OWNER'S MANUAL
AIR PURIFIER
Read before using product (safety instruction), use properly.
About ensuring users safety and property.
Product warranty card is enclosed with the user manual.
After careful read through the user manual, do keep it in a handy place.
PS-P809 Series
www.lg.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PS-P809 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for LG PS-P809 Series

Summary of Contents for LG PS-P809 Series

  • Page 1 Read before using product (safety instruction), use properly. About ensuring users safety and property. Product warranty card is enclosed with the user manual. After careful read through the user manual, do keep it in a handy place. PS-P809 Series www.lg.com...

  • Page 2: The Advantages Are

    Multidimensional Catalyst Sterilization System - Sterilized by HEPA filter Inside, and once again sterilized outside. Only LG air purifier can sterilize perfectly both inside and outside. Easy-use refreshing HEPA filter system. - Easy to check out the filter status immediately through the convenient filter separating system.

  • Page 3: Table Of Contents

    Table of Contents Before Use During Use ❏ The advantages are ..........2 ❏ Operation Mode ..........21~24 – Air Purifying Operation ❏ Cautions for Safety ..........4~13 – Speed Mode ❏ Installation ............... 14 – Automatic Mode ❏ Air purifier Start Guide ..........15 –...

  • Page 4: Cautions For Safety

    Cautions for Safety The following precautions related to safety marked as follows are to prevent unexpected danger or damage by safely and accurately using the product. Warning / Caution This is the symbol to get attention focused for the details and operations that can cause any type of danger.
  • Page 5 Cautions for Safety Warning installation Do not change or extend power never use an octopus feet-type never use the damaged or loose cords at random. of socket. power cords. Otherwise, it may cause fire or Unreasonable use of power may Otherwise, it may cause fire or electrical shock.
  • Page 6 Cautions for Safety Warning Don’t keep and use combustible if abnormal noise comes or smell Don’t put heavy things on power gas, flammable substance or smoke emits from the product, cords or take care so that they around the product. pull the power plugs out and call should not be pressed under the our service center.
  • Page 7 Cautions for Safety Warning operation securely insert power Pull power plugs by never damage, process, Do not hold the power plugs to the end so that grasping the head and never forcedly bend, twist, pull, cable to pull out the power they should not shake.
  • Page 8 Cautions for Safety Warning Do not lay obstacles around the Do not cover with a rug, cushion etc Do not use thermal appliances product. over power cords. near power cords. Otherwise, it may cause failure. Power cords may be damaged and Otherwise, it may cause fire or result in fire and electrical shock in electrical shock.
  • Page 9 Cautions for Safety Warning Do not move the product by Do not put coffee or all types of Contact with the service center holding the front-panel. beverage on the air discharge for repairing the product. May cause electric shock or damage outlet.
  • Page 10 Cautions for Safety Cautions installation Maintain distance of more than Avoid a place near fire arms or Do not use the product for 1m when installing the product heating devices or subject to removing toxic gas as Co. near tV or audio. direct sunlight.
  • Page 11 Cautions for Safety Cautions Do not use except AC 220 V. When using the product with a Do not install the air purifier on Otherwise, it may cause fire or burner within the airtight room, the transportation vehicle (car, electrical shock. sometimes let fresh air into the ship etc.).
  • Page 12 Cautions for Safety Cautions operation Do not use the product for Don’t use strong detergent never operate or stop the Pull power plugs out special purpose such as animals like solvent, etc but use a product while inserting or when not using the or vegetables, precision machine soft cloth.
  • Page 13 Cautions for Safety Cautions Do not let the moisture Do not use this product Pull power plugs out for Do not open the front from the humidifier directly as ventilating fan or so. cleaning. panel during the touch the product. It may cause shorten the Otherwise, it may cause fire operation of the product.

  • Page 14: Installation

    Installation Places to Install Mainframe • places with handy power connections • places with no obstacle to clog air inlet • places with horizontal surface and rich air circulation Install the air purifier on moving objects (car or ship etc) Warning may cause the product defect, therefore do not install on those places.

  • Page 15: Air Purifier Start Guide

    Air Purifier Start Guide turn off air purifier when cleaning. • Cleaning the air purifier with opened windows would disturb the natural air circulation to cause intake too much particles, it may shorten the filter life. After complete cleaning process with enough air circulation, close the windows, turn on the air purifier is the appropriate way to purify air.

  • Page 16: Name Of Each Part

    Name of Each Part Mainframe operation part Filter case (Dual protection filter + Allergen filter + Triple care filter + HEPA filter) sensor part (dust sensor) Cleaning brush for dual protection filter sensor part Do not rotate it with your hand. It may cause failure of product.
  • Page 17 Name of Each Part operation Display and Controller Airflow Display operation Display sanitary Purification Display Filter Check Display Check the polluted condition of filter when turning on Filter Cleaning Display the lamp. Check the filter in case of serious pollution. reservation/Filter Dust/odor Display Cleaning time...

  • Page 18: Filters System

    Name of Each Part Anti-bacteria filter case Dual Allergy filter Triple care filter HEPA filter protection filter Filter system (it introduces only filter part.) Filter name Function  Dual remove big particles This filter has anti-bacteria, anti-mildew, big particles filtering functions. protection Anti-bacteria function These 3 functions may extend the filter replacement frequency.

  • Page 19: Remote Controller

    Name of Each Part remote Controller Power on/off button button uses to start or close this product Fan speed button Set Fan speed operation Mode Button Operation Selection (Manual, Automatic, Speed Purification, Sleep, Yellow Sandstorm) off timer Button ion button It sets the time to turn off the purifier.

  • Page 20: Remote Controller Guide

    Remote Controller Guide First operation of remote controller Battery replacement Caution Open the battery lid Press only 1 key at one time Press several keys at the same time, the remote controller does not work properly Do not stand on the remote controller or punch it Ensure to install batteries as...

  • Page 21: Operation Mode

    Operation Mode Air Purifying Operation Purify Indoor Air. Press on/off button, after a ‘Di-ri-Lin’ sound, start working as the led light on. (Reference according to the following ‘preparatory operation’ category) The air outlet on top will exhaust fresh air. • Press On/Off button again to turn off. •...

  • Page 22: Speed Mode

    Operation Mode Speed mode User may manually adjust fan speed. Press on/off button. switch to the speed mode by pressing the mode button. Press the fan speed button to choose expected fan speed • Default fan speed is weak. • When restart under speed mode, system will retrieve to the previous fan speed.

  • Page 23: Quick Clean Mode

    Operation Mode Quick Clean Mode It operates strongly in a moment and purifies indoor air. Press on/off button. switch to the quick clean mode by pressing the mode button. • When pressing airflow button in the speed purification operation, it switches into the manual operation and it operates on “LOW”...

  • Page 24: Sandstorm Mode

    Operation Mode Sandstorm Mode Purify indoor air effectively when the sandstorm occurs. Press on/off button. switch to the sandstorm mode by pressing the mode button. • Press fan speed button under yellow sandstorm mode will switch to speed mode and increase fan speed by one level. •...

  • Page 25: Additional Functions

    Additional Function ION Mode It generates sterilization ion which is harmless and removes various bacteria. Press on/off button. Press the ion button to choose expected function. • Whenever press one time, it switches to sanitary purification deactivation → sanitary purification in order. →...

  • Page 26: Filter Cleaning Function

    Additional Function Filter Cleaning Function Remove large particles. When operating Filter Cleaning Function, the purifier operation stops. The cleaning brush for dual protection filter starts rotating to remove the particles settled on the filter. The particles removed from the dual protection filter come together into the dustbin lower.

  • Page 27: Off-Timer Operation Function

    Additional Function Off-timer Operation Function Automatically shut down after sleeping several hours. Example:shut down automatically after 3 hours Press on/off button. Press timer button to set 3 hours. • Each time pressing the button, operation time will increase 1 more hour. Selected time •...
  • Page 28 Additional Function Filter Check Lamp It will let you know filter cleaning cycle and its replacement cycle after use for a certain period. When turning on Filter Check Lamp, open the front panel while operating the purifier and check the filter. if it is polluted, wash or replace it.

  • Page 29: Exterior And Dust Sensors Cleaning Method

    Exterior and Dust Sensors Cleaning Method Exterior Cleaning Method Soak soft cloth with warm water, wipe the air purifier after wring dry. • Do not clean mainframe controller and indicator by alkaline liquid. Caution • Do not wipe air purifier’s surface by vitriol, hydrochloric acid or organic solvent.

  • Page 30: Filter Maintenance

    Filter Maintenance Ensure to shut down before cleaning. Hold knob then pull forward, open the front panel. Front Lift the knob of dustbin to the upper direction panel to pull it out. Pull the filter case out of the main unit. Place the filter case down on the even ground and lift the fixed hanger of dual protection filter to the upper direction to open it.
  • Page 31 Filter Maintenance Filter Maintenance Method Filter maintenance may vary depending on the environment. type of filter Classification Maintenance cycle Maintenance Method Clean the dual protection filter with a vacuum Dual About a month cleaner or a soft brush, and when the protection For washing refer to the Fig.

  • Page 32: Dustbin Cleaning

    Clean the dustbin (Cover the front panel after cleaning dustbin. Please cover it tightly, otherwise it doesn't operate.) Ensure that you turn off the power while operation. Pull the front panel forward to open. Front panel Lift the knob of dustbin to the upper direction to pull it out. Empty the dustbin.

  • Page 33: Maintenance

    Maintenance Ensure to run air purifier over 1 hour in shiny day, press on/off button to shut down. Plug out the power. Power plug Ensure to clean and protect air purifier’s mainframe. Use vinylbag to pack when store air purifier for an extended period of time, avoid dust or particle enter interior.

  • Page 34: Confirming Items Before Reporting Defect

    Confirming Items Before Reporting Defect When product goes wrong, before contacting the service center please confirm the following items. symptom Confirmation Procedures total malfunction • Has the power plug been pulled out? • Correctly connect with power point. • Does the remote controller have problems? • Replace the battery or adjust the battery(+, -) pole. •...
  • Page 35 • Clean dust sensor or filter. has problem. • Odor sensor level goes up? • LG air purifier is designed to detect polluted air, therefore odor sensor may not react to food odors. But odor removing filter will remove odor.

  • Page 36: Product Specification

    Product Specification The external dimension, design and product standard can change to improve the quality of the product. Model Name PS-P809 Series Power Supply 220 V~ 50 Hz Weight of Product 16 kg Appearance Size(mm) 475 (Width) x 680 (Height) x 300 (Depth)
