Page 2
Preparation before Operation................11 Examining Features ..................14 Operating the Air Purifier ................16 Using the Extra Functions ................17 Overall Air Quality ....................19 SMART FUNCTIONS LG ThinQ Application ..................20 Smart Diagnosis ....................21 MAINTENANCE Maintaining the Product .................22 TROUBLESHOOTING Before Calling for Service................27 APPENDIX...
Page 3
SAFETY INSTRUCTIONS SAFETY INSTRUCTIONS READ AND SAVE THESE INSTRUCTIONS The following safety guidelines are intended to prevent unforeseen risks or damage from unsafe or incorrect operation of the appliance. The guidelines are separated into ‘WARNING’ and ‘CAUTION’ as described below. Safety Messages This symbol is displayed to indicate matters and operations that can cause risk.
Page 4
SAFETY INSTRUCTIONS responsible for their safety. Children should be supervised to ensure that they do not play with the appliance. • The fan is not a toy. It should not be played with or placed where young children can reach it. •...
Page 5
Operation • If the appliance is immersed in water, stop using it and contact an LG Electronics Customer Information Center. • If there is a gas leakage (isobutane, propane, LNG, etc.), do not touch the appliance or power plug and ventilate the area immediately.
Page 6
SAFETY INSTRUCTIONS Maintenance • Dispose of the packing materials (vinyl, styrofoam, etc.) to keep them out of reach of children. • Take care not to injure or pinch yourself when you detach and reattach parts of the appliance. • Turn off and unplug the appliance before cleaning it or replacing the filter.
Page 7
SAFETY INSTRUCTIONS CAUTION INSTRUCTIONS CAUTION • To reduce the risk of minor injury to persons, malfunction, or damage to the product or property when using this product, follow basic precautions, including the following: Installation • Do not tilt the appliance to pull or push it when transporting. •...
Page 8
SAFETY INSTRUCTIONS • Do not operate the appliance with wet hands. • Do not let the moisture from a humidifier directly touch the appliance. • Do not use the appliance while it is not in an upright position. • Do not use the appliance near objects vulnerable to heat. •...
Page 9
OPERATION OPERATION • The exterior or components of the product may vary depending on the model. Product Overviews Air Purifier • Air is sucked into the air purifier through the Air Outlet air inlet. • Purified air from the filter is emitted. •...
Page 10
OPERATION Filter Deodorization Filter • Minimizes smog causing materials (SO , NO ), sickening house syndrome materials (toluene, formaldehyde), domestic odor, and sulphur compounds. Safe Plus Filter • Minimizes PM1.0, allergen materials, bacterial and viral from the air. Filter Handle •...
Page 11
Hold the top end of the front cover of the product with the LG logo and pull it slightly to achieve separation. Install the filter into the product. • Make sure that the side with the filter handle( ) is facing upward.
Page 12
OPERATION • If there is not enough room for air suction, the To install the cover again, insert the fixing part air purification performance may degrade. at the bottom of the cover into the fixed groove at the bottom of the product and then close it. •...
Page 13
OPERATION • Transport the product safely by holding the Plug the power plug of the adapter into the handle( ) at the bottom of the product with outlet. both hands. NOTE • Hold the product and connect or disconnect the adapter horizontally.
Page 14
Control Panel Start/Stop Button Turns the product on and off. • To prepare the product to connect to Wi-Fi through the LG ThinQ application, press and hold the button for 3 seconds or more. Mode Button Use it to set the mode.
Page 15
OPERATION Status Panel Add-on Display Icon Description Lights up when the lock function is set. Lights up when the Wi-Fi function is activated. The color indicates the life of the filter. For detailed information, refer to Replacing the Filters. Display operating mode It indicates the mode that is operating currently.
Page 16
OPERATION Operating the Air Purifier Using Purify Mode The air purifier purifies indoor air. Start/Stop Press the Mode button to choose the Purify mode. Press the Start/Stop button to turn on or off the air • Each time you press the button, the operating purifier.
Page 17
OPERATION • You cannot set the operation time in Sleep mode Press the Start/Stop button to turn on the separately. To cancel the Sleep mode, press the product. Mode button in the same way as in setting it. Using Pet Mode (Only for models with Pet mode) This is a dedicated mode for pet owners.
Page 18
OPERATION Press the Lock button for 3 seconds or longer during operation. • The lock icon is displayed on the status panel when the lock function is set. NOTE • You can turn off the lock function in the same way as turning it on.
Page 19
• The color of the overall air quality indicator is determined based on the concentration of particulate matter (PM). • PM concentration values are based on the data sheet provided by the sensor manufacturer. • The PM concentration measurement was tested using LG Electronics’ standard test materials.
Page 20
• LG ThinQ is not responsible for any network • Functions may vary by model. connection problems or any faults, malfunctions, or errors caused by network connection.
Page 21
• If the firewall on your wireless router is enabled, opensource.lge.com. disable the firewall or add an exception to it. LG Electronics will also provide open source code to • The wireless network name (SSID) should be a you on CD-ROM for a charge covering the cost of combination of English letters and numbers.
Page 22
• The filter must be replaced at the end of its lifespan, and the cost of replacement filters is not covered under the warranty. To purchase new filters, contact an LG Electronics Customer Information Center or visit the website at www.lg.com •...
Page 23
MAINTENANCE Hold the top end of the front cover of the Close the sensor cover. product with the LG logo and pull it slightly to achieve separation. NOTE • Do not wipe the sensor with any substances other than water. It may cause a appliance to malfunction.
Page 24
MAINTENANCE Using a vacuum cleaner or soft brush, remove any dust from the pre-filter surrounding the filter. CAUTION • Do not clean the filter with water. The service life of the filter may be reduced. • Be careful not to damage the pre-filter when using a vacuum cleaner.
Page 25
MAINTENANCE Replacing the Filters • Filter Status Notification on the status panel is reset and the time for Filter Status Notification is Checking Filter Status Notification initialized. : Filter Status Notification Color Green Orange Status The filter Prepare Replace has been for filter the filter.
Page 26
MAINTENANCE Store the packaged appliance at a shaded place. CAUTION • Do not store the appliance at a humid place or at a place exposed to the direct sunlight. Otherwise the appliance may be deformed, malfunction or generate odor.
Page 27
TROUBLESHOOTING TROUBLESHOOTING Before Calling for Service Please check the following before calling for service. If the problem persists, contact your local service center. Operation Symptoms Possible Cause & Solution The product does not Is the power plug disconnected? power on. •...
Page 28
• For best results, ventilate the area first by opening a window or using a vent hood. Use the appliance only to minimize odors left after ventilating the area. LG ThinQ Symptoms Possible Cause & Solution The product and the...
Page 29
TROUBLESHOOTING Symptoms Possible Cause & Solution The product and the Is your smartphone using mobile data rather than Wi-Fi? smartphone cannot be • In the smartphone's settings, turn off Mobile Data, turn on Wi-Fi, and then connected through Wi- register the product. Does the name (ID) of the wireless router contain special characters? •...
Page 30
APPENDIX APPENDIX Information APPLIANCE SPECIFICATIONS • Appearance and specifications may vary without notice to improve the quality of the appliance. Name AS35GGW10, AS35GGW20 Power DC 24 V Exterior Dimensions 240 mm x 240 mm x 500 mm AC/DC Adapter Manufacturer FOSHAN SHUNDE GUANYUDA POWER SUPPLY CO.,LTD.
