- Page 1 INSTALLATION MANUAL Roof Mounting System NOVA FLEXFIT+ TILE HOOK ARTICLE #920-122120 / 920-122120-B REGINA WAUTERSWEG 13, 8800 ROESELARE BELGIUM +32 (0)51 14 05 94 UP-TO 30% FASTER PORTRAIT LANDSCAPE 25 YEAR INSTALLATION WARRANTY WWW.NOVAMOUNTING.COM...
-
Page 2: Testing & Certification
NOVA Mounting. WARRANTY Warranty according to the terms and conditions found on the website www.novamounting.com NOVA is not accountable for the roof’s capability to maintain the introduced forces. Please check the roof’s compatibility with a static engineer. - Page 3 Tile roof mounting system 13mm...
- Page 4 Solar panels layout...
- Page 5 Installation Procedure STEP.1 Remove or slide the tile from the roof girder slightly and place the hook onto the wooden rafter (refer to the picture below). Using wooden screws to fix the hooks and then put the removed tiles back on as required. 1.
- Page 6 STEP.2 Loosen the bolt of NOVA rail clamp or fixture, then place the rail into the rail fixture. 1.Loosen the bolt of the rail fixture. loosen loosen...
- Page 7 Recommended Torque 12-14N.M Recommended Torque 12-14N.M...
- Page 8 STEP. 3 Insert the NOVA inner rail connector into one end of the rail, then insert the other rail into it. STEP.4 Array layout...
- Page 9 STEP.5 Installing NOVA panel clamps; When installing the first panel, adjust the position of the solar panel according to the technical drawings, secure the panel on the rails by the panel clamps. Attention：1.Ensure the panel clamps are pushed up against the solar panel.
- Page 10 Recommended Torque 12-14N.M Attention: Please install the solar panels vertically.
- Page 11 Attention: Double check all bolts are tightened when solar panel installation completed.
- Page 12 NOVA Tri Rail Joiner NOVA HD Rail Article # 920-12221_ 920-122810 920-12222_ Figure Part Name NOVA HD Rail Joiner NOVA FLEXFIT+ Tile Hook Article # 920-122820 920-122120 Figure Part Name NOVA Click End Clamp 30- NOVA Click Mid Clamp 30- 40mm...
