Contents tion Chart........1 Please read this guide before! ..Auxiliary Functions ......21 2 Safety Instructions......Warning Indicators......22 Starting the Program ..... 22 Intended Use........Child Lock........23 Safety of Children, Vulnerable Changing the Program After It Is Persons and Pets ...... -
Page 4: Safety Instructions
2 Safety Instructions • This section includes the in- • Product can only be used to formation necessary to pre- dry and ventilate laundry which vent the risk of personal injury are washed with water and dry- or material damage. Our com- ing machine safe. -
Page 5: Electrical Safety
• Cleaning and user mainten- • Do not use an extension cord, ance operations should not be multi-plug or adaptor to oper- performed by children unless ate the product. supervised. • The product should not be • Keep the packaging materials powered via an external switch away from children. -
Page 6: Installation Safety
• Do not use the extruding parts • The gap between the product of the product (such as the and the floor should not be re- loading door) to move the duced via materials such as product. rugs, pieces of wood and •... - Page 7 • While placing the product, en- • Do not plug the product to sure that the back wall does loose, broken, dirty, greasy not come in contact with any sockets or sockets that have extrusion (a water tap, elec- come out of their seats or trical outlet etc.).
-
Page 8: Usage Safety
the environment or the objects the products on a sturdy floor around it. The carrier floor with an adequate load carrying must be solid and stable. capacity. • When the product is placed on • Washing machine cannot be the washing machine, their placed on top of the drying ma- combined weight when full chine. - Page 9 able to remove all the items open fire, appropriate ventila- rapidly and to lay them down in tion should be provided (For such a way that heat will be models with flue). dissipated. • Do not operate the product to- •...
-
Page 10: Maintenance And Cleaning Safety
• Do not operate the faulty or • Clean the accumulated fiber damaged product. Unplug the on the fins of the evaporator product (or turn off the fuse to behind the filter drawer with a which it is connected) and call vacuum cleaner. -
Page 11: Environmental Instructions
3 Environmental instructions 3.1 Compliance with the WEEE Regu- 3.3 Standard Conformity and Test In- lations and Waste Disposal formation EU Declaration of Con- formity This product does not contain The development, manufacturing the dangerous and prohibited and sales phases of this product is materials indicated in the "Reg- conducted in conformity with the ulation on The Control of... -
Page 12: Technical Specifications
4 Technical Specifications Height (adjustable) (cm) 84,6 * / 86,6 ** Width (cm) 59,8 Depth (cm) 54,5 Capacity (max.) (kg) 7*** Net weight (±10%) (kg) Voltage Power See the type label**** Main Model Code * Min. height: Height with the adjustable legs closed. ** Max. -
Page 13: General Appearance
5 General Appearance 1 Upper table 2 Control Panel 3 Type label 4 Kickplate opening handle 5 Ventilation grills 6 Adjustable legs 7 For the models with tank located at 8 Fiber filter the bottom, the water tank is inside the kickplate 9 Loading door 10 Power cord... -
Page 14: First Operation
6 First Operation Remove the protective foil and adhesive ad- After the device is installed vertising label if available in your product. • operate the machine for the first time ac- cording to user’s manual. However, please do not remove the labels (e.g. -
Page 15: Removing The Shipping Safety Group
Ignore this warning if the product system does not contain R290*. The dryer has R290 refrigerant gas. R290 is an environmentally friendly but flammable cooling gas. Make sure the air intake of the dryer is open and well ventilated. Keep pos- sible flame sources away from the dryer. -
Page 16: Adjusting The Legs
• If the product is connected via direct dis- Fix the water discharge hose at a charge, remove the hose connections. maximum height of 80 cm. Ensure that the water discharge The drying machine is recommen- hose does not get kinked, collapsed ded to be moved in upright posi- or pressed on between the dis- tion. -
Page 17: Preparation
8 Preparation 8.4 What to Do for Energy Saving Read the “Safety Instructions” first! Use the highest possible spinning cycle as you wash the laundry. Therefore you can re- 8.1 Laundry Suitable for Drying in duce the drying period and reduce energy Drying Machine consumption. -
Page 18: Correct Load Capacity
8.5 Correct Load Capacity age or product damage. For each program, follow the maximum loading capacity. Be- low you can see the laundry and their ap- proximate weight. Duvet Cover Set: 1000-1500 g Flat Sheet: 350-500 g Table Cover: 250-700 g Towel: 350-700 g Dress: 350-500 g Denim Trousers: 500-700 g... -
Page 19: Symbols
9.2 Symbols 9.3 Preparation of Drying Machine • Plug the drying machine. • Open the loading door. • Push and close the loading door. • Place the laundry in the drying machine without jamming them. EN / 19... -
Page 20: Program Selection And Consumption Chart
• Ensure that no laundry is jammed to the loading door. • Do not close the loading door with force. • Select the desired program by using On/ Off program selection button and the ma- chine will turn on. • Selecting the program with the On/Off program selection button does not mean that the program will get started. -
Page 21: Auxiliary Functions
You can dry your delicate clothes suitable for drying or clothes that are recommended for Gentle Care 1200 hand wash (silk blouses, thin underwear etc.) in low temperatures. Dry 1 cotton or synthetic bedding set by clos- Bedding 1000 ing the button / zipper Turn clothes such as down coats, jackets in- Down Wear side out for drying. -
Page 22: Warning Indicators
Audible Warning 2. Select the desired program and repeat the End Time selection process. Drying machine makes an audible warning when the program is completed. Press the Cancelling the End Time Function “Audible Warning” button if you do not want If you want to cancel the end time count- audible warning. -
Page 23: Child Lock
Start/Standby and Drying indicators turn on 1. For example, turn the On/Off/Program to show that program has started. Selection button to select the Extra Dry program in order to select the Extra Dry 9.8 Child Lock program instead of Ironing Dryness after pressing the Start / Standby selec- The drying machine has a child lock which prevents the program flow from being af-... -
Page 24: Cancelling The Program
9.10 Cancelling the Program turn on. Loading door can be opened and drying machine is ready for another opera- If you want to cancel the program and ter- tion. minate the drying operation for any reason Turn the On/Off/Program Selection button after the drying machine starts running, to On/Off position in order to turn the dry- turn the On/Off/Program Selection button... - Page 25 4. Open both of the fiber filters (outer and inner filters) and remove the fibers with your hands or with the brush on the air deflector. You can also clean the hair in the filters with a vacuum cleaner. 6. Insert the fiber filters on one another and place them back in their place.
-
Page 26: Cleaning The Sensors
Condensed water is not potable wa- ter! Do not ever remove the water tank while the program is running! If you forget to empty the water tank, during the next drying sessions the machine will stop operating when the water tank com- pletely fills and a Water Tank warning icon will blink. -
Page 27: Cleaning The Condenser
3. If fiber is accumulated in the funnel on 3. Pull the brush to the left to remove it. the water tank, remove it under running You can use the cleaning brush to clean water. the fiber accumulated on filter, metal surface of condenser and loading door. - Page 28 When the air deflector cover is re- After cleaning the filter, door and the con- moved, it is normal to have water at denser, drag the brush to the right and lock the plastic section in front of the it in its place. condenser.
-
Page 29: Troubleshooting
11 Troubleshooting Drying operation takes too long. Drying machine does not turn on or pro- gram cannot be started. Drying machine • Fiber filter (interior and exterior filters) does not run after it is configured. pores may be clogged. >>> Wash the fiber filters with warm water and dry. - Page 30 • Water discharge hose might have folded. • Filters of the machine may not have been >>> If the product is connected directly to installed.>>> Install the fiber filters (in- the water discharge check the water dis- ternal and external) or the environment- charge hose.
- Page 31 The odour in the laundry does not decrease in the deodorization program (In products with deodorization function). • The amount of laundry maybe higher than recommended. >>>Load desired amount of laundry. • The time of steam application may be low. >>> Select longer time for steam ap- plication Wi-Fi icon flashes continuously (for mod- els featuring HomeWhiz Function).
-
Page 32: Product Information Voucher
12 Product Information Voucher It complies with the Statutory Commission Regulation (EU) No 392/2012. Supplier name or trademark BEKO Model name 7188303470-BMTD37146W Normal capacity (kg) With flue Drying Machine type With con- • denser Energy efficiency class (1) Annual Energy Consumption (kWh) (2) 212.0... - Page 33 EN / 33...
