Schwinn 411:  My machine is making a squeaking noise
Follow this troubleshooting guide to help resolve noise issues with your Schwinn 411 Elliptical.
Some common complaints may include):
Squeaking noises

Follow these steps to troubleshoot the issue
Tools you may need:
100% silicone lubricant
Synthetic grease
Phillips head screwdriver
6mm hex/Allen wrench or the wrenches from the hardware
card included with your machine
1.
Regular weekly maintenance for your elliptical should include applying a small amount of 100% silicone lubricant to
the roller wheels. Please refer to the Maintenance section of your
instructions [13852.F].
2.
Make sure your elliptical is on a solid and level surface. Adjust the leveler feet as necessary to level your machine. Test
to see if the noise persists after adjusting the leveler feet [13852.A].
3.
Hardware can become slightly loosened over time or with frequent use. Use a Phillips head screwdriver and a 6mm
Allen wrench to tighten all the hardware installed during assembly. You can reference the
hardware should be tightened [13852.B].
4.
Inspect all the plastic shrouding/covers to make sure they are aligned, secured properly, and undamaged. If needed,
loosen/remove the hardware securing the shrouds and adjust its position. Retighten hardware once aligned properly
and test to see if the noise persists [13852.C].
5.
If the noise persists, apply a small drop of silicone-based lubricant on the rails and wipe them with a dry cloth or
towel. If too much lubricant is used, the roller wheel will not roll. Pedal on your elliptical slowly to ensure that the rolle
wheels are turning freely and to test for noise [13852.D].
6.
If the noise persists after regular lubrication (see the Maintenance section of your
Wheels [13852.E].
7.
If the roller wheels have already been replaced recently, please
noise to continue troubleshooting.

Looking for other noises to troubleshoot?
Schwinn 411:  My machine is making a rubbing noise
Schwinn 411:  My machine is making a clicking or clunking noise
Schwinn 411:  Why is my machine making a weird noise?
