Page 1
Installation Guide Valve Trim K-T9492 M product numbers are for Mexico (i.e. K-12345M) Los números de productos seguidos de M corresponden a México (Ej. K-12345M) Français, page“ Français-1” Español, página“ Español-1” 085723-2-AF...
″Optional Temperature Limiting Adjustment″ section of this guide. The valve shuts off by water pressure. Do not force the handle in any direction. To turn the valve off, gently turn it to the ″OFF″ position. 085723-2-AF Kohler Co.
Page 3
Instead, use thread sealant tape on the shower arm threads. This will avoid clogging the showerhead spray outlets. Remove the temporary nipple from the shower elbow. Install the desired shower arm and showerhead according to the instructions packed with the showerhead. Kohler Co. 085723-2-AF...
Reinstall the collar on the valve stem with the setscrew against the side of the tab. Reinstall the O-ring, rotate the valve stem counterclockwise to shut the water off. Recheck the water temperature. Complete the information on the valve label (if supplied). 085723-2-AF Kohler Co.
Page 5
Press the cap on the knob so the dot is downward. Round Handle Position the knob on the valve stem and secure with a lock washer and screw. Install the grip ring and O-ring to the knob. Kohler Co. 085723-2-AF...
Page 6
Install the Faceplate and Handle (cont.) Press the cap on the knob so the dot is downward. 085723-2-AF Kohler Co.
