- Page 1 Captair Bio 321-391 Mobile ductless filtering PCR workstations Instructions & User’s Manual...
-
Page 2: Table Of Contents
Contents General ..................3 Safety notices ................3 The Erlab guarantee ..............4 Recommendation for implementation/positioning ..........5 Mounting the unit ..............6 Start up ..................13 The connectivity principle ............ 16 Fan setpoints per filtration column type ......28 Replacing the filters .............. -
Page 3: General
Captair Smart fume hood throughout its life cycle. The E.S.P. program (Erlab Safety Program) was set up to guarantee your safety. We would remind you that it is important to have the safety parameters validated before using the device for the first time and whenever it is used for a different application. -
Page 4: The Erlab Guarantee
Warranty will be successively renewed at each filters replacement and for the life time indicated on the Valipass® and/or or at the end of filter usage time. In order to benefit from Erlab extension of warranty offer, the following conditions shall be respected: •... -
Page 5: Recommendation For Implementation/Positioning
Captair Bio 321-391 Instructions & User’s Manual Recommendation for implementation/positioning Necessary space and dimensions - according to the EN 14175-5 standard 1,4 m. 2 m. 1 m. 3 m. 1 m. Pilier min 15 cm 0,30 m. 3 m. min 2,7 m... -
Page 6: Mounting The Unit
A1/A2... - Page 7 Captair Bio 321-391 Instructions & User’s Manual 321= IO115030002 Work surface - TRESPA® TopLab PLUS 391= IO116030002 321= IO115050002 Work surface - stainless steel 304L 391= IO116050002 321= Z7PIDREF213014 Back panel 391= Z7PIDREF223008 Left side panel Z7PIDVIE213033 Right side panel...
- Page 8 A1 x 1 A1/A2 A2 x 1 B x 1 C1 x 1 C2 x 1 I x 6...
- Page 9 Captair Bio 321-391 Instructions & User’s Manual D x 1 I x 7 E x 1 J x 1 K x 1...
- Page 10 Particulate filter Molecular carbon filter Pre-filter+ grid Filter column configuration 1C 1P 1C1P...
- Page 11 Captair Bio 321-391 Instructions & User’s Manual F x 2 O x 2...
-
Page 13: Start Up
Captair Bio 321-391 Instructions & User’s Manual Start up Calibrating the electronic anemometer Open the sash of the workstation to perform calibration. 1- Press and hold the mute button located on the front of the control panel while simultaneously switching on the main power button located behind the control panel (Off = O, On=I) 2- Release the mute button. - Page 14 Standard usage and decontamination of your Captair Bio Smart ductless filtering PCR workstation 1- Make sure that the unit is on (general switch at the back of the control panel on 1 position (cf. fig 1) and that the fan is off (button on the front panel (cf. fig 2) 2- Make sure that the front door is closed and turn on UV lamp(s) (UV button on the front panel (cf.
- Page 15 The rotation speed Fan fault (RPM) is +/- 10% of 3 beeps the fan setpoint. Press Mute 5 seconds Please contact Erlab or your Pulses The rotation apart usual maintenance contact. speed (RPM) Unserviceable is < 700 RPM Filtration...
-
Page 16: The Connectivity Principle
The connectivity principle An ecosystem designed for simpler use and safer protection Service on-board Erlab devices RJ45 Consultations + settings RJ45 Local network Consultations + settings... - Page 17 Automatized status report Download (except if local connection) The connectivity of Erlab devices allows for the remote setting and monitoring of one or more devices. After registering your product online, use eGuard : - Receive security alerts, - View your usage statistics,...
- Page 19 « Settings » using the following Apply the following procedure credentials: Login : erlab / Password : smart Please go to page 24 Page is not accessible: Modify computer network parameters...
- Page 20 Access to the Network and sharing center (windows 10) Left click Left click Access to the network connection (windows 10) N.B : This confirms N.B : This confirms your WIFI is your WIFI is Right click Right click disconnected! disconnected! Left click to access properties Left click to access properties...
- Page 21 Captair Bio 321-391 Instructions & User’s Manual Enter compatible network parameters as indicated below (windows 10) Left click Left click Left click Left click...
- Page 22 Write down your existing parameters before changing them in order to be able to set your initial parameters after the operation! Enter the following Enter the following parameters: parameters: Validate Validate Modify computer network parameters (windows 11) Network parameters Left click Left click...
- Page 23 Captair Bio 321-391 Instructions & User’s Manual Access to the Network and sharing center (windows 11) Left click Left click Access to the network connection (windows 11) Left click Left click...
- Page 24 Open your web browser again, type again the following IP address 192.168.0.200 and validate OK: You are connected to the embedded software You enter the « Status » page and you can have access to the « Settings » using the following creden- tials: Login : erlab / Password : smart...
- Page 25 Captair Bio 321-391 Instructions & User’s Manual Administrator interface description Enter the unit IP address into the address bar of your browser in order to access the embedded sotware. Status page details Choose active interface page Device ID: Model Device ID: serial number, MAC address, device status...
- Page 26 Access to the settings is protected by the following credentials: Login : erlab Password : smart...
- Page 27 Captair Bio 321-391 Instructions & User’s Manual Settings page details Device time and date settings Device network settings Mode: Selected IP protocol Hostname: Device name on network IP: IP address of the device MASK: network mask GW: Network gateway Modify network settings:...
-
Page 28: Fan Setpoints Per Filtration Column Type
Log page details Displays the device’s event log Used for downloading the log in .csv format Fan setpoints per filtration column type Unit / Type of filtration column 1C1P 2000 2400 2200 2800... -
Page 29: Replacing The Filters
Molecular filter HEPA filter H14 / ULPA Pre-filter Column Configuration 1C1P The table below summarises the different types of carbon filters that Erlab® offers along with their fields of application. Type AS For organic vapors HEPA H14 For particles ULPA U16... - Page 30 Filter Replacement Procedure For these operations, we strongly recommended that the user or maintenance technician wear the necessary safety equipment, including: safety glasses, lab coat and gloves Remove the protective shields on either Switch off the workstation side of the workstation Diconnect the power supply to the fan...
- Page 31 Captair Bio 321-391 Instructions & User’s Manual Models Captair Bio 321 - 391 Smart Unstack the filtration column(s) above the workstation. After carrefuly removing the filters from their packaging, assemble the column per the configuration below. If your column configuration changed,...
-
Page 32: Recommendations For The Use Of Filters
To ensure their safety, we invite users who have not had their application validated via the eValiQuest questionnaire or whose device is not covered by a Valipass usage certificate, to contact ERLAB or their usual distributor to arrange a new usage validation for the device in question. -
Page 33: Cleaning And Maintenance
Captair Bio 321-391 Instructions & User’s Manual Cleaning and maintenance Mechanical item checks Hinges: Hinges must be properly attached and must allow any items on the front side of the workstation to be instantly and easily lifted upward. Acrylic Parts: Ensure the transparency of the panels is a part of regular maintenance for the enclosure. - Page 34 About Erlab The Erlab Research and Development laboratory Since 1968, Erlab has been a specialist, inventor and world leader in ductless, zero-emission filtering fume hoods for laboratories to provide total safety in chemical handling. Erlab filtration We provide technologies to protect laboratory staff from inhaling chemicals. This is made possible thanks to our Research and Development (R&D) department, which has continuously improved our filtration technology for more than 50 years.
