www.cometsystem.com

MONITORING, DATA LOGGING AND

CONTROL SYSTEM

MS55

INSTRUCTION MANUAL

Basic Part

February 2025

Table of Contents

Need help?

Do you have a question about the MS55 and is the answer not in the manual?

Questions and answers

Summary of Contents for Comet MS55

Page 1 MONITORING, DATA LOGGING AND CONTROL SYSTEM MS55 INSTRUCTION MANUAL Basic Part February 2025...
Page 2: Table Of Contents
7.16. Problems with correct measurement ................40 7.17. Problems in communication with computer ..............41 8. RECOMMENDATION FOR OPERATION AND MAINTENANCE ........42 9. TECHNICAL DESCRIPTION AND PARAMETERS OF DATA LOGGER ......44 Note: Manual Appendixes are available in electronic pdf format at www.cometsystem.com. ie-ms2-MS55-06...
Page 3: Introduction
Ethernet interface etc.) • to monitor on-line measured values and states The basic model is data logger MS55D. Drawing (MS55D): Items marked Accessory are not included in delivery and it is necessary to order separately. ie-ms2-MS55-06...
Page 4 Architecture of measuring system with data logger MS55D: ie-ms2-MS55-06...
Page 5: General Safety Precautions
Configuration of data logger – read and change the data logger configuration by means of 2.1.3 the SW in part Configuration – Configuration of data logger (icon i). Detailed description of data logger configuration is in part DESCRIPTION of CONFIGURATION and MODES of DATA LOGGER. ie-ms2-MS55-06...
Page 6: Maintenance
Processes. • MS55 data logger does not enable to switch different configurations from the instrument keyboard during operation. To switch to different configuration use the PC program •...
Page 7: Rules For Mounting And Connection Of Data Logger
- working position is with input connectors downward The way of mounting the holder to data logger: Notes: horizontal working position for data loggers with thermocouple inputs is not suitable using of the original screws is required (longer screws can damage device)! ie-ms2-MS55-06...
Page 8 In cable routing follow rules of standards for installation of low current distribution (EN 50174-2), especially it is necessary to pay attention to avoid electromagnetic interference intrusion to the leads, transmitters, transducers and sensors. Do not locate cabling near sources of interference. ie-ms2-MS55-06...
Page 9 - do not connect cable shielding at end device side, if these device do not have terminal designed for shielding. Shielding must not be connected to outer metal parts of the device nor with other devices. Do not use shielding as a signal lead. ie-ms2-MS55-06...
Page 10 If system is not grounded properly, it is a danger of state, when system floats on variable potential against all other circuitry. It can cause communication dropouts, occasional resets and in extreme case damage of some peripherals. Especially when using pulse power sources (e.g. A1940) it is strongly recommended to ground the system. ie-ms2-MS55-06...
Page 11: Data Logger Interface Connectors
Connect wire to released terminal (circular hole behind the rectangular one) and close the terminal by removing the screwdriver. Notice: The entire input terminal block is possible to remove from data logger by pulling it up from the connector. Connection of leads: Read Technical parameters of inputs before connecting input signals ie-ms2-MS55-06...
Page 12 For connection of RS485 link for input module RS use e.g. shielded cable 2x2x0.5 mm where one pair can be used for power of transducers and second pair for link RS485. • It is recommended to terminate the link by resistor 120  at the beginning and end of the cable. ie-ms2-MS55-06...
Page 13: Mounting And Connection Of Output Relays Module Mp018
Pay attention to necessary safety (depending on the character of connected device). Relay module must be activated for proper function by means of SW – see Appendix No. 6. If data logger is delivered together with this module, function is activated from the manufacturer. ie-ms2-MS55-06...
Page 14: Mounting And Connection Of External Terminal With Display
50 m from data logger. Its function is identical with internal built-in display of MS55 (keyboard and display work in parallel). The part of the display is also audio indication working analogically as external audio indication unit connected to output ALARM OUT.
Page 15 + practically unlimited distance between computer and data logger (depend on coverage of operator signal) + SMS messages can be used - communication and SMS messages are charged by the GSM operator - operation reliability depends on third party ie-ms2-MS55-06...
Page 16: Connection Of Data Logger With Support Of Sms Messaging
Data logger consumption in different variations is specified in Appendix No. 1. Appendix No. 1 describes also several possibilities of data logger power back-up. ie-ms2-MS55-06...
Page 17: Control And Indication Components Of Data Logger
Error message can occur instead of measured value. Binary inputs display at the whole LCD bottom line user defined ENTER MENU description of state closed/open. In case value is not available or is not correct error message is displayed – see Appendix No. 8. ie-ms2-MS55-06...
Page 18 If Smoked Ham no process is needed use selection No process. Press ENTER key to activate selected process. Press MENU key to leave the display without storing new ENTER MENU process. cca 5 s ie-ms2-MS55-06...
Page 19 ENTER key to confirm the selection. RS232 Adjusted communication interface must correspond with physical connection and with SW configuration. If you choose selection Ethernet-DHCP, IP address is set and gate MENU ENTER address to 0.0.0.0, network mask is set to Default (0). ie-ms2-MS55-06...
Page 20 Setting is analogical as for IP address. This selection is available only for active Ethernet interface. Gate IP address: Be careful in gate IP address setting. Incorrectly set gate address can cause network conflict or other complications. Always consult IP address setting with network administrator. ENTER MENU ie-ms2-MS55-06...
Page 21: Alarm Out
Self test of data logger internal voltage. First value indicates approximate power voltage (9 to 30 V, see technical Selftest: parameters). Second value is voltage of negative source (-2V to 3.0V -6V) and third value is voltage of internal back-up battery (2,6V to 3,3 V). ENTER MENU ie-ms2-MS55-06...
Page 22 (corresponds to Error1) and value 65535 (corresponds to Error 2) indicates converter upper limitation. With counter inputs binary state of counter is displayed. With binary inputs state of ENTER MENU input (ON/OFF) is displayed and with RS485 input symbols „--- “ are displayed. ie-ms2-MS55-06...
Page 23: User Program For Data Logger
If SW services several data loggers at the same time, you will be asked to choose data logger from the list before each communication with data logger. In the mode Display all data loggers are displayed in parallel (with the exception of those connected via modem). ie-ms2-MS55-06...
Page 24: Basic Items In Menu Program
Item of menu Display - online visualization of measured values on the computer, reading interval can be set in section File-Options, bookmark Display (in basic version it is fixed to 10s, in optional version can be set from 10 s). In suitable configuration the mode can be shared on several computers. See Application notes. ie-ms2-MS55-06...
Page 25: Description Of Configuration And Data Logger Modes
For USB connection you can use higher speed (in case it is supported by data logger). For Ethernet interface cannot be changes. For RS485 with larger networks a need to decrease the speed can appear. ie-ms2-MS55-06...
Page 26 Recipient of e-mails 1-3 - e-mail addresses of recipients. E-mails will be sent to those addresses in case of selected alarms Sender - enables to set addresses of the e-mail sender. Selection Original sender sets sender name to <data logger name>@IP address Send testing e-mail - sends testing e-mails to selected addresses Bookmark SNMP: ie-ms2-MS55-06...
Page 27: Bookmark Profile
• SMS phone number list – if you use sending of SMS messages after alarm creation, then enter here telephone numbers for sending messages. Enter numbers in international format with country code, e.g. 0049... or +49..ie-ms2-MS55-06...
Page 28: Bookmark Ch
Address of connected device, Maximum waiting etc. – setting of RS485 input, for more information see Appendix No. 3. 6.5. Bookmark Ch.. Measuring & recording • tick Input channel is measuring and fires alarms to enable this channel for measuring, ie-ms2-MS55-06...
Page 29 By means of continuous and conditional record situation can be solved, when device operation is monitored. In case of its trouble-free operation record with long logging interval is sufficient, but in case of failure there is a need to have detailed record with failure. ie-ms2-MS55-06...
Page 30 Always time and value is stored when defined state of conditions started or was terminated. Example table with sampled record: Channel 1: T[°C] Date and time 1.1.2009 08:01:11 23,8 1.1.2009 08:40:23 24,5 1.1.2009 09:05:07 26,8 1.1.2009 09:12:44 33,2 1.1.2009 10:08:09 37,5 1.1.2009 10:32:48 42,3 ie-ms2-MS55-06...
Page 31: Bookmark Ch
If other devices are controlled based on validity of the condition (relay outputs, sending of SMS message, audible indication etc.), always use nonzero hysteresis and nonzero time delay for creation of condition validity to avoid false alarms at transient effects of input value. ie-ms2-MS55-06...
Page 32 4. if power of data logger is switched OFF in area 3 or 4, after switching ON measured value is over limit decreased of hysteresis, condition stays valid. But if measured value does not match this, condition is invalid immediately. Other examples of configuration of conditions depended on measured value: • Setting of condition validity at measured value drop: ie-ms2-MS55-06...
Page 33 • Condition with fixed specified time validity measured value 3600s condition valid condition invalid To renew validity of condition measured value first must drop below specified limit and then to exceed the limit. ie-ms2-MS55-06...
Page 34 Combination of condition validity termination with hysteresis OR after specified delay measured value 3600s condition valid condition invalid measured value 3600s condition valid condition invalid To renew validity of condition measured value first must drop below specified limit and then to exceed the limit. ie-ms2-MS55-06...
Page 35 PIN code entering is enabled (if using Administration of users and passwords). If condition number 4 is set this way on any input channel, condition can be controlled also by means of SMS messages. Example: ie-ms2-MS55-06...
Page 36: Bookmark Ch
Some actions last during all alarm time (audible indication, ALARM OUT output activity, visual indication, relay closing), other actions last only at the moment of alarm creation (SMS message, e-mails). Changes of ALARM OUT output state or all alarms state can be recorded. ie-ms2-MS55-06...
Page 37: Application Notes
Remote condition by means of SMS messages is enabled. Command set<number of channel> activates condition number 4 on selected channel. Command clr < number of channel > deactivates this condition. Control of condition number 4 by means of ie-ms2-MS55-06...
Page 38: Possibilities Of Setting Logging Interval
LCD is displayed requirement Enter PIN and four asterisks by means of arrow keys enter first (highest digit) and press Enter after entering the last digit and pressing button Enter validity of PIN code is checked. If valid editing of selected item is allowed ie-ms2-MS55-06...
Page 39: Sharing Of Display Mode On Several Computers Together With Automatic Storing Of Data On Network
7.10. Can be confirmation of alarm signalization applied to acoustic alarm only? Yes, it is possible for MS55 data logger with firmware version 5.6.0 and later. The settings are possible at the Common bookmark - Confirmation of alarm signalization – button Advanced. Use the latest version of software.
Page 40: What Is It "Latched Alarms
This feature is available for MS55 data logger with firmware version 5.6.0 and later. Description of setting is specified in Appendix No. 6. Use the latest version of software.
Page 41: Problems In Communication With Computer
(see setting conditions) in risky installations. Also faulty probe or transducer can cause such troubles. 7.17. Problems in communication with computer Possibilities of trouble shooting of usual problems can be found in Appendix No. 4 at concrete communication interface. ie-ms2-MS55-06...
Page 42: Recommendation For Operation And Maintenance
5. Functional verification of data logger (functions used in application): A) verification of data transfer to computer B) verification of alarms – change input value to activate alarm and check on display and also in external audio indication (if used) ie-ms2-MS55-06...
Page 43 Placing out of operation after end of device life Disconnect the power cord and return data logger to the supplier or specialized company. Notice: data logger contains back-up Lithium battery on motherboard and on each counter input module (CTU, CTK) ie-ms2-MS55-06...
Page 44: Technical Description And Parameters Of Data Logger
3 x 10 cycles Electric life of relay contact: 1 x 10 cycles Material of contact: Ag Cd O Maximum wire cross section in terminal: 1,5 mm Dimensions 140 x 211 mm Mounting MP019 on DIN rail 35mm or MP013 holders ie-ms2-MS55-06...
Page 45 Setting of communication serial link, 1 start bit, 8 data bits, 1 stop bit, without parity communication speed 1200Bd , 9600Bd, 19200Bd, 57600Bd, 115200 Bd, 230400Bd ... this speed is adjustable only for SMS messages transmission by means of interface RS232 ie-ms2-MS55-06...
Page 46 Device is tested in accordance with EN 61326-1: 2006 article 6 table 1 radiation: EN 55022 ed. 2 class B immunity: EN 61000-4-2: class B (4/8 kV) EN 61000-4-3: class A (3V/m) EN 61000-4-4: class A (0,5/1 kV) EN 61000-4-5: class A EN 61000-4-6: class A (3 V) ie-ms2-MS55-06...
Page 47 If needed user can recalculate measured value to desired real value with physical unit by means of a special menu item Recalculations in the PC program. Galvanic isolated inputs have isolation strength of 500 V. It is not tested as safety isolation, see Not allowed manipulations and warning. ie-ms2-MS55-06...
Page 48 ± 5 A maximum Overload capacity: Input module type B2 and B2G Measured value: dc current Range: (0.. 5) A 0.1 % from range (± 5 mA) Accuracy: approximately 0.04  Input resistance: 10% (current ± 5.5 A maximum) Overload capacity: ie-ms2-MS55-06...
Page 49 General parameters of ac inputs non-sine signal: symmetric rectangular 1:1 additional error 11% additional error – 4% symmetric triangle time response t step from 0 to of range approximately 2 s step from of range to 0 approximately 10 s ie-ms2-MS55-06...
Page 50 50 in maximum Input module type E4 Measured value: ac voltage Range: (0.. 50) V 1 % from range (± 0,5 V) Accuracy: Input resistance: >700 k Overload capacity: 100 V maximum (from safety aspect only 50 V AC) ie-ms2-MS55-06...
Page 51 Input module type K3 Measured value: temperature from resistance sensor Pt1000/ 3850 ppm (-10 .. 50) °C Range: ±0.06 °C Accuracy (without probe): Measuring current: approximately 0,2 mA (depends on temperature) ± 5 V maximum Maximum voltage on input: ie-ms2-MS55-06...
Page 52 T (Cu / Cu-Ni) (-200..400) °C Range: ± (0.3 % from measured value + 1,5 °C) Accuracy without probe: compensated at temperature range (0..50) °C Cold junction: ± 5 V maximum Maximum voltage on input: ie-ms2-MS55-06...
Page 53 „L“: 0 to 0,8 V Input level: state „H“: 3 to 30 V maximum (1..9) mA .. depending on applied input voltage in state „H“ Input current: Minimum length of 200 ms input pulse: Galvanic isolated: 500 V, not designed for safety function ie-ms2-MS55-06...
Page 54 It is prohibited to copy and make any changes in this manual, without explicit agreement of company COMET SYSTEM, s.r.o. All rights reserved. COMET SYSTEM, s.r.o. makes constant development and improvement of their products. Manufacturer reserves the right to make technical changes to the device without previous notice. Misprints reserved.
