12. Battery
13. Pushlock button
14. Saw chain
15. Cutter rail
16. Hex key
17. Dosing aid for chain oil (not illustrated)
2.2 Items supplied
Please check that the article is complete as
specifi ed in the scope of delivery. If parts are
missing, please contact our service center or the
sales outlet where you made your purchase at
the latest within 5 working days after purchasing
the product and upon presentation of a valid bill
of purchase. Also, refer to the warranty table in
the service information at the end of the operating
instructions.
•
Open the packaging and take out the equip-
ment with care.
•
Remove the packaging material and any
packaging and/or transportation braces (if
available).
•
Check to see if all items are supplied.
•
Inspect the equipment and accessories for
transport damage.
•
If possible, please keep the packaging until
the end of the guarantee period.
Danger!
The equipment and packaging material are
not toys. Do not let children play with plastic
bags, foils or small parts. There is a danger of
swallowing or suff ocating!
•
Original operating instructions
3. Proper use
This cordless branch chainsaw is designed for
for sawing trunks, branches, wooden beams and
boards etc., and for performing cross cuts and
longitudinal cuts. It is not suitable for cutting any
materials other than wood. This branch chainsaw
is not designed for tree-felling purposes.
The equipment is to be used only for its prescri-
bed purpose. Any other use is deemed to be a
case of misuse. The user / operator and not the
manufacturer will be liable for any damage or inju-
ries of any kind caused as a result of this.
Please note that our equipment has not been de-
signed for use in commercial, trade or industrial
Anl_18VMS2_12_1A_SPK7_PRINT.indb 152 Anl_18VMS2_12_1A_SPK7_PRINT.indb 152
GB
applications. Our warranty will be voided if the
machine is used in commercial, trade or industrial
businesses or for equivalent purposes.
4. Technical data
Motor power supply: ............................... 18 V DC
Idle speed n : .............................. Level 3300 rpm
0
Cutter rail length ...................................... 158 mm
Max. cutting length: ................................ 125 mm
Cutting speed at rated rpm: ......................4.8 m/s
Battery charger output voltage: .............. 20 V DC
Battery charger output current: ....................... 3 A
Charging unit
supply voltage: .................... 200-250V~ 50-60Hz
Battery type: ............................................... Li-Ion
Number of battery cells: ................................... 5
Battery capacitance: ................................. 2,5 Ah
Weight ........................................... approx. 1.1 kg
Chain type ........ Hangzhou Jingfeng Tools: 28 DL
Cutter rail type: Hangzhou Jingfeng Tools: 153 mm
Danger!
Sound and vibration
Sound and vibration values were measured in ac-
cordance with EN 62841-1 and EN 62841-4-1.
L sound pressure level ..................... 79.2 dB(A)
pA
K uncertainty .......................................... 2.4 dB
pA
L sound power level ........................ 87.2 dB(A)
WA
K uncertainty .......................................... 2.4 dB
WA
L sound power level guaranteed ......... 98 dB(A)
WA
Wear ear-muff s.
The impact of noise can cause damage to hea-
ring.
Total vibration values (vector sum of three direc-
tions) were determined in accordance with EN
62841-1 and EN 62841-4-1.
Handle under load
Vibration emission value front handle
a = 2.205 m/s
2
h
Vibration emission value rear handle
a = 2.205 m/s
2
h
K uncertainty = 1.5 m/s
