Installation Guide
Ceramic Oval Handle Trim Kit
M product numbers are for Mexico (i.e. K-12345M)
Los números de productos seguidos de
M corresponden a México (Ej.
K-12345M)
Français, page "Français-1"
Español, página "Español-1"
110424-2-AC
K-251, K-253, K-258,
K-260, K-262, K-264,
K-273, K-274
Advertisement
Related Manuals for Kohler K-253
Summary of Contents for Kohler K-253
- Page 1 Installation Guide Ceramic Oval Handle Trim Kit K-251, K-253, K-258, K-260, K-262, K-264, K-273, K-274 M product numbers are for Mexico (i.e. K-12345M) Los números de productos seguidos de M corresponden a México (Ej. K-12345M) Français, page “Français-1” Español, página “Español-1”...
-
Page 2: Tools And Materials
Please read all instructions before you begin. Shut off the water supply. Observe all local plumbing and building codes. Kohler Co. reserves the right to make revisions in the design of faucets without notice, as specified in the Price Book. 110424-2-AC... - Page 3 Place a ceramic cap into the oval handle and secure it from underneath with a flathead screw. Align the handle assembly on the stem extension and secure with a setscrew. Repeat with the second handle if needed. Kohler Co. 110424-2-AC...
- Page 4 Secure the bonnet onto the valve with the oval-head screw. Place the ceramic cap into the oval handle and secure from underneath with a flathead screw. Align and place the handle assembly onto the bonnet. Secure with the setscrew. 110424-2-AC Kohler Co.
- Page 5 For new and replacement installations, place the ceramic cap into the oval handle, and secure from underneath with a flathead screw. Align and place the handle assembly onto the bonnet and secure with a setscrew. Kohler Co. 110424-2-AC...
