- Page 1 Captair ChemTrap H402 Standalone filtration system for fire proof and chemical storage cabinets Instructions & User’s Manual...
-
Page 2: Table Of Contents
Contents General ..................3 Safety notices ................3 The Erlab guarantee ..............4 Mounting the unit ..............5 Start-up ..................9 The connectivity principle ............ 11 Recommendations for the use of filters ......24... -
Page 3: General
The Erlab Services was set up to guarantee your safety. We would remind you that it is important to have the safety parameters validated before using the device for the first time and whenever it is used for a different application. -
Page 4: The Erlab Guarantee
Consumable items (including filters) and Captair Pyramid remain under warranty only until the first use. Erlab Inc. is the Sole US Distributor of Captair products and is not responsible for damage that occurs as a result of failure to follow instructions that are included with the original product. -
Page 5: Mounting The Unit
Captair ChemTrap H402 Standalone filtration system for fire proof and chemical storage cabinets... -
Page 6: Parts List
Parts list G21 H Smart Chemtrap G31 H Midcap H11042101 (AS) H11042201(BE+) H11042401 (F) H11042301 (K) Carbon filter H11012101 (AS) H11012201(BE+) 1P1C H11012401 (F) H11012301 (K) Particulate filter H11012021 (HEPA H14) Cover plate YTR G119009 EU = PIDEL076 Power cable GB = PIDEL090 CH = PIDEL106 RJ45 cable... - Page 7 Captair ChemTrap H402 Standalone filtration system for fire proof and chemical storage cabinets Connection from ChemTrap Connection to Safety Cabinet...
-
Page 8: Filter Installation
Filter installation Place filter horizontally (seal up). Close the Chemtrap by pushing firmly to allow correct airtightness. -
Page 9: Start-Up
Captair ChemTrap H402 Midcap Standalone filtration system for fire proof and chemical storage cabinets Start-up Having carefully followed the steps described in the installation guide, your Captair ChemTrap chemical storage cabinets is now ready to use. The power switch is located at the back of the control panel. -
Page 10: Description Of The Alarms
Filter The Molecode Note: filter has to be replaced. breakthrough detection value (Molecode is > the sensitivity Please get in touch with Erlab or your usual main- S/A/F setting for a tenance contact. option) period of 40s. 2 beeps 5 seconds... -
Page 11: The Connectivity Principle
Captair ChemTrap H402 Standalone filtration system for fire proof and chemical storage cabinets The connectivity principle An ecosystem designed for simpler use and safer protection Embedded service Erlab devices RJ45 Consultations + settings RJ45 Local network Consultation & Settings Consultations... - Page 12 Connect to your device Embedded service Direct connection on PC Conditions of use with data cable (RJ45) Hardware requirements 1 PC + 1 cable Parameters Monitoring + Controlling Data access One unit Historical data access Historical data download Alerts, Notifications Multiple units monitoring Multiple user accounts Automatized status report...
- Page 13 Captair Chemtrap H402 Standalone filtration system for fire proof and chemical storage cabinets...
-
Page 14: Parameters Settings
You enter the « Status » page and you can have access to the embedded software. access to the « Settings » using the following cre- dentials: Apply the following procedure Login : erlab / Password : smart Page is not accessible Modify computer network parameters (windows 10) Network... - Page 15 Captair ChemTrap H402 Standalone filtration system for fire proof and chemical storage cabinets Access to the Network and sharing center (windows 10) Left click Left click Access to the network connection (windows 10) N.B : This confirms N.B : This confirms...
- Page 16 Enter compatible network parameters as indicated below (windows 10) Left click Left click Left click Left click...
- Page 17 Captair ChemTrap H402 Standalone filtration system for fire proof and chemical storage cabinets Write down your existing parameters before changing them in order to be able to set your initial parameters after the operation! Enter the following Enter the following...
- Page 18 Access the network and sharing center (windows 11) Left click Left click Access the network connection (windows 11) Left click Left click...
- Page 19 Open your web browser again, type again the following IP address 192.168.0.200 and validate • OK : You are connected to the embedded software You enter the « Status » page and you can have access to the « Settings » using the following credentials: Login : erlab / Password : smart...
- Page 20 Administrator interface description (not available for Midcap version) Open your web browser, type the IP address into the address bar and validate to access administration interface. Status page description Choose active interface page Device ID: Model Device ID: serial number, MAC address, device status Unit location Option Molecode Gauge: indicates filter failure of the main carbon filter(s) Fan gauge: indicates the fan status...
- Page 21 Captair ChemTrap H402 Standalone filtration system for fire proof and chemical storage cabinets Access to the settings is protected by the following credentials: User name: erlab Password: smart...
- Page 22 Settings page details Device time and date settings Device network settings Mode: Selected IP protocol Hostname: Device name on network IP: IP address of the device MASK: network mask GW: Network gateway Modify network settings : Default mode : DHCP Each unit is identified with its hostname : ER-UNIT-S/N Hostname example for a chemtrap H Smart, S/N: 25698 Hosname will be: ER-H-25698...
- Page 23 Captair ChemTrap H402 Standalone filtration system for fire proof and chemical storage cabinets History page details Displays the device’s event log Used for downloading the log in .csv format...
-
Page 24: Recommendations For The Use Of Filters
Valipass usage certificate, to contact ERLAB or their usual distributor to arrange a new usage validation for the de- vice in question. Failing that and/or in the absence of information regarding device usage: ERLAB is unable to provide any guidance as to the predicted service life of the filter(s). - Page 25 Captair ChemTrap H402 Standalone filtration system for fire proof and chemical storage cabinets...
- Page 26 About Erlab The Erlab Research and Development laboratory Since 1968, Erlab has been a specialist, inventor and world leader in ductless, zero-emission filtering fume hoods for laboratories to provide total safety in chemical handling. Erlab filtration We provide technologies to protect laboratory staff from inhaling chemicals. This is made possible thanks to our Research and Development (R&D) department, which has continuously improved our filtration technology for more than 50 years.
