  • Page 1 EN User Manual | Washer Dryer EWI7294M2B...

  • Page 2: Table Of Contents

    Welcome to Electrolux! Thank you for choosing our appliance. Get usage advice, brochures, trouble shooter, service and repair information: www.electrolux.com/support Subject to change without notice. CONTENTS 1. SAFETY INFORMATION................2 2. SAFETY INSTRUCTIONS................5 3. PRODUCT DESCRIPTION................7 4. TECHNICAL DATA..................9 5.

  • Page 3: General Safety

    • This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning the use of the appliance in a safe way and understand the hazards involved.
  • Page 4 • The appliance shall be installed as a freestanding product or below the kitchen worktop if space margins permit. • Do not install the appliance behind a lockable door, a sliding door or a door with a hinge on the opposite side, that would prevent the appliance door from being fully open.

  • Page 5: Safety Instructions

    • Items that have been soiled with substances such as vegetable or mineral oil, acetone, alcohol, petrol, kerosene, spot removers, turpentine, waxes and wax removers should be washed separately with an extra amount of detergent before being dried in the washer dryer. •...

  • Page 6: Electrical Connection

    • Make sure that there is air circulation • Ensure that there are no visible water between the appliance and the floor. leaks during and after the first use of the • Remove all the packaging and the transit appliance. bolts.

  • Page 7: Product Description

    Refresh steam programme, offers the and the type of fabric without consuming perfect solution for refreshing even the more time, energy and water than most delicate garments without washing. necessary. Use the delicate fragrance exclusively developed by Electrolux to add a ENGLISH...

  • Page 8: Appliance Overview

    Access your appliance details, documentation and articles on how to use the best features (User Manual also available at electrolux.com/manuals ) • Get usage advice, troubleshooting, service and repair information (also available at electrolux.com/ support ) • Buy accessories, Consumable and Original Spare parts for you appliance (also available at electrolux.com/shop )

  • Page 9: Technical Data

    4. TECHNICAL DATA Dimension Width/ Height/ Total depth 59.7 cm /84.7 cm /57.6 cm Electrical connection Voltage 230 V Overall power 2100 W Fuse 10 A Frequency 50 Hz Level of protection against ingress of solid particles and moisture IPX4 ensured by the protective cover, except where the low voltage equipment has no protection against moisture Cold water...

  • Page 10: Information For Installation

    Adjust the appliance correctly to prevent vibration, noise and movement of the appliance when it operates. 1. Install the appliance on a flat hard floor. The appliance must be levelled and stable. Make sure that the appliance does not touch the wall or other units and there is air circulation below the appliance.
  • Page 11 the hose because of its natural ageing. 5. Connect the other end of the COLD water The sector in the window shows this fault inlet hose to the cold water tap with 3/4" A. If this occurs, close the water tap and thread.
  • Page 12 The drain hose can be bent into U shape and ratings. Make sure that they are compatible put around the plastic guide. On the edge of a with the mains power supply. sink - Fasten the guide to the water tap or to Check that your domestic electrical the wall.

  • Page 13: Control Panel

    6. CONTROL PANEL 6.1 Control panel description The options are not selectable with all washing programmes. Check the compatibility between options and washing programmes in the "Options compatibility with programmes" paragraph in the "Programmes" chapter. An option can exclude another one, in this case the appliance doesn't allow you to set the incompatible options together.
  • Page 14 6.2 Display Door locked indicator. The digital indicator can show: • Programme duration (e. g. , washing and/or drying phase). • Delay time (e. g. • Cycle end ( • Warning code (e.g. • Error indicator ( Time Manager indicator. Extra Rinse indicator.

  • Page 15: Dial And Buttons

    7. DIAL AND BUTTONS 7.1 Introduction The indicator Cold corresponds to cold water. 7.6 Spin When you set a programme, the appliance The options/functions are not available automatically sets the default spin speed. with all washing programmes. Check the compatibility between options/functions Touch repeatedly this button to: and washing programmes in the •...

  • Page 16: Permanent Extra Rinse

    indicator The option can increase the programme duration. 7.8 Permanent Extra Rinse With this option you can permanently have an extra rinse when you set a new programme. ■ ■ To activate/deactivate this option, hold the Prewash button pressed for 3 seconds until ■...

  • Page 17: Settings

    The display shows the selected delay time. you have to dry (refer to "Timed drying" table). The display shows the set value. After touching the Start/Pause button, the appliance begins the countdown and the door Each time you touch this button the time is locked.

  • Page 18: Factory Defaults

    8.4 Factory Defaults 1. Switch the appliance on by pressing the On/Off button. This function allows to restore the factory 2. Press and hold the Temperature and Spin default options. To activate this option follow buttons for some seconds. steps below: 3.

  • Page 19: Programmes

    10. PROGRAMMES 10.1 Programme Chart Programme Reference Maxi‐ Programme description Default tempera‐ spin speed (Type of load and level of soiling) ture Spin speed load Temperature range range 1400 rpm 5.0 kg Programme to treat mixed fabrics (cotton and synthetic (1400 - 400 items) up to 5 kg.
  • Page 20 Items with label "Dry clean only". FreshScent System Electrolux fragrance. If you use this special gentle fragrance, your laundry will scent as just washed. Read care‐ fully the instructions supplied with the fragrance. Reduce the fragrance dosage when treating smaller load. By means of the Time Manager button, you can reduce the programme duration when treating items labeled to be washed at low temperature.
  • Page 21 Programme Reference Maxi‐ Programme description Default tempera‐ spin speed (Type of load and level of soiling) ture Spin speed load Temperature range range 1.0 kg Cotton, synthetic and mixed items. Special steam cycle without washing that can be used to prepare your dried laun‐ Steam Refresh dry for ironing or refresh garments worn once.
  • Page 22 Programme Reference Maxi‐ Programme description Default tempera‐ spin speed (Type of load and level of soiling) ture Spin speed load Temperature range range Reset position. The display shows dashes only. According to Commission Regulation EU 2019/2023. This programme at default temperature and spin speed, in washing only mode, with rated capacity 9.0 kg is able to clean normally soiled cotton laundry declared to be washable at 40 °C or 60 °C, together in the same cycle.
  • Page 23 Programme ■ ■ ■ ▲ ■ ■ Wool ■ ■ ■ Spin/Drain ■ ■ ■ ■ ■ Rinse ■ ■ ▲ ■ ■ Machine Clean ■ ■ Steam Refresh Jeans ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■...

  • Page 24: Automatic Drying

    Programme Universal Liquid Univer‐ Liquid for col‐ Delicates Special oureds woollens powder 1) Wool ▲ ▲ Jeans ▲ ▲ ▲ Outdoor ▲ ▲ Hygiene ▲ ▲ ▲ OneGo 20/60min ▲ ▲ At temperature higher than 60 °C the use of powder detergent is recommended. ▲...

  • Page 25: Timed Drying

    Dryness Level Type of fabric Load Synthetics and mixed fabrics up to 3.0 kg (jumpers, blouses, underwear, household and bed linen) Delicate fabrics up to 2.0 kg (acrylics, viscose and delicate mixed fabrics) Wool items up to 1.0 kg (woollen jumpers) Outdoor sporting garments up to 2.0 kg (outdoor clothing, technical, sport...

  • Page 26: Daily Use - Washing Only

    Dryness Level Type of fabric Load Spin Suggested du‐ (kg) speed ration (mins) (rpm) Wool 1200 110 - 130 (woollen jumpers) Outdoor sporting garments 1200 120 - 140 (outdoor clothing, technical, sport fabrics, water‐ proof and breathable jackets, shell jackets) Denim garments 1200 110 - 130...

  • Page 27: Filling The Detergent And Additives

    11.3 Filling the detergent and additives 2. Press the lever down to remove the dispenser. 3. To use powder detergent, turn the flap - Compartment for prewash phase, soak pro‐ gramme or stain remover. - Compartment for washing phase. - Compartment for fabric softener and other liquid treatments(fabric conditioner, starch).

  • Page 28: Setting A Programme

    The drain pump can operate shortly before the appliance fills water. 11.7 Starting a programme with the delay start 1. Touch the Delay Start button repeatedly until the display shows the desired delay time. The related indicator comes on. 2. Touch the Start/Pause button.

  • Page 29: Cancelling A Running Programme

    11.10 Cancelling a running After touching the Start/Pause button the programme SensiCare System starts the laundry load detection: 1. Press the On/Off button to cancel the programme and to deactivate the 1. The appliance detects the load in the first appliance.

  • Page 30: End Of The Programme

    11.12 End of the programme 1. If necessary, touch the Spin button to decrease the spin speed proposed by the When the programme has finished, the appliance. appliance stops automatically. The acoustic 2. Press the Start/Pause button: the signals operate (if they are active). The appliance drains the water and spins.

  • Page 31: Washing And Timed Drying

    12.1 Complete wash&dry 2. Touch button Start/Pause to start the programme programme. The SensiCare estimation starts. Non-automatic wash&dry programmes In the display the door locked indicator In some washing programmes, you can comes on. combine Mode - Wash and Mode - Dry for The display also shows the remaining running a complete wash&dry programme.

  • Page 32: Daily Use - Drying Only

    13. DAILY USE - DRYING ONLY The display also shows the remaining WARNING! programme time. Refer to Safety chapters. 13.3 Timed Drying 1. Tap on the Time Dry button repeatedly to set the desired time value (see the This appliance is an automatic washer "Timed drying"...

  • Page 33: Fluff In The Fabrics

    14. FLUFF IN THE FABRICS During the washing and/or drying phase, To remove the fluff inside the drum, set a some types of fabric, (sponge, wool, special programme: sweatshirt) could release fluff. • Empty the drum. • Clean the drum, the gasket and the door The released fluff could stick to the fabrics with a wet cloth.

  • Page 34: Stubborn Stains

    – powder detergents (also tablets and single-dose detergents) for all types of fabric, excluding delicate. Prefer powder detergents containing bleach for whites and laundry sanitization, – liquid detergents (also single-dose detergents) , preferably for low temperature wash programmes (60 °C max) for all types of fabric, or special ones for woollens only.

  • Page 35: Drying Cycle Duration

    15.8 Garment labels helps to reduce energy and water consumption. When you dry the laundry, obey the • With adequate pre-treatment, stains and indications on the labels of the limited soiling can be removed; the manufacturers: laundry can then be washed at a lower temperature.

  • Page 36: Care And Cleaning

    16. CARE AND CLEANING "Cleaning the inlet hose and the valve filter" WARNING! paragraphs. If necessary, please contact the Authorised Service Centre. Refer to Safety chapters. 16.3 External cleaning 16.1 Periodic cleaning schedule Clean the appliance with mild soap and warm Periodic cleaning helps to extend the life water only.

  • Page 37: Cleaning The Drum

    2. Run the Machine Clean programme. For more details, refer to washing programme table. Refer to "Cleaning the drum" paragraph. 3. Add a small quantity of powder detergent into the empty drum, in order to rinse out 16.6 Door seal any left residues.

  • Page 38: Cleaning The Drain Pump

    Regularly check the drain pump filter and make sure that it is clean. Clean the drain pump if: • The appliance does not drain the water. • The drum does not turn. • The appliance makes an unusual noise because of the blockage of the drain pump.
  • Page 39 4. Turn the filter 180 degrees in anti- 10. Clean the filter under the water tap. clockwise direction to open it, without removing. Let the water flow out. 11. Put the filter back into the special guides by turning it clockwise. Make sure that you tighten the filter correctly to prevent leakages.

  • Page 40: Cleaning The Inlet Hose And The Valve Filter

    16.10 Cleaning the inlet hose and the valve filter It is recommended to clean both the filters of the inlet hose and valve occasionally to remove any deposit, collected over the time: 1. Remove the inlet hose from the tap and clean the filter.

  • Page 41: Troubleshooting

    17. TROUBLESHOOTING WARNING! Refer to Safety chapters. 17.1 Alarm Codes and Possible failures The appliance does not start or it stops during operation. First try to find a solution to the problem (refer to the tables). WARNING! Deactivate the appliance before carrying out any check. With some problems, the display shows an alarm code and the Start/ Pause button may flash continuously:...
  • Page 42 • Make sure that the sink spigot is not clogged. • Make sure that the drain hose has no kinks or bends. The appliance does not • Make sure that the drain filter is not clogged. Clean the filter, if necessary. Re‐ drain the water.
  • Page 43 Problem Possible solution • Make sure that a washing programme that ends with water in tub, has not been selected. • Make sure that the washing programme is finished. • Set the drain or the spin programme if there is water in the drum. You cannot open the appli‐...

  • Page 44: Emergency Door Opening

    17.2 Emergency door opening To open the door, proceed as follows: 1. Press the On/Off button to switch the In case of power failure or functioning failure appliance off. the appliance door remains locked. The 2. Disconnect the mains plug from the washing programme continues when the mains socket.

  • Page 45: Washing Only

    18.2 Legend Laundry load. hh:mm Programme duration. Energy consumption. °C Temperature in the laundry. Litres Water consumption. Spin speed. Remaining moisture at the end of the cycle. The higher is the spin speed, the higher is the noise and the lower is the remaining moisture at the end of washing cycle. Values and programme duration may differ depending on different conditions (e.g.
  • Page 46 18.4 Common programmes - Washing only These values are indicative only. Programme rpm 1) Litres hh:mm °C Cottons 2.800 100.0 03:30 52.0 85.0 1400 90°C Cottons 1.950 95.0 03:10 52.0 55.0 1400 60°C Cottons 0.350 95.0 03:00 52.0 20.0 1400 20°C Synthetics 0.600...

  • Page 47: Environmental Concerns

    19. ENVIRONMENTAL CONCERNS appliances marked with the symbol with Recycle materials with the symbol . Put the the household waste. Return the product to packaging in relevant containers to recycle it. your local recycling facility or contact your Help protect the environment and human municipal office.
